Summary of Contents for HIKVISION DS-K11T341BMI-T

  • Page 1 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual...
  • Page 2 MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS...
  • Page 3 OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
  • Page 4 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual FCC Compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 5 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual licence. L’exploitation est autorisée aux deux conditions suivantes : • l’appareil ne doit pas produire de brouillage, et • l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
  • Page 6 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual case of some lithium battery types). • Do not dispose of the battery into fire or a hot oven, or mechanically crush or cut the battery, which may result in an explosion. • Do not leave the battery in an extremely high temperature surrounding environment, which may result in an explosion or the leakage of flammable liquid or gas.
  • Page 7 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual is not a malfunction however), and affecting the endurance of sensor at the same time. • Please use the provided glove when open up the device cover, avoid direct contact with the device cover, because the acidic sweat of the fingers may erode the surface coating of the device cover.

  • Page 8: Table Of Contents

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Contents Chapter 1 Overview ............................13 1.1 Overview ..............................13 1.2 Features ..............................13 Chapter 2 Appearance ..........................15 Chapter 3 Installation ........................... 16 3.1 Installation Environment ........................16 3.2 Wall Mounting ............................16 3.2.1 Flush Mounting ..........................
  • Page 9 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 6.4 User Management ..........................40 6.4.1 Add Administrator ........................40 6.4.2 Add Identity Picture ........................41 6.4.3 Add Card ............................43 6.4.4 Add Password..........................44 6.4.5 Set Authentication Mode ......................44 6.4.6 Search and Edit User ........................45 6.5 Temperature Measurement Settings .....................
  • Page 10 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 7.2.1 Add Device ........................... 63 7.2.2 Reset Device Password ........................ 70 7.3 Group Management ..........................71 7.3.1 Add Group ............................ 71 7.3.2 Import Resources to Group ......................71 7.3.3 Edit Resource Parameters ......................72 7.3.4 Remove Resources from Group ....................
  • Page 11 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 7.7.2 Configure Remaining Open/Closed ..................... 92 7.7.3 Configure Multi-Factor Authentication ..................93 7.7.4 Configure Custom Wiegand Rule ....................95 7.7.5 Configure Card Reader Authentication Mode and Schedule ............97 7.7.6 Configure First Person In ......................97 7.7.7 Configure Anti-Passback ......................
  • Page 12 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 7.12.6 Configure RS-485 Parameters ....................131 7.12.7 Security Mode Settings ......................132 7.12.8 Network Parameters Settings ....................132 7.12.9 Report Strategy Settings ......................132 7.12.10 Network Center Parameters Settings ..................133 7.12.11 Configure Wi-Fi ........................133 7.12.12 Set Access Control Parameters ....................

  • Page 13: Chapter 1 Overview

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Chapter 1 Overview 1.1 Overview The temperature screening terminal is a type of access control device integrated with a temperature screening function. It can quickly take skin-surface temperature and upload abnormal temperature events to the center, which can be widely applied in multiple scenarios such as enterprises, stations, dwellings, factories, schools, campuses, etc.
  • Page 14 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual • Watchdog design and tamper function • Audio prompt for authentication result • NTP, manually time synchronization, and auto synchronization • Connects to external access controller or Wiegand card reader via Wiegand protocol •...

  • Page 15: Chapter 2 Appearance

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Chapter 2 Appearance Refer to the following contents for detailed information of the temperature screening terminal: Figure 1, Temperature Screening Terminal Diagram Table 2-1 Description of Temperature Screening Terminal Description Card Presenting Area Display Screen Camera IR Light...

  • Page 16: Chapter 3 Installation

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Chapter 3 Installation 3.1 Installation Environment • Avoid backlight, direct sunlight, and indirect sunlight. • For better identity authentication, there should be light source in or near the installation environment. • Sunlight, wind, hot/cool air from air conditioner and other external factors, which may affect surface temperature, will create the deviation of the temperature measurement.
  • Page 17 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Figure 2, Install Gang Box 2. Use four supplied screws (KA4×22) to secure the mounting plate on the gang box. Figure 3, Secure Mounting Plate 3. Remove the back sheet of the device with tools to display the wiring terminals. 4.

  • Page 18: Surface Mounting

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Figure 4, Hang Device 6. Use the two screws at the bottom of the device to secure the device on the mounting plate. Figure 5, Secure Device 3.2.2 Surface Mounting NOTE: The additional force shall be equal to three times the weight of the equipment. The equipment ad its associated mounting means shall remain secure during the installation.
  • Page 19 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Figure 6, Mounting Template 2. Drill holes on the wall or other surface according to the Hole 2 on the mounting template. 3. Align the holes to the mounting plate and secure the mounting plate on the wall with the 4 supplied screws (KA4×22).

