SyncMaster LD220HD
LCD TV Monitor

User Manual

The color and the appearance may differ depending on the
product, and the specifications are subject to change
without prior notice to improve the performance.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SyncMaster LD220HD and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung SyncMaster LD220HD

Summary of Contents for Samsung SyncMaster LD220HD

  • Page 1: User Manual

    SyncMaster LD220HD LCD TV Monitor User Manual The color and the appearance may differ depending on the product, and the specifications are subject to change without prior notice to improve the performance.

  • Page 2: Table Of Contents

    Power Saving Function ........6-2 Contact SAMSUNG WORLDWIDE ......6-3 Correct Disposal .

  • Page 3: Major Safety Precautions

    The contents of this manual may not be partially or in whole reproduced, distributed or used in any form without the written permission of Samsung Electronics, Co., Ltd. The SAMSUNG logo and SyncMaster are the registered trademarks of Samsung Electronics, Co., Ltd. Microsoft, Windows and Windows NT are the registered trademarks of Microsoft Corporation.

  • Page 4: Care And Maintenance

    Care and Maintenance External Surface and Screen Maintenance Clean the product with a soft dry cloth. • Avoid cleaning the product with an inflammable substance such as benzene or thinner or with a wet cloth. This may result in a problem with the product.

  • Page 5: Safety Precautions

    Safety Precautions Icons used for safety precautions ICON NAME Warning Caution Meaning of Signs Do not perform. Do not disassemble. Do not touch. Power Related The following images are for your reference and may differ depending on models and countries. Warning Avoid using a damaged power cord or plug or a loose power outlet.

  • Page 6: Installation Related

    Caution Avoid unplugging the power plug while the product is operating. • Otherwise, it may damage the product due to electric shock. When unplugging the power plug from the wall outlet, make sure to hold it by the plug and not by the cord. •...

  • Page 7: Cleaning Related

    Avoid installing the product where children may reach it. • If a child touches the product, the product may fall and this may result in injury. • Since the front part is heavier, install the product on a flat and stable surface. Install the antenna far away from any high voltage cables.

  • Page 8: Usage Related

    Caution Avoid spraying cleansing agent directly onto the product. • This may result in discoloration or cracking of the exterior of the product or the panel coming off. If you can't get the product clean with just the supplied cloth, use a soft, damp cloth with a "monitor-exclusive cleansing agent"...
  • Page 9 Avoid moving the product by pulling the power cord or antenna cable. • Otherwise, it may result in electric shock, fire or a problem with the product due to damage to the cable. Avoid lifting up or moving the product by holding only the power cord or signal cable.
  • Page 10 Keep the small accessories in a location out of the reach of children. Avoid placing a heavy object over the prod- uct. • Otherwise, it may result in a problem with the product or injury. Be careful that children do not place the bat- teries in their mouths when removed from the remote control.

  • Page 11: Installing The Product

    Installing the Product Package Contents • Unpack the product and check if all of the following contents have been included. • Store the packaging box in case you need to move the product at a later stage. Quick Setup Guide (Not available in all locations) Batteries (AAA X 2) 'DVI-A to D-Sub' Cable...

  • Page 12: Connecting To A Computer

    Connecting to a Computer 1. Connect the product to a PC depending on the video output supported by the PC. The connecting part may differ depending on the product model. When the graphics card provides a D-Sub (analog) output Connect the [ ] port of the product to the [ •...
  • Page 13 2. Connect the [HDMI/PC/DVI-D AUDIO IN] port on the rear side of the monitor to the sound card of the PC. 3. Connect one end of the power cord to the [ POWER ] port of the product and connect the other end of the power cord to the 110V or 220V wall outlet.

  • Page 14: Using It As A Tv

    Using it as a TV You may view television programs on the monitor if it is connected to an antenna or cable/satellite system without installing any separate TV reception hardware or software on your computer. 1. Connect the cable/satellite or TV antenna cable to the [ANT IN] port on the rear side of the monitor. •...

  • Page 15: Connecting An Hdmi Cable

    Connecting an HDMI cable Connect the HDMI OUT port of the AV device (Blu-Ray/DVD/Cable/Satellite box) to the [HDMI IN] terminal of the monitor using the HDMI cable. Press the [SOURCE] button at the front of the monitor or on the remote control to select <HDMI> mode. You do not need to make a separate audio connection when connecting via HDMI.

  • Page 16: Connecting Using A Dvi To Hdmi Cable

    Connecting Using a DVI to HDMI Cable 1. Connect the DVI output terminal of an external device to the [HDMI IN] terminal of the monitor using a DVI to HDMI cable. 2. Connect the red and white plugs of an RCA to stereo (for PC) cable to the same colored audio output terminals of the digital output device, and connect the opposite plug to the [HDMI/PC/DVI-D AUDIO IN] terminal of the product.

