Summary of Contents for FIBARO Swipe
- Page 1 SWIPE...
- Page 2 Scan the code to watch the video. Watch the video tutorial before configuring the device. Support If you need help configuring the FIBARO Swipe, take advantage of our guides and technical manuals available at: http://manuals.fibaro.com...
-
Page 3: Package Contents
Package Contents Manuals and Warranty Micro-USB Cable Holder FIBARO Swipe... - Page 4 Step 1. Detach the frame Step 2. Slide out the plate Detach the front magnetic frame using the Slide the detection plate down to remove it gap in the bottom of the housing. from the housing. Step 3. Engage the batteries Step 4.
- Page 5 Step 5. Replace the picture Step 6. Attach the frame You can replace the existing photo with Attach the front magnetic frame. your favorite one at this point. Step 7. Place on the holder Step 8. Plug the USB cable Place the assembled device on its holder.
- Page 6 Adding the device The device must be in the direct range of the Z-Wave controller during the adding process. Step 1 Login to the Home Center controller and select “Devices” from the main menu. Step 2 Select the “Add or remove device” option from the left side menu.
-
Page 7: Adding The Device
A loud sound sequence will confirm entering the menu, keep holding your hand. Step 5 After hearing two short beeps, take your hand away and swipe up to confirm selection. Step 6 Wait for the device to be added to... - Page 8 Home Center interface. Click the icon in the top right corner of the FIBARO Swipe window. Select a gesture to which you want to assign reaction and click the plus icon (New Reaction). Select the device you want to control.
- Page 9 Drag and drop two or three gestures to create a desired sequence. Confirm the selection by clicking “Confirm new sequence”. Wake up the Swipe according to the instructions on page 11 (section Menu). Click the plus icon (New Reaction) next to the newly created sequence.
- Page 10 Gestures and sequences FIBARO Swipe supports 6 gestures (up, down, left, right, clockwise, counter-clockwise) and combinations of gestures, called sequences. Sequences can be made of two or three gestures. Every sequence must be unique and cannot contain circular gestures. Additionally, two identical gestures may not be used next to each other.
-
Page 11: Acoustic Signals
Acoustic signals FIBARO Swipe is equipped with a buzzer, which signals detected gestures, menu position and status of the device. Validity of every detected gesture or sequence is signalled by: 2 short beeps - gesture/sequence is valid 1 long beep - gesture/sequence is invalid Intermittent tone - during a circular gesture. - Page 12 © 2016 Fibar Group S.A. All rights reserved. Made in Poland. 105420610101 www.fibaro.com...