  • Page 20: Bracket Mounting

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Figure 8, Hang Device 7. Use the two screws at the bottom of the device to secure the device on the mounting plate. Figure 9, Secure Device 3.3 Bracket Mounting Before You Start •...
  • Page 21 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Figure 10, Secure Mounting Plate 2. Route the cable through the cable hole of the mounting plate and the bracket, and connect to corresponding external devices’ cables. 3. Use the two screws at the bottom of the device to secure the device on the mounting plate. Figure 11, Install Device UM DS-K1T341BM(W)I-T Touchless Identity Authentication Terminal 031221NA...
  • Page 22 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 4. Remove the bottom cover and the back cover by removing the screws (M3). Figure 12, Remove Bottom Cover and Back Cover 5. Route the cable through the cable hole of the bottom of the bracket, and connect to corresponding external devices’...
  • Page 23 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 8. Install the bottom cover and the back cover back on the bracket with screws. Figure 14, Install Cover Back UM DS-K1T341BM(W)I-T Touchless Identity Authentication Terminal 031221NA...

  • Page 24: Chapter 4 Wiring

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Chapter 4 Wiring The device supports connecting to the RS-485 terminal, the door lock, the exit button, the alarm output/input devices, the Wiegand card reader, the access controller, and the power supply. You can wire the peripherals according to the descriptions below.

  • Page 25: Wire Secure Door Control Unit

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Figure 15, Device Wiring NOTE: You should set the temperature screening terminal’s Wiegand direction as Input to connect to a Wiegand card reader. If connects to an access controller, you should set the Wiegand direction as Output to transmit authentication information to the access controller.

  • Page 26: Wire Fire Module

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Figure 17, Secure Door Control Unit Wiring NOTE: The secure door control unit should connect to an external power supply separately. The suggested external power supply is 12V, 0.5A. 4.4 Wire Fire Module 4.4.1 Wiring Diagram of Door Open When Powering Off •...

  • Page 27: Wiring Diagram Of Door Locked When Powering Off

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Figure 19, Wire Secure Door Control Unit Type 2 NOTE: The fire system (NO and COM, normally open when powering off) is connected with the lock and the power supply in series. When an fire alarm is triggered, the door remains open. In normal times, NO and COM are closed.
  • Page 28 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual • Security Type: Door Locked When Powering Off • Scenario: Installed in Entrance/Exit with Fire Linkage NOTE: An Uninterpretable Power Supply (UPS) is required. The fire system (NC and COM, normally closed when powering off) is connected with the lock and the power supply in series.

  • Page 29: Chapter 5 Activation

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Chapter 5 Activation You should activate the device before the first login. After powering on the device, the system will switch to Device Activation page. Activation via the device, SADP tool and the client software are supported. The default values of the device are as follows: •...

  • Page 30: Activate Via Web Browser

    SADP is a tool to detect, activate and modify the IP address of the device over the LAN. Before You Start • Get the SADP software from the supplied disk or the official Website http://www.hikvision.com/en/, and install the SADP according to the prompts. UM DS-K1T341BM(W)I-T Touchless Identity Authentication Terminal 031221NA...
  • Page 31 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual • The device and the PC that runs the SADP tool should be within the same subnet. The following steps show how to activate a device and modify its IP address. For batch activation and IP addresses modification, refer to User Manual of SADP for details.

  • Page 32: Activate Device Via Client Software

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 5.4 Activate Device via Client Software For some devices, you are required to create the password to activate them before they can be added to the software and work properly. NOTE: This function should be supported by the device. 1.

  • Page 33: Chapter 6 Basic Operation

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Chapter 6 Basic Operation 6.1 Set Application Mode After activating the device, you should select an application mode for better device application. 1. On the Welcome page, select Indoor or Others from the drop-down list. Figure 26, Welcome Page 2.

  • Page 34: Login

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual application mode by default. 6.2 Login Login the device to set the device basic parameters. You should enter the device activation password for the first login. Or if you have add the administrator’s credential, you can login via the configured credential. 6.2.1 First Time Login You should login the system before other device operations.

  • Page 35: Log In By Administrator

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 6.2.2 Log in by Administrator After you add the administrator for the device, only the administrator can log in to the device for device operation. 1. Long tap on the initial page for 3 s to enter the admin login page. Figure 28, Admin Login 2.

  • Page 36: Communication Settings

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Figure 29, Home Page NOTE: The device will lock for 30 minutes after five failed identity or card attempts. 3. (Optional): Tap and you can enter the device activation password for login. 4. (Optional): Tap and you can exit the admin login page.