  • Page 17: Connecting A Component Cable

    Connecting a Component cable 1. Connect the VIDEO OUT port of the AV device (DVD/VCR/Cable/Satellite box) to the [COMPONENT IN [P , Y]] input ports using a component video cable [P ,Y]. 2. Connect the audio port of the AV device (DVD/VCR/Cable/Satellite box) to the [COMPONENT IN [R-AUDIO-L]] port of the monitor.

  • Page 18: Connecting A Scart Cable

    Connecting a Scart cable 1. Connect the EXT(RGB) port of the monitor to the DVD Player using a SCART jack. 2. When a Scart device is connected to your monitor, the Source automatically changes to EXT. • Connect to the DVD Devices input if the device has a [EXT [RGB]] jack. •...

  • Page 19: Connecting Common Interface

    Connecting COMMON INTERFACE 1. Insert the CI CARD into the CAM in the direction of the arrow until it fits. 2. Insert the CAM with the CI CARD installed into the common interface slot. (Insert the CAM in the direction of the arrow, right up to the end so that it is parallel with the slot.) 3.

  • Page 20: Connecting Headphones

    Connecting Headphones Connect your headphones to the Headphone connection terminal. 2-10 Kensington Lock A Kensington Lock is an anti-theft device that enables users to lock the product so that they can safely use it in public locations. Since the shape and usage of the locking device may differ depending on the model and the manufacturer, for more information, refer to the User Manual supplied with the locking device.

  • Page 21: Using The Product

    Using the Product Plug & Play Feature When the TV is initially powered on, basic settings proceed automatically and subsequently. 1. Press the [POWER ] button on the remote control. • You can also use the [ • The message <Select the OSD Language.> is displayed. 2.
  • Page 22 8. The description for the connection method providing the best HD screen quality is displayed. Check the description and press the [ ] button. 9. The message <Enjoy your TV.> is displayed. When you have finished, press the [ ] button. If you want to reset this feature...

  • Page 23: Viewing The Control Panel

    Viewing the Control panel Touch one of the operating buttons lightly. The LED buttons appear. ICON [MENU] [ -/+ ] Remote Control Sensor Speaker Using the Product DESCRIPTION Use this button to select a function. Signals other than the TV signal can only be selected if the corresponding device is connected.

  • Page 24: Remote Control

    Remote Control The performance of the remote control may be affected by a TV or other electronic device operating near the product, causing a malfunction due to interference with the frequency. POWER Turns the product On/Off. Number Buttons Press to change the channel. Activates a highlighted menu item.

  • Page 25: Installing Batteries In The Remote Control

    Installing Batteries in the Remote Control 1. Lift the cover at the back of the remote control upward as shown in the figure. 2. Install two AAA size batteries. Make sure to match the +and - ends of the batteries with the diagram inside the compartment. 3.

  • Page 26: Teletext Feature

    Teletext Feature Most television stations provide written information services via Teletext. The index page of the teletext service gives you information on how to use the service. In addition, you can select various options to suit your requirements by using the remote control buttons.

  • Page 27: Using The Screen Adjustment Menu (Osd: On Screen Display)

