- Page 1 DS-K1T341A Series Face Recognition Terminal Quick Start Guide UD17592B...
- Page 2 Installation Installation Environment: Indoor and outdoor installation are supported. If installing the device indoors, the device should be at least 2 meters away from the light, and at least 3 meters away from the window or the door. If installing the device outdoors, you should apply Silicone sealant among the device to keep the raindrop from entering.
- Page 3 Appearance Loudspeaker microUSB Interface (Use micro USB to USB cable to connect with USB interface) Camera Camera Debugging Port 22.7 mm (For debugging only) 12.3 mm 83.2 mm White Light IR Light IR Light Installation Appearance Loudspeaker Installation Environment: Indoor and outdoor installation are supported. If installing the device indoors, the device should be at least 2 meters away from the light, and at microUSB Interface least 3 meters away from the window or the door.
- Page 4 When connecting door magnetic sensor and exit button, the device and the RS-485 card reader should use the common ground connection. The Wiegand termimal here is a Wiegand input terminal. You should set the face recognition terminal’s Wiegand direction to “Input”. If you connect to an access controller, you should set the Wiegand direction to “Output”.
- Page 5 Device Wiring (With Secure Door Control Unit) Face Recognition Terminal Secure Door Control Unit Power Input Black Door Contact Green/Brown SENSOR Sensor Input Black Secure Door Yellow Control Unit Exit Button Blue RS-485 Wiring Terminal Green/Black BUTTON Red/Black Exit Button Black White/Purple (NC)
- Page 6 Activation Power on and wire the network cable after installation. You should activate the device before the first login. Activate Device If the device is not activated yet, it will enter the Activate Device page after powering on. Enter 8 to 16 characters. Steps: 1.
- Page 7 Two-Way Audio After adding the device to the client software, you can call the device from the client software, call the client software from the device, call the center from the device, or call the indoor station from the device. Call Client Software from Device After adding the device on the client software, tap ->...
- Page 8 Add Face Picture 1. Use finger to hold the screen surface for 3 s and slide to right/left and enter the activation password to enter the Home page. 2. Enter the User Management page, tap + to enter the Add User page.
- Page 9 Tips When Collecting/ Comparing Face Picture Expression Keep your expression naturally when collecting or comparing face pictures, just like the expression in the picture on the right. Do not wear hat, sunglasses, or other accessories that can affect the facial recognition function. Do not make your hair cover your eyes, ears, etc.
- Page 10 Positions When Collecting/ Comparing Face Picture (Recommended Distance: 0.5m) Too High Recommended Height: 1.43m to 1.90m Too Low 1.4m 1.4m 0.5m 0.5m Too Far Too Close 1.4m 1.4m 0.5m 1.2m...
- Page 11 Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
- Page 12 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into Warnings and Cautions: Warnings: Neglecting any of the warnings may cause serious injury or death. Cautions: Neglecting any of the cautions may cause injury or equipment damage.
- Page 13 This Manual is subject to domestic and international copyright protection. Hangzhou Hikvision Digital Technology Co., Ltd. (“Hikvision”) reserves all rights to this manual. This manual cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