  • Page 37: Set Wi-Fi Parameters

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Figure 30, Network Settings 3. Set the device network information. • If the DHCP function is enabled, the system will allocate an IP address, subnet mask, and gateway automatically. • If the DHCP function is not enabled, you should set the device IP address, subnet mask, and gateway. 4.

  • Page 38: Set Rs-485 Parameters

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Figure 31, Wi-Fi Settings 3. Enable the Wi-Fi function. 4. Select a Wi-Fi in the list to enter the Wi-Fi parameters settings page. 5. Select an IP mode. If selecting DHCP, you should input the Wi-Fi password.If selecting Static, you should input the Wi-Fi password, IP address, subnet mask and gateway.

  • Page 39: Set Wiegand Parameters

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 1. Tap Comm. (Communication Settings) on the Home page to enter the Communication Settings page. 2. On the Communication Settings page, tap RS-485 to enter the RS-485 tab. Figure 32, Set RS-485 Parameters 3.

  • Page 40: User Management

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Figure 33, Wiegand Settings 3. Enable the Wiegand function. 4. Select a transmission direction. • Output: A temperature screening terminal can connect an external access controller. And the two devices will transmit the card No. via Wiegand 26 or Wiegand 34. •...

  • Page 41: Add Identity Picture

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual NOTE: Numbers, upper case letters, lower case letters, and special characters are allowed in the user name. Up to 32 characters are allowed in the user name. 5. (Optional): Add an identity picture, cards, or password for the administrator. NOTE: For details about adding an identity picture, see Add Identity Picture.
  • Page 42 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Figure 34, Add Identity Picture 6. Position your face looking at the camera. NOTE: Make sure your identity picture is in the identity picture outline when adding the identity picture. Make sure the captured identity picture is in good quality and is accurate. For details about the instructions of adding identity pictures, see Tips When Collecting/Comparing identity Picture.

  • Page 43: Add Card

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 9. Enable or disable the Administrator Permission function. • Enable Administrator Permission – The user is the administrator. Except for the normal attendance function, the user can also enter the Home page to operate after authenticating the permission. •...

  • Page 44: Add Password

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 8. Tap to save the settings. 6.4.4 Add Password Add a password for the user and the user can authenticate via the password. 1. Long tap on the initial page and login. 2. Tap User → + to enter the Add User page. 3.

  • Page 45: Search And Edit User

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Control Settings page. For details see Setting Access Control Parameters. • Custom – You can combine different authentication modes together according to your actual needs. 4. Tap to save the settings. 6.4.6 Search and Edit User After adding the user, you can search for and edit the user.

  • Page 46: Identity Authentication

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual The available parameters’ descriptions are as follows: Table 6-1 Temperature Measurement Parameters Descriptions Parameter Description When enabling the function, the device will authenticate the permissions Enable Temperature and at the same time take the temperature. When disabling the device, the Detection device will authenticate the permissions only.

  • Page 47: Authenticate Via Single Credential

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual NOTE: For detailed information about scanning fingerprint, see Tips for Scanning Fingerprint. For detailed information about authenticating identity, see Tips When Collecting/Comparing Identity Picture. If authentication succeeds, an “Authenticated” prompt will pop up. 6.6.2 Authenticate via Single Credential Set the user authentication type before authentication.

  • Page 48: Set Identity Picture Parameters

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Figure 36, Basic Parameters Table 6-2 Basic Parameters Parameter Description Community No. Set the device installed community No. Building No. Set the device installed building No. Unit No. Set the device installed Unit No. Voice Prompt to disable or enable the voice prompt.
  • Page 49 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Figure 37, Identity Picture Parameters Table 6-3 Identity Picture Parameters Parameter Description Set the matching threshold when authenticating via 1:N matching mode. The 1:N Security Level larger the value, the smaller the false accept rate and the larger the false rejection rate.

  • Page 50: Set Time

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Parameter Description By default, the resolution is 70. After the function is enabled, when a person authenticates the permissions on Face with Mask the authentication page, the device can recognize the identity whether wearing Detection a mask or not, and prompts to wear a mask according to the configuration.

  • Page 51: Set Access Control Parameters

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Figure 38, Time Parameters 6.8 Set Access Control Parameters You can set the access control permissions, including the functions of authentication mode, door contact, and lock locked time. On the Home page, tap ACS (Access Control Settings) to enter the Access Control Settings page. Edit the access control parameters on this page and tap to save the settings.

