105425510101(US)
EN
FIBARO Button
Z-Wave Plus compatible device that allows you to
control other devices through the Z-Wave network and
run various scenes defined in FIBARO System.
Different actions may be triggered with one to five
clicks or by holding the button down. In Panic Button
mode, each press of the button results in triggering the
Fibaro Alarm. With its small design and wireless
communication, the FIBARO Button can be convenien-
tly mounted on any surface and in any position or
location at home, e.g. beside the bed or under the
desk.
For full instruction manual and technical
specification please visit our website:
Read the manual before attempting
Specifications
Power supply:
Battery type:
Operating temperature:
Dimensions (diameter x height):
Basic activation of the device
1) Press and turn the button counter-clockwise to open
the casing.
2) Remove the paper strip underneath the battery.
3) Press and turn the button clockwise to close the
casing.
4) Locate the device nearby the main Z-Wave controller.
5) Set the main Z-Wave controller in add mode.
6) Click the button six times at least.
7) Wait for the device to be added into the system,
successful adding will be confirmed by the controller.
8) Install the device in desired location using the
attached self-adhesive pad.
9) Click the button four times to wake it up.
FIBARO BUTTON
FGPB-101
is a compact, battery-powered,
manuals.fibaro.com/en/button
to install the device!
1a. Press
1b. Turn
FIBARO Button - Opening
FCC ID:
2AA9MFGPB101
IC number:
20430-FGPB101
3.6V battery
ER14250 (½AA)
32 - 104°F
1.81" x 1.34"
