Interactive Display
User Manual
WA65D WA75D WA86D
The color and the appearance may differ depending on the product, and the content in the
manual is subject to change without prior notice to improve the performance.
Recommended hours of use per day of this product is under 12 hours. If the product is used
for longer than 12 hours a day, the warranty may be void.
© Samsung
Samsung owns the copyright for this manual. Use or reproduction of this manual in parts or entirety without the authorization of Samsung is prohibited.
Trademarks other than Samsung are property of their respective owners.
Advertisement
Table of Contents
Related Manuals for Samsung WA75D
Summary of Contents for Samsung WA75D
- Page 1 12 hours a day, the warranty may be void. © Samsung Samsung owns the copyright for this manual. Use or reproduction of this manual in parts or entirety without the authorization of Samsung is prohibited. Trademarks other than Samsung are property of their respective owners.
-
Page 2: Table Of Contents
Table of contents Before using the product General Features Troubleshooting guide Safety precautions 4 Launcher 20 Problems and solutions 70 Safety symbols 4 Launcher menu 20 Storage 5 Editing the launcher 21 Electricity and safety 5 App drawer 22 Specifications Installation 5 Control Center... -
Page 3: Before Using The Product
Chapter 01 Before using the product Safety precautions CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN. The following safety instructions are to ensure your personal safety and prevent property CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). damage. -
Page 4: Storage
The product may become damaged by an electric shock. " Contact Customer Service Centre if the inside of the product needs cleaning (service fee Only use the power cord provided with your product by Samsung. Do not use the will be charged). -
Page 5: Operation
Then contact Samsung time) may seriously affect its performance. Customer Service Centre. Be sure to consult Samsung Customer Service Centre if you want to install the product at such a place. •... - Page 6 Be sure to power off the product and disconnect the power cord when water Leaving the screen fixed on a stationary image for an extended period of time may or other foreign substances have entered the product. Then contact Samsung cause afterimage burn-in or defective pixels.
-
Page 7: Precautions For Use
Precautions for use Be careful that if you use the supplied pen with a load exceeding 2.5 kg, scratches may occur on the protective glass. If you use a ballpoint pen other than the supplied pen, be careful that the screen may be stained with ink or damaged. -
Page 8: Preparations
Chapter 02 Preparations Checking the components $ Contact the vendor where you purchased the product if any Quick Setup Guide Warranty card Regulatory guide components are missing. (Not available in some locations) $ The appearance of the components may differ from the images shown. -
Page 9: Parts
" The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality. Parts Description WA65D/WA75D/WA86D Speaker Speaker output The pen is magnetic. Keep it by attaching to the marked location. -
Page 10: Ports
" The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality. Ports Description WA65D/WA75D/WA86D You can connect a device using a USB-C cable. • USB-C connection allows video output and touch-based control of the device. - Page 11 WA65D/WA75D/WA86D " The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality. Rear Ports Description RS232C Serial Interface for debug only. Connects to a network using a LAN cable. (1000 Mbps) RS232C •...
-
Page 12: Before Installing The Product (Installation Guide)
WA65D/WA75D/WA86D that the ambient temperature is kept below 35 °C. Ventilation " Contact Samsung Customer Service Center for further details. Installation on a perpendicular wall Minimum 30 mm Ambient temperature: 35 °C or less... -
Page 13: Installing The Wi-Fi Dongle (Model: Si07B)
We recommend you contact a technician for assistance when installing the wall mount bracket. • Samsung is not responsible for any damage to the product or injury to yourself or others if you select to install the wall mount on your own. •... -
Page 14: Wall Mount Kit Specifications (Vesa)
Samsung is not liable for these kinds of accidents. • Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is used or the consumer fails to follow the product installation instructions. -
Page 15: Connecting To A Network
Connecting to a network • Depending on how your network is configured, you may be able to attach your product to your LAN by connecting the LAN port on the back of your product directly to a network wall outlet using a LAN cable. "... - Page 16 Set the network connection to use Internet services such as perform software upgrades. How to set up manually Automatic Open Network Settings (Wired) Network Type Wired from the Open Network Settings page. The network connection screen appears, and the verification process starts. Connect to the network using a LAN cable.
-
Page 17: Network Settings (Wireless)
If you select the Pure High-throughput (Greenfield) 802.11n mode and the encryption The network connection screen appears, and the verification process starts. type is set to WEP, TKIP or TKIP AES (WPS2Mixed) on your AP or wireless router, Samsung When the connection has been verified, the... - Page 18 How to set up using the WPS button Right click the Network icon on the bottom right of the screen. In the pop-up menu that appears, click Status. If your router has a WPS button, follow these steps. On the dialog that appears, click the Support tab. Network Type Wireless from the...