  • Page 52: Maintenance

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual The available parameters descriptions are as follows: Table 6-4 Access Control Parameters Descriptions Parameter Description Select the temperature screening terminal’s authentication mode. You can also customize the authentication mode. NOTE: Biometric recognition products are not 100% applicable to anti-spoofing environments.

  • Page 53: Log Query

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Tap Data (Data Management) to enter the Data Management page. Tap the button on the page to manage the data. Tap Yes on the pop-up window to complete the settings. Figure 41, Data Management The available button descriptions are as follows: Table 6-5 Data Descriptions Parameters...

  • Page 54: Time And Attendance Status Settings

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Figure 42, Log Query 2. Tap Card on the left of the page and select a search type from the drop-down list. 3. Tap the input box and input the employee ID, the card No., or the user name for search. 4.

  • Page 55: Disable Attendance Mode Via Device

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual NOTE: The function should be used cooperatively with time and attendance function on the client software. 6.10.1 Disable Attendance Mode via Device Disable the attendance mode and the system will not display the attendance status on the initial page. Tap T&A Status to enter the T&A Status page.
  • Page 56 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Figure 44, Auto Attendance Mode 3. Select an attendance status and set its schedule. 1) Select Check In, Check Out, Break Out, Break In, Overtime In, or Overtime Out as the attendance status. 2) Tap Schedule.

  • Page 57: Set Manual Attendance Via Device

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Result When you authenticate on the initial page, the authentication will be marked as the configured attendance status according to the configured schedule. Example: If the Break Out Schedule is set as Monday 11:00, and the Break In Schedule is set as Monday 12:00, the valid user’s authentication from Monday 11:00 to 12:00 will be marked as a break.
  • Page 58 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 2. Set the Attendance Mode as Manual and Auto. Figure 46, Manual and Auto Mode 3. Select an attendance status and set its schedule. 1) Select Check In, Check Out, Break Out, Break In, Overtime In, or Overtime Out as the attendance status.

  • Page 59: View System Information

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Result On the initial page and authenticate. If you do not select a status, the authentication will be marked as the configured attendance status according to the schedule. If you tap Select Status and select a status to take attendance, the authentication will be marked as the selected attendance status.

  • Page 60: Video Intercom

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual • View Device Information – You can view the device information. 1. Tap Info. (System Information) → Device to enter the Device page. NOTE: Some device models do not support displaying the fingerprint information. •...

  • Page 61: Call Device From Client Software

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 2. Run the client software and the control panel of the software pops up. 3. Click Device Management to enter the Device Management interface. 4. Add the main station and the device to the client software. NOTE: For details about adding device, see Add Device.
  • Page 62 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 5. Link a user to an indoor station and set a room No. for the indoor station. 6. Tap on the authentication page of the device. Enter the room No. on the dial page and tap to call the room.

  • Page 63: Chapter 7 Client Software Configuration

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Chapter 7 Client Software Configuration 7.1 Configuration Flow of Client Software Follow the flow diagram below to configure on the client software. Figure 48, Flow Diagram of Configuration on Client Software 7.2 Device Management The client supports managing access control devices and video intercom devices.
  • Page 64 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Add a Detected Online Device You can select a detected online device displayed in the online device list and add it to the client. 1. Enter the Device Management module. 2. Click Device tab on the top of the right panel. 3.
  • Page 65 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual device to the client. 8. (Optional): Check Import to Group to create a group by the device name, and import all the channels of the device to this group. Example: For access control device, its access points, alarm inputs/outputs, and encoding channels (if exist) will be imported to this group.
  • Page 66 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 8. (Optional): Check Import to Group to create a group by the device name, and import all the channels of the device to this group. Example: For access control device, its access points, alarm inputs/outputs, and encoding channels (if exist) will be imported to this group.
  • Page 67 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual You can log into the device to get the certificate file by Web browser. 6. Check Synchronize Time to synchronize the device time with the PC running the client after adding the device to the client. 7.
  • Page 68 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 6. (Optional): Check Transmission Encryption (TLS) to enable transmission encryption using TLS (Transport Layer Security) protocol for security purpose . NOTE: This function should be supported by the device. If you have enabled Certificate Verification, you should click Open Certificate Folder to open the default folder, and copy the certificate file exported from the device to this default directory to strengthen the security.
  • Page 69 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual • Click Add to add the device and go back to the device list. • Click Add and New to save the settings and continue to add other device. NOTE: Identity pictures cannot be applied to devices added by ISUP account except DS-K1T671 series and DS-K1T331 series.

  • Page 70: Reset Device Password

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual STRONG PASSWORD RECOMMENDED − The password strength of the device can be automatically checked. We highly recommend that you create a strong password of your own choosing (using a minimum of eight characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.

