TURBO HD Bullet &Turret Camera User Manual UD.6L0201D2097A01 Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. This manual is applicable to the models below (X indicates certain character(s), e.g.: DS-2CE16CXT-...
Privacy Notice Surveillance laws vary by jurisdiction. Check all relevant laws in your jurisdiction before using this product for surveillance purposes to ensure that your use of this product conforms. Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules.
2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the European Union. See the product documentation for specific battery information. The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg).
1.2.2 Overview of Type II Camera Figure 1-2 Overview of Type II Camera 1.2.3 Overview of Type III Camera Mounting Base TVI Cable Power Cable Camera Enclosure Figure 1-3 Overview of Type III Camera 2 Installation Before you start: Please make sure that the device in the package is in good condition and all the assembly parts are included.
2.1 Installation of Type I & Type II Camera The installation of Type I and Type II cameras are the same, here we take the installation of Type I camera as an example Type I and Type II cameras support wall-mounting, ceiling-mounting, and gang box installation methods.
Page 6
5. Adjust the surveillance angle by loosening the 3 adjusting screws. 6. Tighten the fixing screws and the fixing ring to fix the camera. Figure 2-3 Fix the Camera to the Wall 2.1.3 Installation with Gang Box Steps: 1.Attach the supplied drill template to the ceiling/ wall according , as shown in Figure 2-4.
Page 7
5.Connect the corresponding power cable and video cable. 6.Fix the camera to the ceiling with the supplied fixing screws. Figure 2-7 Fix the Camera to Gang Box 7.Loosen the screws and trim ring to adjust the surveillance angle. 8. Fix the camera by tightening the screws and trim ring.
Page 8
4.Connect the corresponding power cable and video cable. 5.Secure the camera to the mounting base. 6.Adjust the camera according to the figure below to get an optimum angle. 360° 0-75° 360° Figure 2-11 3-axis Adjustment 2.2.2 Wall Mounting Steps: 1. Install the wall mounting bracket onto the wall, as shown in Figure 2-12.