    Using the Screen Adjustment Menu (OSD: On Screen Display) The Screen Adjustment Menu (OSD: On Screen Display) Structure TOP MENUS Picture MagicBright [PC / DVI] Auto Adjustment Picture Mode [TV / Ext. / Component / Sharpness HDMI] Picture Reset Sound Mode Audio Descrip- tion...
  • Page 28 Picture [PC / DVI ] The default setting may be different depending on the selected Input Mode (input signal source selected in External Input List) and the selected resolution Using the Product...
  • Page 29 MENU MagicBright <MagicBright> is a feature providing an optimum viewing environment depending on the contents of the image you are watching. Currently five different modes are available: <Entertain>, <Internet>, <Text>, <Dynamic Contrast> and <Custom>. Each mode has its own pre-configured brightness value.
  • Page 30 MENU Contrast / Brightness / You can use the on-screen menus to change the contrast and brightness according to personal pref- Sharpness erence. • <Contrast> - Adjust the Contrast. • <Brightness> - Adjust the Brightness. • <Sharpness> - Adjust the Sharpness. Not available when <MagicBright>...
  • Page 31 Picture [ TV / Ext. / Component / HDMI ] Using the Product...
  • Page 32 MENU Mode You can select the type of picture which best corresponds to your viewing requirements. You can activate either <Dynamic>, <Standard>, or <Movie>. • <Dynamic> Selects the picture for high-definition in a bright room. • <Standard> Selects the picture for optimum display in a normal environment. •...
  • Page 33 MENU Advanced Settings Samsung‘s new products allow you to make even more precise picture settings than previous mod- els. See below to adjust detailed picture settings. <Advanced Settings> is available in <Standard> or <Movie> mode. • <Black Tone> - You can select the level on the screen to adjust the screen depth.
  • Page 34 MENU Picture Options • <Colour Tone> The tone of the color can be changed. • <Cool> - <Normal> - <Warm1> - <Warm2> • • • <Size> You can switch the Size. • <Auto Wide> - Automatically adjusts the picture size to the "16:9" aspect ratio. •...
  • Page 35 MENU • <Digital NR> Digital Noise Reduction. If the broadcast signal received by your TV is weak, you can activate the Digital Noise Reduction feature to help reduce any static and ghosting that may appear on the screen. • <Off> - <Low> - <Medium> - <High> - <Auto> •...
  • Page 36 MENU Mode • <Standard> Choose Standard for the standard factory settings. • <Music> Choose Music when watching music videos or concerts. • <Movie> Choose Movie when viewing movies. • <Clear Voice > Emphasizes voice over other sounds. • <Custom > Choose Custom if you want to adjust the settings according to personal preference .
  • Page 37 MENU Audio Description This is an auxiliary audio function that provides an additional audio track for visually challenged per- sons. This function handles the Audio Stream for the AD (Audio Description), when it is sent along with the Main audio from the broadcaster. Users can turn the Audio Description On or Off and control the volume.
  • Page 38 Channel MENU Country Select the country in which the product is being used before you use the Auto Store feature. If you do not see your country in the list, select others. • <Digital Channel> You can change the country for digital channels. •...
  • Page 39 MENU Manual Store You can scan the frequency ranges available on your television in your area and store all the chan- nels found manually. • <Digital Channel> Manual store for digital channels. • <Channel> Set the Channel number using the ▲,▼ or number (0~9) buttons •...
  • Page 40 MENU Now & Next Guide / The EPG (Electronic Programme Guide) information is provided by the broadcasters. Programme Full Guide / Default entries may appear blank or out of date as a result of the information broadcast on a given channel. Guide The display will dynamically update as soon as new information becomes available.
  • Page 41 MENU Channel List Using this menu, you can Add / Delete or set Favourite channels and use the program guide for digi- tal broadcasts. You can select these options by simply pressing the [CH LIST] button on the remote control. •...
  • Page 42 Setup MENU Plug & Play This brings up the menu items that appeared when you first plugged in the TV. Language The language chosen affects only the language of the OSD. Time • <Clock> Setting the clock is necessary in order to use the various timer features of the TV. •...
  • Page 43 MENU • <Timer1 / Timer2 / Timer3> Three different on / off timer settings can be made. You must set the clock first. • <On Time> Set the <hour>, <minute>, <am/pm>, and <activate/inactivate>. (To activate the timer with the setting you’ve chosen, set to Activate.) •...
  • Page 44 MENU Child Lock This feature allows you to prevent unauthorized users, such as children, from watching unsuitable programme by muting out video and audio. • <Off>-<On> • Before the setup screen appears, the PIN number input screen appears. Enter your 4 digit PIN number.
  • Page 45 MENU Preference Primary Audio Language / Secondary Audio Language / Primary Subtitle Language /Secondary Sub- title Language / Primary Teletext Language /Secondary Teletext Language Using this feature, users can select one of the languages. The language selected here is the default when the user selects a channel.
  • Page 46 MENU Energy Saving This feature adjusts the brightness of the TV in order to reduce power consumption. When watching TV at night, set the <Energy Saving> mode option to <High> to reduce eye fatigue as well as power consumption. • <Off>...

  • Page 47: Setting Up Anynet

    <Anynet+> is a function that enables you to control all connected Samsung devices that support <Anynet+> with your Samsung TV‘s remote. The <Anynet+ > system can be used only with Samsung devices that have the <Anynet+> feature. To be sure your Samsung device has this feature, check if there is an <Anynet+>...
  • Page 48 Setup • <Anynet+ (HDMI-CEC)> To use the <Anynet+> Function, <Anynet+ (HDMI-CEC)> must be set to On. When the <Anynet+ (HDMI-CEC) >function is disabled, all the< Anynet+> related operations are deactivated. • <Auto Turn Off> Setting an <Anynet+> Device to turn Off automatically when the TV is turned off. The active source on the TV remote must be set to TV to use the <Anynet+>...
  • Page 49 Support Using the Product...
  • Page 50 • <Yes> : If during the sound test you can hear sound only from one speaker or not at all, select <Yes>. There may be a problem with the TV. Contact Samsung’s call center for assistance. • <No> : If you can hear sound from the speakers, select <No>. There may be a problem with your external equipment.

  • Page 51: Installing The Device Driver

    If you install the device driver, you can set up the appropriate resolution and frequency for the product. The device driver is included on the CD supplied with the product. If the supplied drive file is corrupted, please visit the Samsung Electronics website (http://www.samsung.com/), and download the driver.