  • Page 71: Group Management

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 7.3 Group Management The client provides groups to manage the added resources in different groups. You can group the resources into different groups according to the resources’ locations. Example: For example, on the 1st floor, there mounted 16 doors, 64 alarm inputs, and 16 alarm outputs.

  • Page 72: Edit Resource Parameters

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 7.3.3 Edit Resource Parameters After importing the resources to the group, you can edit the resource parameters. For access point, you can edit the access point name. For alarm input, you can edit the alarm input name. Here we take access point as an example.

  • Page 73: Configure Basic Information

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 3. Create a name for the added organization. NOTE: Up to 10 levels of organizations can be added. 4. (Optional): Perform the following operation(s). • Edit Organization – Hover the mouse on an added organization and click to edit its name.
  • Page 74 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual NOTE: Enter the person’s basic information first. For details about configuring person’s basic information, refer to Configure Basic Information. 3. In the Credential → Card area, click +. 4. Click Settings to enter the Settings page. 5.

  • Page 75: Upload An Identity Photo From Local Pc

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual the sector of the card to encrypt. 7. Click OK to confirm the operation. 8. Place the card on the card enrollment station, and click Read to get the card number. The card number will display in the Card No.

  • Page 76: Collect Identity Via Access Control Device

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 3. Click Add Face in the Basic Information panel. 4. Select Take Photo. 5. Connect the identity scanner to the PC running the client. 6. (Optional): Enable Verify by Device to check whether the identity authentication device managed in the client can recognize the identity in the photo.

  • Page 77: Configure Access Control Information

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 7. Confirm to add the person. • Click Add to add the person and close the Add Person window. • Click Add and New to add the person and continue to add other persons . 7.4.7 Configure Access Control Information When adding a person, you can set her/his access control properties, such as setting the person as a visitor or a blocklist person, or as a super user who has super authorization.

  • Page 78: Customize Person Information

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual • Click Add to add the person and close the Add Person window. • Click Add and New to add the person and continue to add other persons. 7.4.8 Customize Person Information You can customize the person properties which are not pre-defined in the client according to actual needs, e.g., place of birth.

  • Page 79: Configure Additional Information

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 4. Enter the floor No. and room No. of the person. 5. Confirm to add the person. • Click Add to add the person and close the Add Person window. • Click Add and New to add the person and continue to add other persons. 7.4.10 Configure Additional Information When adding person, you can configure the additional information for the person, such as person’s identity type, identity No., country, etc., according to actual needs.

  • Page 80: Import Person Pictures

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual NOTE: If the person has multiple cards, separate the card No. with semicolon. Items with asterisk are required. By default, the Hire Date is the current date. 7. Click to select the CSV file with person information. 8.

  • Page 81: Export Person Pictures

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 1. Enter the Person module. 2. (Optional): Select an organization in the list. NOTE: All persons’ information will be exported if you do not select any organization. 3. Click Export to open the Export panel and check Person Information as the content to export. 4.

  • Page 82: Move Persons To Another Organization

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 3. Click Get from Device. 4. Select an added access control device or the enrollment station from the drop-down list. NOTE: If you select the enrollment station, you should click Login, and set IP address, port No., user name and password of the device.

  • Page 83: Report Card Loss

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 6. Click the Card No. column and enter the card number. • Place the card on the card enrollment station. • Swipe the card on the card reader. • Manually enter the card number and press the Enter key. The person(s) in the list will be issued with card(s).

  • Page 84: Configure Schedule And Template

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual • Card Type – This field is available only when the model is DS-K1F100-D8E or DS-K1F180-D8E. Select the card type as EM card or IC card according to the actual card type. • Serial Port –...

  • Page 85: Add Template

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual NOTE: Up to 8 time durations can be set to one holiday period. 3) (Optional): Perform the following operations to edit the time durations. • Move the cursor to the time duration and drag the time duration on the timeline bar to the desired position when the cursor turns to •...

  • Page 86: Set Access Group To Assign Access Authorization To Persons

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual • Move the cursor to the time duration and drag the time duration on the timeline bar to the desired position when the cursor turns to • Click the time duration and directly edit the start/end time in the appeared dialog. •...
  • Page 87 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual persons to access. 7. Click Save. You can view the selected person(s) and the selected access point(s) on the right side of the interface. Figure 50, Display the Selected Person(s) and Access Point(s) 8.

  • Page 88: Configure Advanced Functions

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual You can click the prompt to apply the changed data to the device. You can select either Apply Now or Apply Later. Figure 51, Data Synchronization 7.7 Configure Advanced Functions You can configure the advanced functions of access control to meet some special requirements in different scene.
  • Page 89 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual • Voice Prompt – If you enable this function, the voice prompt is enabled in the device. You can hear the voice prompt when operating in the device. • Upload Pic. After Linked Capture – Upload the pictures captured by linked camera to the system automatically.
  • Page 90 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual • Door Contact – You can set the door sensor as remaining closed or remaining open. Usually, it is remaining closed. • Exit Button Type – You can set the exit button as remaining closed or remaining open. Usually, it is remaining open.
  • Page 91 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual • Basic Information ­ Name – Edit the card reader name as desired. ­ Minimum Card Swiping Interval – If the interval between card swiping of the same card is less than the set value, the card swiping is invalid. You can set it as 0 to 255. ­...

  • Page 92: Configure Remaining Open/Closed

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual ­ Liveness Detection Security Level – After enabling Live Identity Detection function, you can set the matching security level when performing live identity authentication. 4. Click OK. 5. (Optional): Click Copy to, and then select the card reader(s) to copy the parameters in the page to the selected card reader(s).

  • Page 93: Configure Multi-Factor Authentication

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 1) Click Remain Open or Remain Closed. 2) Click Add. 3) Enter the start date and end date. 4) Drag the cursor to draw the time duration, which means in that duration of time, the configured access group is activated.
  • Page 94 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 3) Specify the start time and end time of the effective period for the person/card group. 4) Select members(s) and card(s) in the Available list, and the selected member(s) and card(s) will be added to the Selected list.

  • Page 95: Configure Custom Wiegand Rule

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual • Local Authentication and Super Password – Authentication by the access control device and by the super password. 4) Select the added person/card group in the left list below and it will be added to the Selected list on the right as the authentication group.
  • Page 96 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 5. Set the parity mode according to the property of the third party card reader. NOTE: Up to 80 bits are allowed in the total length. The odd parity start bit, the odd parity length, the even parity start bit and the even parity length range from 1 to 80 bit.

  • Page 97: Configure Card Reader Authentication Mode And Schedule

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 7.7.5 Configure Card Reader Authentication Mode and Schedule You can set the passing rules for the card reader of the access control device according to your actual needs. Perform this task if you need to configure the card reader’s authentication mode and schedule. 1.

  • Page 98: Configure Anti-Passback

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 1. Click Access Control → Advanced Function → First Person In to enter the First Person In page. 2. Select an access control device in the list on the left panel. 3. Select the current mode as Enable Remaining Open after First Person or Disable Remaining Open after First Person from the drop-down list for each access control point of the selected device.

  • Page 99: Configure Device Parameters

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 5. Select the afterward card readers for the first card reader. NOTE: Up to four afterward card readers can be added as afterward card readers for one card reader. 6. Click OK in the dialog to save the selections. 7.
  • Page 100 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 2. On the navigation bar on the left, enter Advanced Function → More Parameters. 3. Select an access control device in the device list and enter Network → Uploading Mode. 4. Select the center group from the drop-down list. 5.
  • Page 101 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual triggered capture. NOTE: The capture function should be supported by the device. Before setting the capture parameters, you should set the picture storage first to define where the event triggered pictures are saved. For details, refer to Set Picture Storage in the user manual of the client software.
  • Page 102 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 5. Select the picture quality as High, Medium, or Low. The higher the picture quality is, the larger size the picture will be. 6. Click Save. Set Parameters for Temperature Screening Terminal For temperature screening terminal, you can set its parameters. NOTE: This function should be supported by the device.
  • Page 103 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual By default, Sector 13 is encrypted. It is recommended to encrypt sector 13. 6. Click Save to save the settings. Set RS-485 Parameters You can set the access control device’s RS-485 parameters including the baud rate, data bit, the stop bit, parity type, flow control type, communication mode, work mode, and connection mode.

  • Page 104: Configure Linkage Actions For Access Control

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 7. Click Save. • The configured parameters will be applied to the device automatically. • After changing the communication direction, the device will reboot automatically. 7.8 Configure Linkage Actions for Access Control You can configure different linkage actions for the event detected by the access control device. After that, linkage actions will be triggered once the event happens.

  • Page 105: Configure Device Actions For Access Event

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual NOTE: For details about setting e-mail parameters, refer to Set Email Parameters in the user manual of client software. 2) Click OK. 5. Enable the event so that when the event is detected, en event will be sent to the client and the linkage actions will be triggered.

  • Page 106: Configure Device Actions For Person Id

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual NOTE: It should be supported by the device. 1. Click Access Control → Linkage Configuration. 2. Select the access control device from the list on the left. 3. Click Add button to add a new linkage. 4.

