  • Page 1 Enterprise WiFi System Model: UAP-Outdoor+...

  • Page 2: Installation Requirements

    This Quick Start Guide includes the warranty terms and is for use with the UniFi AP-HD, model UAP-HD. The UniFi AP can be powered by any of the following: • PoE Adapter (included) •...

  • Page 3: Package Contents

    Package Contents UniFi AP-HD Antennas (Qty. 2) Wall Mount Bracket Metal Strap M2.9x20 Screws M3x20 Screw (Qty. 3) Anchors (Qty. 3) Enterprise WiFi System Models: UAP-HD 48V, 0.5A Power Cord UniFi Controller CD Quick Start PoE Adapter with User Guide...

  • Page 4: Network Topology Requirements

    Network Topology Requirements • A DHCP-enabled network for the AP to obtain an IP address (wireless clients will also obtain IP addresses after deployment) • A management station computer running the UniFi Controller software, located either onsite and connected to WKH©VDPH©/D\HU ©QHWZRUN©RU©RIIõVLWH©LQ©D©FORXG©RU©12&...

  • Page 5: Hardware Overview

    Hardware Overview LED Color Status Initializing. Flashing White Factory default, waiting to be integrated. Steady White Device is busy; do not touch or unplug it. Alternating This usually indicates that a process such White/Blue as a firmware upgrade is taking place. This is used to locate an AP.
  • Page 6 The Main Ethernet port is used to connect the power and should be connected to the LAN and DHCP server. Power can be provided by any of the following: • Included PoE adapter • 48V, 802.3af compliant switch • Ubiquiti Networks TOUGHSwitch PRO, model TS-8-PRO...

  • Page 7: Hardware Installation

    Hardware Installation The UniFi AP can be mounted to a wall or on a pole. Perform the steps for the appropriate installation: Wall Mount To mount the AP on a wall, use the included Wall Mount Bracket, Screws, and Screw Anchors. 1.
  • Page 8 6. Align the mounting tabs on the UniFi AP with the notches on the Wall Mount Bracket, and slide the UniFi AP down until it locks into place.
  • Page 9 Pole Mount To mount the UniFi AP on a pole, use the included Metal Strap: 1. Turn the screw on the Metal Strap counter-clockwise to open the strap. 2. Straighten out the end of the Metal Strap and slide it through the back of the UniFi AP.
  • Page 10 3. Wrap the Metal Strap around the pole. Use a flathead screwdriver to turn the screw clockwise and securely fasten the strap to the pole.

  • Page 11: Antenna Installation

    Antenna Installation Connect each Antenna to a RP-SMA connector by rotating it clockwise.
  • Page 12 Powering the UniFi AP The UniFi AP can be powered by the included PoE Adapter or a compatible PoE switch. 1. Lift the locking tab of the Port Cover and slide the cover down to remove it. 2. Connect an Ethernet cable to the Main port.
  • Page 13 Connecting to the PoE Adapter 1. Connect the other end of the Ethernet cable to the Ethernet port labeled POE on the PoE Adapter. 2. Connect an Ethernet cable from your LAN to the Ethernet port labeled LAN on the PoE Adapter. 3.

  • Page 14: Software Installation

    Connect the other end of the Ethernet cable coming from the UniFi AP directly to a PoE port on one of the following: • 48V, 802.3af compliant switch • Ubiquiti Networks TOUGHSwitch PRO, model TS-8-PRO TOUGHSwitch PRO Power Connection Diagram Software Installation Insert the UniFi Controller software CD into your CD-ROM drive and follow the on-screen instructions.

  • Page 15: Specifications

    Specifications UAP-HD Dimensions 205 x 83 x 37 mm Weight 250 g Networking Interface (2) 10/100 Ethernet Ports Buttons Reset Antennas (2) 5 dBi Antennas Wi-Fi Standards 802.11 b/g/n (2.4 GHz) Power Method PoE 802.3.af Power Supply 48V, 0.5A PoE Adapter (Included) Power Save Supported Max.

  • Page 16: Safety Notices

    Safety Notices Read, follow, and keep these instructions. Heed all warnings. Only use attachments/accessories specified by the manufacturer. WARNING: Do not use this product in location that can be submerged by water. WARNING: Avoid using this product during an electrical storm.

  • Page 17: Limited Warranty

    (VI) has no original Ubiquiti MAC label, or is missing any other original Ubiquiti label(s); or (VII) has not been received by Ubiquiti within 30 days of issuance of the RMA.

  • Page 18: Limitation Of Liability

    SUBJECT TO LIMITATIONS, INTERRUPTIONS, DELAYS, CANCELLATIONS AND OTHER PROBLEMS INHERENT IN THE USE OF COMMUNICATIONS FACILITIES. UBIQUITI NETWORKS, ITS AFFILIATES AND ITS AND THEIR THIRD PARTY PROVIDERS ARE NOT RESPONSIBLE FOR ANY INTERRUPTIONS, DELAYS, CANCELLATIONS, DELIVERY FAILURES, DATA LOSS, CONTENT CORRUPTION, PACKET LOSS, OR OTHER DAMAGE RESULTING FROM ANY OF THE FOREGOING.
  • Page 19 Note Some countries, states and provinces do not allow exclusions of implied warranties or conditions, so the above exclusion may not apply to you. You may have other rights that vary from country to country, state to state, or province to province. Some countries, states and provinces do not allow the exclusion or limitation of liability for incidental or consequential damages, so the above limitation may not apply to you.

  • Page 20: Industry Canada

    Industry Canada This Class A digital apparatus complies with Canadian ICES-003. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that permitted for successful communication.
  • Page 21 RoHS/WEEE Compliance Statement English European Directive 2002/96/EC requires that the equipment bearing this symbol on the product and/or its packaging must not be disposed of with unsorted municipal waste. The symbol indicates that this product should be disposed of separately from regular household waste streams.

  • Page 22: Declaration Of Conformity

    UBIQUITI NETWORKS device, megfelel a vonatkozó alapvetõ [Hungarian] követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak. Íslenska Hér me l sir UBIQUITI NETWORKS yfir ví a UBIQUITI NETWORKS device, er í samræmi vi grunnkröfur og a rar kröfur, sem ger ar eru í [Icelandic] tilskipun 1999/5/EC.

  • Page 23: Online Resources

    NETWORKS device, è conforme ai requisiti essenziali ed alle altre [Italian] disposizioni pertinenti stabilite dalla direttiva 1999/5/CE. Latviski Ar o UBIQUITI NETWORKS deklar , ka UBIQUITI NETWORKS device, atbilst Direkt vas 1999/5/EK b tiskaj m pras b m un citiem ar to saist [Latvian] tajiem noteikumiem.

This manual is also suitable for:
