- Page 1 RT520, RT520TX, RT520RF Quick Guide...
-
Page 2: Product Compliance
Introduction The RT520 and RT520RF are the latest additions to SALUS’ tried and tested RT range of thermostat heating controls. With a new on-board load compensation feature, they offer the most cost effective fully compliant Boiler Plus solution on the market providing the homeowner with optimum efficiency and maximum heating control comfort. -
Page 3: Button Functions
Button Functions RT520 / RT520RF Thermostat RXRT520 Receiver 7. ON - When in Manual Mode, ON will 1. MENU - enter the menu options, press and hold turn the boiler on. for 3 sec to return to main screen or to 8. - Page 4 RT520TX Wiring Diagram BOILER AC 230V RT520TX RXRT520 RXRT510 2 x AA PUMP AC 230V RT520TX RXRT520 RXRT510 2 x AA 16 (5) A OpenTherm Power Up and Configuration Please make the receiver connections and power the receiver before inserting the batteries into the thermostat.
- Page 5 In addition to an accurate and stable room temperature, the advantage of this system is the minimization of energy consumption and significant savings. RT520 offers 3 types of TPI controls: 1.for radiators (6CPH);...
- Page 6 When the OPTIMUM START function is active, the thermostat sends a heating signal to the heat source beforehand so that the preset temperature in the room is reached at the set time in the schedule. When the OPTIMUM STOP function is active, the thermostat, taking into account the inertia of the system, switches off the heat source earlier, keeping the temperature set in the schedule.
- Page 7 Programming - Automatic Mode The schedule has 6 time intervals for which different temperatures can be adjusted. You can set 2, 3 or up to 6 temperatures per day. You must define all time periods. Here is an example of setting a certain time with a certain temperature.
- Page 8 Landlord Settings Administrator settings is a function protected by a PIN code that allows the administrator to set a service reminder on the regulator that will warn the tenant about the upcoming boiler inspection. Using UP or DOWN, enter the Press button.
-
Page 9: Factory Reset
RT520TX Thermostat Pairing with the Receiver If you are using the RT520RF pack, the pairing between the thermostat and the receiver is already done. During the pairing process, please make sure the thermostat and the receiver are at least 1 meter from each other. - Page 10 New Territories, Hong Kong www.salus-controls.eu SALUS Controls is a member of the Computime Group. Maintaining a policy of continuous product development SALUS Controls plc reserve the right to change specification, design and materials of products listed in this brochure without prior notice.
