Chapter 12. Managing Disk Storage
Command
print
quit
rescuestart-mbend-mb
resize minor-numstart-mbend-mb
rm minor-num
select device
set minor-numflagstate
Table 12.1. parted commands

12.1.1. Viewing the Partition Table

After starting parted, type the following command to view the partition table:
print
A table similar to the following appears:
Disk geometry for /dev/sda: 0.000-8678.789 megabytes
Disk label type: msdos
Minor Start
1 0.031 101.975
2 101.975 5098.754
3 5098.755 6361.677
4 6361.677 8675.727
5 6361.708 7357.895
Disk geometry for /dev/hda: 0.000-9765.492 megabytes
Disk label type: msdos
Minor Start
1 0.031 101.975
2 101.975 611.850
3 611.851 760.891
4 760.891 9758.232
5 760.922 9758.232
The first line displays the size of the disk, the second line displays the disk label type, and the
remaining output shows the partition table.
In the partition table, the Minor number is the partition number. For example, the partition with minor
number 1 corresponds to /dev/sda1. The Start and End values are in megabytes. The Type is one
of primary, extended, or logical. The Filesystem is the file system type, which can be one of ext2,
ext3, fat16, fat32, hfs, jfs, linux-swap, ntfs, reiserfs, hp-ufs, sun-ufs, or xfs. The Flags column lists the
flags set for the partition. Available flags are boot, root, swap, hidden, raid, lvm, or lba.
In this example, minor number 1 refers to the /boot/ file system, minor number 2 refers to the root
file system (/), minor number 3 refers to the swap, and minor number 5 refers to the /home/ file
system.
110
End Type Filesystem
primary ext3
primary ext3
primary linux-swap
extended
logical ext3
End Type Filesystem
primary ext3
primary linux-swap
primary ext3
extended
logical ext3
Description
Display the partition table
Quit parted
Rescue a lost partition from start-mb to end-
mb
Resize the partition from start-mb to end-mb
Remove the partition
Select a different device to configure
Set the flag on a partition; state is either on or
off
Flags
boot
Flags
boot
lba