-
Page 19: General Features
Launcher menu Long press and hold on a blank space on the home screen to call up the launcher menu. After finishing the setup wizard, you will be presented with the brand new Samsung OS EDLA " You can change Wallpaper &... -
Page 20: Editing The Launcher
Editing the launcher Customize the launcher to your needs by relocating the widgets and icons. • Create a new page by long pressing and dragging a widget or an icon to another page. • Remove an app icon or widget from the launcher by long pressing and dragging it to the Remove button. -
Page 21: App Drawer
App drawer Swipe up from anywhere on the home screen to bring up the drawer. • You can view and open any app installed on this device from here. • Navigate through all apps by scrolling the navigation bar on the right edge of the drawer. -
Page 22: Control Center
Control Center Swipe down from anywhere in the launcher to bring up the control & notification center. • You can change brightness and quickly adjust other controls by clicking on the tiles in the Control Center. • Some tiles also support expanded operations when you click on them. - Page 23 • Active apps to bring up the active apps page, where you can view all the apps that are active and running. Tap Stop to stop a running app. • Tap the Users icon to see all the users on this device. You can manage users by tapping the Manage users button on this page.
-
Page 24: Notification Center
Notification center All app notifications will be displayed in the notification center. • Click on a notification to enter the app interface. • You can also click the arrow in a notification to expand or collapse it. • Click the Manage button to enter notification settings. -
Page 25: System Navigation
System navigation WAD provides two types of system navigation methods. • 3-button navigation: always shows the navigation bar at the bottom of the screen with the Back/Home/Recent buttons inside it. • Gesture navigation: same as Android mobile phones, swipe from one of the screen edges to trigger Back/Home/Recent. -
Page 26: Writing
Chapter 04 Writing Note Opening Note Note on the home screen to open Note. " In Note, you can change pen/brush types, thickness and colors. -
Page 27: Writing
Writing Erasing Use the supplied pen to write on the display. Select Eraser the erase the written content with either end of the pen or your finger. You can use your palm to erase the content in a large area on the screen. You can also tap Clean •... -
Page 28: Note Menu
Note Menu Item Description Create a note. Open Open an existing note. Save Save the current note. Save as Save the current note in the desired format. Import Import a note in the IMG, PDF, SVG, or IWB format. Export Export a note in the IMG, PDF, SVG, or IWB format. -
Page 29: Settings
Settings Item Description Eraser mode Eraser mode to Eraser Erase selection. Swiping with multiple fingers allows you to write by using multiple Multi-finger writing fingers when this option is toggled on or drag the canvas when this option is toggled off. When this option is toggled on, the screen automatically dims when you write or Automatic brightness... - Page 30 Note Functions QR code-based sharing Note canvas list Tap the QR code to enlarge it.
- Page 31 Brush settings Ruler Select the ruler type to use. Adjust the eraser size. Selected ruler is activated for use. You can insert a 3D shape and preset its color.
- Page 32 Form Mind map A form is inserted as shown. The system automatically recognizes handwriting and generates potential text. After potential text is selected, the handwriting is automatically converted to a standard font. The cells in the form automatically adapt to the handwriting size. Write outside of a canvas (available after the zoom scale exceeds 100%).
- Page 33 Note • Selection: Different functions are available for different content. Below are examples. • Shape: After selecting a shape, you can change the frame/fill color of the shape and flip, pin to top, clone, or delete it. A note inserted as shown is placed automatically in the top right corner. •...
- Page 34 Pages Exit Page to view, select, or delete all pages that are added to the note. Tap Exit. You are prompted whether to save the note. You can save the note and exit or exit without saving.
-
Page 35: Entering Palette Exit
Palette Entering Palette Exit Palette in the list of all apps to open Palette. Palette's home screen shows Toolbox and ColorBox options by default for quick selection. -
Page 36: Ui Elements
UI Elements Item Description The menu allows you to perform operations such as saving, importing, sharing, The palette allows you to explore and use more artistic functions in your Menu and exiting. creation. Clear Tap to clear a canvas. Undo Undo the current operation. -
Page 37: Settings
Chapter 05 Settings Settings Entering Settings You can access Settings from the Control Center drawer. -
Page 38: System Settings
System Settings Item Description Network & Internet Manage network settings From system settings, various settings can be managed. Connected devices Connect to devices and change settings of connected devices Apps Check apps on this device and adjust app settings Notifications Manage system notification settings Storage Check device storage occupation and empty trash... -
Page 39: Network & Internet
Network & Internet You can manage all network settings in Network & Internet settings. Click on a connected network to see detailed information. Go to the Internet page to see all available networks. You can also tap the icon to add a network... - Page 40 Turn on Ethernet to enable ethernet connection. Change to static IP to configure ethernet manually. *Note: once ethernet is connected, all data will be transmitted via ethernet. You can change proxy settings under Proxy.
- Page 41 Turn on the Wi-Fi hotspot to share Internet from the IFP to other devices. You can change hotspot settings including security type and password.
- Page 42 Turn on Data Saver to prevent apps from using unrestricted data, to avoid data usage limits. You can configure the system VPN in VPN settings. Click the icon to add a configuration.
- Page 43 You can configure DNS settings on the Private DNS page.
- Page 44 Apps Manage app settings in Apps. Change general settings for apps under General. Select an app to view and change settings for that app.
- Page 45 Notifications You can manage app notifications and system notifications in Notifications. Manage Privacy settings to protect your personal privacy. Manage notifications for each app in settings. Manage general system notification settings in General.
- Page 46 Storage See the total/free space on your device and manage the storage space in Storage. Go to Free up space to check removable items and clear unused files. Turn on Storage Manager to allow auto clearing photos and videos regularly. View how much storage each type of file takes in the list.
- Page 47 Sound Adjust volume and change other audio settings in Sound. You can change other sound preference settings in the list. You can enable Live Caption by Google, which helps generate captions when speech is detected.
- Page 48 Display You can change display settings in Display. Decide when to turn off the device screen while inactive in Screen timeout. Choose what to show on the lock screen in Lock screen.
- Page 49 Change the system UI to dark mode by opening Dark theme. Change the display size and font size to suit your preferences. You can also set the schedule to turn on dark mode. Set screen saver type and activation timing in Screen Saver.
- Page 50 Set your favorite wallpaper in Wallpaper. You can also enable dark mode here. Themed icons is a beta feature by Google. When it is enabled, all Google apps will have the same color. You can set different wallpapers for the home screen and lock screen.
-
Page 51: Accessibility
Accessibility Manage all auxiliary functions for disabled users in Accessibility. Accessibility features from installed apps will be shown first. - Page 52 Security Manage all security settings in Security. You can also change screen lock timing and power button behavior by clicking the gear icon beside this setting item. Set system screen lock in Screen Lock. You can set different types of screen lock: swipe/pattern/PIN/password...
- Page 53 Check privacy usage and manage privacy settings in Privacy. Modify whether to show Notifications on the lock screen: View and manage all Google account autofill services. You can view all privacy You can view all privacy permissions in the Privacy dashboard.
- Page 54 Location See location information usage by apps and manage location permissions in Location. Apps You can manage how location information is obtained in Location services. using location recently will be shown first. You can also manage location permission for all apps.
- Page 55 Safety & emergency Check and manage personal information for medical and emergency uses in It supports setting up emergency SOS calls, crisis & earthquake alerts and wireless Safety & emergency. emergency alerts. Your device will play alerts when emergency broadcasts or messages are received.
- Page 56 Passwords & accounts You can manage all passwords and accounts registered on this device in Check accounts registered by apps or services on this device in Accounts for Owner. Passwords & accounts. Click Passwords to see all passwords stored on this device. Select an account to see detailed settings for that account.
- Page 57 Digital Wellbeing & parental controls Check device & app usage in Digital Wellbeing & parental controls. Set up device behavior to reduce interruptions by managing which notifications to show on screen and setting up Do Not Disturb mode or Heads Up notifications.
-
Page 58: Google
Google Once you have logged in to a Google account on your IFP, you can manage that Google account in detail under Google. - Page 59 Advanced All original Samsung settings are integrated into Advanced. Manage audio output channel and external source settings in Input & output. Set general information about this device, including basic system settings, in Check for system updates in update. System general.
- Page 60 Manage the device power schedule in Startup & shutdown. Manage advanced system display settings in Display.
- Page 61 Administrator Wake on LAN The administrator settings are used by device administrators to provide device control functions at a higher level. Wake on LAN is toggled on and the device is connected to a network cable, IFD can be To modify these settings, you need to specify an administrator password. Otherwise, all remotely turned on through through the network.
-
Page 62: Usb Clone
USB clone Default startup item USB clone function allows you to quickly export the system and on-screen display If the default startup item is specified, the corresponding app/web page/document is automatically launched after startup. (OSD) settings from one Interactive Display to another. The following options are supported: •... - Page 63 Auto Remove Files Set Auto Remove Files to prevent the Interactive Display from occupying a large amount of storage space. The storage period can be set to one of the following: None, 1 day, 7 days, or 30 days The following file types can be removed: •...
