Samsung Flip WM55B Quick Setup Manual

Quick Setup Guide
WM55B WM65B
* Recommended hours of use per day of this product is under 16 hours. If the product is used for longer than 16 hours a day, the warranty may be
void.
* The colour and the appearance may differ depending on the product, and the content in the manual is subject to change without prior notice to
improve the performance.
* Download the user manual from the following Samsung Website for further details.
http://www.samsung.com/displaysolutions
Checking the Components
Quick Setup Guide
1
Warranty card (Not available in some locations)
2
Regulatory guide
3
Waste Electrical & Electronic Equipment
4
Power cord
5
Contact the vendor where you purchased the product if any components are missing.
Components may differ in different locations.
Refer to the installation guide for the WMB stand or wall mount (available for optional purchase).
Troubleshooting Guide
Issues
Touching does not work when
HDMI connection is used.
Specifications
Model Name
Size
Panel
Display area
Power Supply
Operating
Environmental
considerations
Storage
* This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take
adequate measures.
* For detailed device specifications, visit the Samsung website.
* Connecting the LAN Cable:
Use Cat7(*STP Type) cable for the connection.(10/100 Mbps)
(*Shielded Twist Pair)
* For EXTERNAL (USB), connect a USB terminal that can support under 100 W.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United
States and other countries.
Check whether the TOUCH
USB cable.
WM55B
55 CLASS (54.6 inches / 138.7 cm)
1209.6 mm (H) x 680.4 mm (V)
Refer to the label at the back of the product as the standard voltage can vary in different countries.
USB cable
6
Touch Pen x 2
7
Terminal cover, Screw (M4 x L10) x 2
8
Cable cover, Screw (M4 x L10)
9
Solutions
port on the product is connected to a USB port on the PC using the supplied
AC100-240V~ 50/60Hz
Temperature: 0 °C – 40 °C (32 °F – 104 °F)
Humidity: 10% – 80%, non-condensing
Temperature: -20 °C – 45 °C (-4 °F – 113 °F)
Humidity: 5% – 95%, non-condensing
BN68-14173G-00
WM65B
65 CLASS (64.5 inches / 163.9 cm)
1428.48 mm (H) x 803.52 mm (V)