  • Page 52: Standard Signal Mode Table

    Standard Signal Mode Table An LCD monitor has one optimal resolution for the best visual quality depending on the screen size due to the inherent characteristics of the panel, unlike a CDT monitor. Therefore, the visual quality will be degraded if the optimal resolution is not set for the panel size. It is recommended setting the resolution to the optimal resolution of the product.
  • Page 53 RESOLUTION 720 x 240 720 x 480 720 x 480 720 x 576 1440 x 480 1440 x 576 1280 x 720 1280 x 720 1920 x 1080 1920 x 1080 1920 x 1080 1920 x 1080 1920 x 1080 1920 x 1080 1920 x 1080 1920 x 1080...

  • Page 54: Installing The Software

    What is Natural Color ? This software is for Samsung products only and enables you to adjust the displayed colors on the product so they more closely match the colors of printed pictures. For more information, refer to the online help of the software (F1).

  • Page 55: Multiscreen

    MultiScreen What is MultiScreen ? MultiScreen enables you to partition multiple sections on the Monitor. Installing the Software 1. Insert the installation CD into the CD-ROM drive. 2. Select the MultiScreen setup program. If the pop-up screen for the software installation does not appear on the main screen, find and double-click the MultiScreen setup file on the CD-ROM.

  • Page 56: Troubleshooting

    Troubleshooting Monitor Self-Diagnosis • You can check if the product is working properly using the Self-Diagnosis function. • If a blank screen is displayed and the Power LED blinks even if the product and the PC are properly connected, perform the self-diagnosis function according to the procedures below.

  • Page 57: Before Requesting Service

    Before Requesting Service Please check the following before requesting After-Sales service. If the problem continues, please contact your nearest Samsung Electronics Service Center. PROBLEMS RELATED TO INSTALLATION ( The monitor screen flickers. Screen is blank and power indicator is off.
  • Page 58 The remote control buttons do not respond. You may see small particles if you look closely at the edge of the bezel surrounding the screen. PROBLEMS RELATED TO REMOTE CONTROL Check the battery polarities (+/-). Check if the batteries have been exhausted. Check if the power is on.

  • Page 59: Faq

    How can I change the frequency of the video sig- nal? How can I change the resolution? How can I use the power saving function? How can I clean the outer case/LCD Panel? Can I watch digital TV broadcasting with an ana- log TV? Can I use my present antenna to receive digital broadcasting?

  • Page 60: More Information

    More Information Specifications MODEL NAME LCD Panel Screen Size Display Area Pixel Pitch Synchronization Horizontal Frequency Vertical Frequency Color Resolution Optimal Resolution Maximum Resolution Input Signal, when a terminator is installed. Maximum Pixel Clock Power Voltage Dimension (Width x Height x Depth) / Weight Tilt angle Environmental con- Operating...

  • Page 61: Power Saving Function

    Power Saving Function This product provides a power saving function that automatically turns the screen off when the product is not used for a predetermined period of time to reduce power consumption. If the product enters power saving mode, the power LED turns to a different color to indicate that the product is in power saving mode.

  • Page 62: Contact Samsung Worldwide

    Contact SAMSUNG WORLDWIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. U.S.A CANADA MEXICO ARGENTINA BRAZIL CHILE COLOMBIA COSTA RICA ECUADOR EL SALVADOR GUATEMALA HONDURAS JAMAICA NICARAGUA PANAMA PUERTO RICO REP.
  • Page 63 3 - SAMSUNG (7267864) 0 801 1SAMSUNG (172678) 022 - 607 - 93 - 33 808 20 - SAMSUNG (7267864) 0800-SAMSUNG(726-7864) 902 - 1 - SAMSUNG (902 172 678) 0771 726 7864 (SAMSUNG) 0848-SAMSUNG(7267864, CHF 0.08/ min) 0845 SAMSUNG (7267864)
  • Page 64 MALAYSIA NEW ZEALAND PHILIPPINES SINGAPORE THAILAND TAIWAN VIETNAM SOUTH AFRICA TURKEY U.A.E ASIA PACIFIC 1800-88-9999 0800 SAMSUNG (0800 726 786) 1-800-10-SAMSUNG(726-7864) 1-800-3-SAMSUNG(726-7864) 1-800-8-SAMSUNG(726-7864) 02-5805777 1800-SAMSUNG(726-7864) 1800-29-3232 02-689-3232 0800-329-999 1 800 588 889 MIDDLE EAST & AFRICA 0860-SAMSUNG(726-7864) 444 77 11...

  • Page 65: Correct Disposal

    Correct Disposal CORRECT DISPOSAL OF THIS PRODUCT (WASTE ELECTRICAL & ELECTRONIC EQUIPMENT) - EUROPE ONLY (Applicable in the European Union and other European countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g.
  • Page 66 More Information...