-
Page 64: System
System You can configure system language, input method and speech settings. You can change general system settings in System. Item Description English, French, German, Italian, Polish, Portuguese, Russian, Spanish, Swedish, Greek, Cheskry, Slovak, Hungarian, Finnish, Turkish, South Arabic Language, Hebrew, Chinese (Traditional/ Languages Simplified), Japanese, Korean, Romania, Croatia, Lithuania, Serbian, Latin, Norway, Denmark, Vietnam, Indonesia, Thailand,... - Page 65 Gestures Long press and hold the power button: set what happens when you long press and hold the power button. Change system navigation and modify what happens when you long press a button. • Default: the IFP is powered off. •...
-
Page 66: System Update
Backup System update After logging in to your Google account, you can manage backup services provided by Google. Click System update to check Google system and security patch updates. If any update is Click Backup to manage backup items and settings. available, it can be downloaded and installed from this menu. -
Page 67: Multiple Users
Multiple users Reset options You can add local users and guests in Multiple users. Reset system settings or erase all data by selecting different system reset options. The system will create an individual space for each user. Switching to a newly added user will require going through the setup wizard. - Page 68 About OSD menu view basic system information. OSD menu allows you to view and configure external signal sources, image display, and system sounds. Item Description You can open the OSD menu by using one of the following methods: • Third-party licenses Button on the sidebar: Legal Information •...
-
Page 69: Troubleshooting Guide
The blank spaces are not caused by the product. $ Test your product as follows before calling Samsung Customer Service when an HDMI cable is connected to the product and Blank spaces on the screen are caused by the PC or graphics card. To resolve the problem, Centre. - Page 70 Source window (HDMI) issue The brightness and color do not look normal. From the menu, select Menu → Brightness or Menu → Display → Color Temperature to try resetting the screen. The display looks unstable and then freezes. The screen may freeze when a resolution other than the recommended resolution is used or if the signal is not stable.
- Page 71 Sound issue There is no sound. Check the volume. The volume is too low. Adjust the volume. If the volume is still low after turning it up to the maximum level, adjust the volume on your PC sound card or software programme. Video is available but there is no sound.
- Page 72 Check whether the TOUCH port on the product is connected to a USB port on the PC using used. the supplied USB cable. • WA65D/WA75D/WA86D " HDMI 1 or 2 → TOUCH 1 on the rear of the product " HDMI 3 →...
- Page 73 HDMI-CEC issues HDMI-CEC does not work. Check if the device is an Anynet+ device. The Anynet+ system supports Anynet+ devices only. Check if the Anynet+ device power cord is properly connected. Check the Anynet+ device’s Video/Audio/HDMI cable connections. Check whether Anynet+ (HDMI-CEC) is set to Setting...
- Page 74 HDMI-CEC issues The connected device is not displayed. Check whether or not the device supports Anynet+ functions. Check whether or not the HDMI cable is properly connected. Check whether Anynet+ (HDMI-CEC) is set to Menu → SETTINGS → External Device Manager.
-
Page 75: Specifications
Chapter 07 Specifications General Model Name WA65D WA75D WA86D Panel Size 65 CLASS (64.5 inches / 163.9 cm) 75 CLASS (74.5 inches / 189.3cm) 86 CLASS (85.6 inches /217.4cm) Display area 1428.48 mm (H) x 803.52 mm (V) 1649.664 mm (H) x 927.936 mm 1895.04 mm (H) x 1065.96 mm (V) - Page 76 ****** is the product’s EPREL registration number. You can find the registration number on the rating label of your product. • Türkiye only To access the energy labelling information of the model: WA65D, WA75D, WA86D (1) Go to https://www.samsung.com/global/ecodesign_energy (2) Get the model identifier from the energy label of the product and type it in the search box...
-
Page 77: Preset Timing Modes
Preset timing modes clock Signal timing name Reference HDMI TypeC [MHz] [KHz] [Hz] 720*576P504:3 31.25 The screen will automatically be adjusted if a signal that belongs to the following standard 720*576P5016:9 31.25 signal modes is transmitted from your PC. If the signals transmitted from the PC differ from 1280*720P5016:9 74.25 37.5... -
Page 78: Appendix
" When the service is requested, in spite of in warranty, we may charge you for a visit from a service technician in the following cases. • Use of supplies or separately sold product unspecified by Samsung. • Repair from a person besides an engineer of outsourcing service company or partner of Not a product defect Samsung Electronics Co., Ltd. -
Page 79: Prevention Of Afterimage Burn-In
Open Source used in this product can be found on the following webpage pixels that control the liquid crystals. (https://opensource.samsung.com). Such a voltage difference between electrodes increases with time and makes the liquid crystals thinner. When this occurs, a previous image can remain on the screen when the pattern changes. -
Page 80: Low Blue Light
Low Blue Light ENERGY STAR Low Blue Light (software solution) filters out blue light to protect your eyes by adjusting how ENERGY STAR is a U.S. Environmental Protection Agency voluntary program that helps much blue light is shown: businesses and individuals save money and protect our climate through superior energy efficiency.