  • Page 107: Door Control

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 7. In the Linkage Target area, set the property target to enable this action. • Buzzer on Controller – The audible warning of access control device will be triggered. • Buzzer on Reader – The audible warning of card reader will be triggered. •...

  • Page 108: Check Real-Time Access Records

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual • Open Door – When the door is locked, unlock it and it will be open for once. After the open duration, the door will be closed and locked again automatically. • Close Door – When the door is unlocked, lock it and it will be closed. The person who has the access authorization can access the door with credentials.

  • Page 109: Enable Receiving Event From Devices

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Before the client can receive the event information from the device, you need to enable the events of the resource and arm the device first. For details, refer to Enable Receiving Event from Devices. 7.10.1 Enable Receiving Event from Devices Before the client software can receive event notifications from the device, you need to arm the device first.

  • Page 110: Search Historical Events

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual displayed in the event list. 4. View the event details. 1) Select an event in the event list. 2) Click Expand in the right-lower corner of the page. 3) View the detail description and handing records of the event. 5.
  • Page 111 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual > Include Sub-Node: Search the events of the device and all resource channels. > Device Type: The device type which events you want to search. ­ Group – Search the events by resource channels in the group. NOTE: For video intercom device, you need to select searching scope: All and Locking Log.

  • Page 112: Time And Attendance

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual NOTE: You should configure the e-mail parameters first. • Export Event Information – Click Export to export the event log or event pictures to the local PC in CSV format. You can set the saving path manually. •...
  • Page 113 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual • Work Hour Rate – Work Hour Rate is used to calculate work hours by multiplying it by overtime. When you work for a certain period after end-work time on workday, you will reach different overtime level. You can set different work hour rates (1-10, can be a decimal) for three overtime levels.
  • Page 114 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 7. Set the attendance status if the employee works on holiday. 8. (Optional): Check Repeat Annually to make this holiday setting effective every year. 9. Click OK. The added holiday will display in the holiday list and calendar. NOTE: If the date is selected as different holidays, it will be recorded as the first-added holiday.
  • Page 115 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual also edit or delete the leave type. 1. Enter the Time & Attendance module. 2. Click Attendance Settings → Leave Type to enter the Leave Type Settings page. 3. Click Add on the left to add a major leave type. 4.
  • Page 116 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual reconnection every 30 mins. After being reconnected, the client will synchronize the data recorded during the disconnected time period to the third-party database. Configure Break Time You can add break time and set start time, end time, duration, calculation mode and other parameters for the break.

  • Page 117: Add General Timetable

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 3. Set the display settings for attendance report. • Company Name – Enter a company name to display the name in the report. • Attendance Status Mark – Enter the mark and select the color. The related fields of attendance status in the report will display with the mark and color.

  • Page 118: Add Shift

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 5. Select calculation method. • First In & Last Out – The first check-in time is recorded as start work time and the last check-out time is recorded as the end-work time. • Each Check-In/Out –...
  • Page 119 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual You can add shift for employees including setting shift period (day, week, month) and the effective attendance time. According to the actual requirements, you can adding multiple timetables in one shift for employees, which requires them to check in and check out for each timetable.

  • Page 120: Manage Shift Schedule

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Figure 57, Add Multiple Timetables 6. Click Save. The added shift lists on the left panel of the page. At most 64 shifts can be added. 7. (Optional): Assign the shift to organization or person for a quick shift schedule. 1) Click Assign.
  • Page 121 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual The practice typically sees the day divided into shifts, set periods of time during which different shifts perform their duties. You can set department schedule, person schedule, and temporary schedule. Set Department Schedule You can set the shift schedule for one department, and all the persons in the department will be assigned with the shift schedule.
  • Page 122 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Set Person Schedule You can assign the shift schedule to one or more persons. You can also view and edit the person schedule details. Before You Start Add department and person in Person module. See Person Management for details. NOTE: The person schedule has the higher priority than department schedule.

  • Page 123: Manually Correct Check-In/Out Record

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual NOTE: The temporary schedule has higher priority than department schedule and person schedule. 1. Click Time & Attendance → Shift Schedule to enter the Shift Schedule Management page. 2. Click Temporary Schedule to enter Temporary Schedule page. 3.

  • Page 124: Add Leave And Business Trip

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Before You Start • You should add organizations and persons in Person module. For details, refer to Person Management. • The person’s attendance status is incorrect. 1. Click Time & Attendance → Attendance Handling to enter attendance handling page. 2.

