Summary of Contents for Invertek Drives OPTIDRIVE E2

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION Safety of machinery, and safety-critical applications Optidrive hardware and software are designed and tested to a high standard and failures are unlikely. SAFETY NOTICES It is the responsibility of the installer to ensure that the equipment or system into which the product is incorporated complies with the EMC legislation of the country of use.

  • Page 3: Safety Notices

    Copyright Invertek Drives Ltd © 2007 The manufacturer accepts no liability for any consequences resulting from inappropriate, negligent or incorrect installation, or adjustment of the optional operating parameters of the drive or from mismatching of the drive to the motor.
  • Page 4 Ensure that all terminals are tightened to the appropriate torque (see table) WARRANTY All Invertek Drives Ltd (IDL) products carry a 2-year warranty, valid from the date of manufacture. Complete Warranty Terms and Conditions are available upon request from your IDL Authorised Distributor.

  • Page 5: Electrical Installation

    Each drive star connected to system earth point Earth L2/ N L3 – not 1Ø,230V Isolator other drives Contactor, mcb or Fuses L1 L2 L3 U V W Screened motor cable connects to motor frame earth U V W ELECTRICAL INSTALLATION Connect drive according to diagram (above), ensuring that motor terminal box connections are correct (see diagram, below).

  • Page 6: Control Terminal Block

    OPERATION – USING THE KEYPAD MANAGING THE KEYPAD When the drive is delivered from the factory, only the Standard Parameter Set (see overleaf) is accessible. To access the Standard Parameter Set, press the Navigate key ⇔ for >1 sec. • Scroll through P-01 to P-14 (and roll over to P-01) by pressing •...
  • Page 7 OPERATING IN KEYPAD MODE Set P-12 = 1(this allows the Optidrive to be controlled from the keypad): Enable the drive by closing digital input 1. The display will show StoP. Press the START key. The display shows H 0.0. Press to increase speed The drive will run forward, increasing speed until...

  • Page 8: Mechanical Installation

    MECHANICAL INSTALLATION Carefully inspect the Optidrive before installation to ensure it is undamaged. Store the Optidrive in its box until required. Storage should be clean and dry and within the temperature range –40 C to 60 Install the Optidrive on a flat, vertical, flame-resistant, vibration- free mounting (NOTE: Drive is for INDOOR USE ONLY).

  • Page 9: Grounding (Earthing)

    OPERATION – MOTOR TERMINAL BOX CONNECTIONS Motors are connected in either STAR or DELTA. The motor rating plate will indicate the voltage rating for the method of connection, ensure that this matches the Optidrive operating voltage. Υ (STAR) connection Δ (DELTA) connection U V W Wires from Optidrive - NOTE: INDOOR USE ONLY DIMENSIONS...
  • Page 10 EASY STARTUP When delivered, the Optidrive is in the default state, meaning that it is set to operate in terminal mode and all parameters (P-xx) have the default values as shown overleaf. Connect a control switch between the control terminals 1 and 2. Ω...
  • Page 11 STANDARD PARAMETER SET Explanation Par. Description Range Default P-01 Maximum speed P-02 to 5*P-09 (max 500Hz) 50Hz (60Hz) Maximum speed limit – Hz or rpm. See P-10 P-02 Minimum speed 0 to P-01 (max 500Hz) Minimum speed limit – Hz or rpm. See P-10 P-03 Accel ramp time (s) 0 to 600s...

  • Page 12: Troubleshooting

    OPTIDRIVE E2 OPTIONS DIGITAL INPUTS – Terminal mode (P-12 = 0) The following additional P-15 Digital Input 1 Digital Input 2 Digital Input 3 Analog Input Comments products are available: Open: Stop (disable) Open: Analog speed ref Open: Forward run...