  • Page 125: Calculate Attendance Data

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 2. Click Apply for Leave/Business Trip to enter adding the leave/business trip page. 3. Select person from left list. 4. Set the date(s) for your leave or business trip. 5. Select the major leave type and minor leave type from the drop-down list. NOTE: You can set the leave type in Attendance Settings.

  • Page 126: Attendance Statistics

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 4. Click Save. The client will calculate the attendance data of the previous day from the time you have configured. Manually Calculate Attendance Data You can calculate the attendance data manually by setting the data range. 1.
  • Page 127 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual manually. For details, refer to Manually Calculate Attendance Data. 1. Enter the Time & Attendance module. 2. Click Attendance Statistics → Attendance Record. 3. Set the attendance start time and end time that you want to search. 4.
  • Page 128 DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual automatically to the email address you configured. NOTE: Set the email parameters before you want to enable auto-sending email functions. For details, refer to Set Email Parameters in the user manual of the client software. 1.

  • Page 129: Remote Configuration (Web)

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual • Generate Report – Select one added report and click Report to generate the report instantly and you can view the report details. 7.12 Remote Configuration (Web) Configure device parameters remotely. 7.12.1 View Device Information View and set device name, view device type, serial No., version, lock number, and local RS-485 number.

  • Page 130: Time Management

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 4. Click OK. Result The device password is changed. You should enter the new password on the Device for Management page to reconnect the device. 7.12.4 Time Management Manage device’s time zone, time synchronization, and DST parameters. Time Zone and Time Synchronization 1.

  • Page 131: Configure Rs-485 Parameters

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual Restore Settings 1. On the Device for Management page, click Remote Configuration → System → System Maintenance to enter the System Maintenance tab. • Restore Default – The parameters will be restored the default ones, excluding the IP address. •...

  • Page 132: Security Mode Settings

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 4. Select the serial No. of the port from the drop-down list to set the RS-485 parameters. 5. Set the baud rate, data bit, the stop bit, parity, flow control, communication mode, working mode, and the connection mode from the drop-down list.

  • Page 133: Network Center Parameters Settings

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual settings. • Center Group – Select a center group from the drop-down list. • Main Channel – The device will communicate with the center via the main channel. NOTE: N1 refers to wired network. 7.12.10 Network Center Parameters Settings You can set the notify surveillance center, center’s IP address, the port No., the protocol (EHome), the EHome account user name,etc.

  • Page 134: Set Temperature Screening Terminal Parameters

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual You can hear the voice prompt when operating in the device. • Upload Pictures after Capturing – If you enable this function, the captured pictures will be sent to the client software. • Save Captured Pictures –...

  • Page 135: Configure Identity Picture Parameters

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual • ECO Mode (1:N) – Set the matching threshold when authenticating via ECO mode 1:N matching mode. The larger the value, the smaller the false accept rate and the larger the false rejection rate. •...

  • Page 136: Configure Supplement Light Parameters

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual 4. Click Save. 7.12.15 Configure Supplement Light Parameters You can turn on or off the supplement light. You can also adjust the supplement light brightness. 1. Click Maintenance and Management → Device to enter the device list. 2.

  • Page 137: Tips For Scanning Fingerprint

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual A. Tips for Scanning Fingerprint • Recommended Finger – Forefinger, middle finger or third finger. • Correct Scanning – The figure displayed below is the correct way to scan your finger. You should press your finger on the scanner horizontally.

  • Page 138: Tips When Collecting/Comparing Identity Picture

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual B. Tips When Collecting/Comparing Identity Picture The position when collecting or comparing identity picture is as below: • Positions – Recommended distance: 1 ft 7 in (0.5 m) • Expression ­ Keep your expression naturally when collecting or comparing identity pictures, just like the expression in the picture below.

  • Page 139: Tips For Installation Environment

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual C. Tips for Installation Environment • Light Source Illumination Reference Value Candle: 10 lux Bulb: 100 to 850 lux Sunlight: More than 1200 lux • Installation Location – Install the device at least 6 ft 7 in (2 m) away from the light, and at least 9 ft 10 in (3 m) away from the window or door.

  • Page 140: Dimensions

    DS-K11T341BM(W)I-T Touchless Identity Authentication Terminal User Manual D. Dimensions UM DS-K1T341BM(W)I-T Touchless Identity Authentication Terminal 031221NA...

  • Page 141: Communication Matrix And Device Command

    • Communication Matrix – Scan the following QR code to get the device communication matrix. NOTE: Note that the matrix contains all communication ports of Hikvision access control and video intercom devices. Figure 58, QR Code of Communication Matrix •...

This manual is also suitable for:

Ds-k1t341bmwi-t

Table of Contents
