Pentair FLECK 9100 Service Manual

Pentair FLECK 9100 Service Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
FLECK 9000/9100/9500
SERVICE MANUA
L
waterpurification.pentair.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the FLECK 9100 and is the answer not in the manual?

Questions and answers

Related Manuals for Pentair FLECK 9100

Summary of Contents for Pentair FLECK 9100

  • Page 1 FLECK 9000/9100/9500 SERVICE MANUA waterpurification.pentair.com...
  • Page 2 JOB SPECIFICATION SHEET TABLE OF CONTENTS Job Number: ________________________________________ JOB SPECIFICATION SHEET ..........2 Model Number: ______________________________________ EQUIPMENT CONFIGURATION ..........2 Water Test: _________________________________________ INSTALLATION & START-UP ..........3 Capacity Per Unit: ____________________________________ 9000/9100/9500 (3200 SERIES) ELECTRO MECHANICAL Mineral Tank Size: ________ Diameter: ______Height: ______ TIMER ASSEMBLY ............6 Brine Tank Size and Salt Setting per Regeneration: _________ POWER HEAD ASSEMBLY ...........8...
  • Page 3 INSTALLATION & START-UP 11. Place approximately 1 inch (25 mm) of water above the grid plate. If a grid is not utilized, fill to the top of the air check in the salt tank. Do not add salt to the brine tank at this time. Water Pressure 12.
  • Page 4 7 Release Compound is used in the ® pins at the higher numbered end of this section as required. manufacture of Pentair control valves. The use of The number of pins multiplied by two equals minutes of other types of lubricants may attack the control’s plastic or rubber components.
  • Page 5 INSTALLATION & STARTUP CONTINUED 4. Because the control valve regenerates with soft water from the other tank, subtract the water used for regeneration. Changing Length of Brine Tank Refill Time Take each regeneration cycle and calculate the water used. The second group of holes on the program wheel determines Example: Unit is set for a 16-inch diameter tank with 4 ft the length of time the water conditioner refills the brine tank resin and salted at 8 lbs.
  • Page 6 INSTALLATION CONTINUED 9000/9100/9500 (3200 SERIES) ELECTRO MECHANICAL TIMER ASSEMBLY Meter Dome and Union Orientation Control valves outfitted with an electromechanical timer and stainless steel water meter include a special male x female threaded stainless steel union to insure proper installation and operation of the water meter.
  • Page 7 9000/9100/9500 (3200 SERIES) ELECTRO MECHANICAL TIMER ASSEMBLY CONTINUED Item No. Part No. Description Item No. Part No. Description 21 ....3 ..14087 ....Insulator 1 ....1 ..13870-03 ..Housing, Timer, 9000 22 ....1 ..15314 ....Switch, Micro, Modified 2 ....1 ..17870 ....Label, Indicator, 9000 Timer 23 ....1 ..
  • Page 8 POWER HEAD ASSEMBLY 8 • FLECK 9000/9100/9500 Service Manual ®...
  • Page 9 POWER HEAD ASSEMBLY CONTINUED Item No. Part No. Description Item No. Part No. Description 17 ....2 ..10340 ....Washer, Lock #4, Zinc 1 ....2 ..18728 ....Nut, Tinnerman, U Type, 8-32 18 ....2 ..16433 ....Switch, Miniature 2 ....1 ..11838 ....Power Cord, 6' Fleck 19 ....1 ..
  • Page 10 9000 CONTROL VALVE ASSEMBLY 14861-01 VALVE BODY,9000,MACHINED W/O-RINGS(P/Ns 11710 & 12281) BR61500-9000 Rev E 10 • FLECK 9000/9100/9500 Service Manual ®...
  • Page 11 9000 CONTROL VALVE ASSEMBLY CONTINUED Item No. Part No. Description Item No. Part No. Description 33 ....1 ..19153 ....Washer, Flow, 0.6 GPM 1 ....1 ..14861 ....Valve Body, 9000 ..19152 ....Washer, Flow, 0.8 GPM 2 .....16 ..13242-02 ..Seal, 5600,9000, 9100 ..
  • Page 12 9000 CONTROL VALVE ASSEMBLY CONTINUED Item No. Part No. Description Item No. Part No. Description 53 ..... 60421 ....Seal & Spacer Kit, 9000/9100 ..60385-0382 ..Injector Drain, 9000, 9100, Lower 0.50 BLFC #3 INJ, 5.0 DLFC ..60421HW ..Seal & Spacer Kit, 9000 ..
  • Page 13 9100 CONTROL VALVE ASSEMBLY BR61500-9100 Rev E Item No. Part No. Description Item No. Part No. Description 17 ....2 ..13363 ....Washer, Hague Drive 1 ....1 ..40688 ....Valve Body Assy, 9100 18 ....1 ..14905 ....Piston, 9000, 9100 Lower 2 .....16 ..
  • Page 14 9100 CONTROL VALVE ASSEMBLY CONTINUED Item No. Part No. Description Item No. Part No. Description 26 ....1 ..10914-000 ..Throat, Injector, #000, 47 ....1 ..13361 ....Spacer, 4600, 9100 Brown 48 ....1 ..40538 ....Retainer, 32 mm, O-ring ..10914-00 ..Throat, Injector, #00, Violet DIST, 7000 ..
  • Page 15 9100 CONTROL VALVE ASSEMBLY CONTINUED Item No. Part No. Description Item No. Part No. Description 0.50 BLFC #2 INJ, 3.5 DLFC ..60022-50 ..BLFC, 0.50 GPM, 5000/5600/9000/9100 ..60385-0272 ..Injector Drain, 9000, 9100, 0.50 BLFC #2 INJ, 4.0 DLFC ..60022-100 ..BLFC, 1.0 GPM, 5000/5600/9000/9100 ..
  • Page 16 9500 CONTROL VALVE ASSEMBLY OPTIONAL 1600 INJECTOR BR61500-9500 Rev E Item No. Part No. Description Item No. Part No. Description 1 ....1 ..16919-01 ..Valve Body, 9500, Machining 16 ....1 ..14921 ....Link, Piston Rod 2 .....16 ..16101 ....Seal, 2850, 4500 17 ....2 ..
  • Page 17 9500 CONTROL VALVE ASSEMBLY CONTINUED Item No. Part No. Description Item No. Part No. Description ..14801-05C ..Nozzle, Injector, 5C, White ..60481-21 ..Injector Assy, 1600, #1, S.S. Brass, HW ..14801-06C ..Nozzle, Injector, 6C, Red ..60481-22 ..Injector Assy, 1600, #2, S.S. 29 ....1 ..
  • Page 18 9500 CONTROL VALVE ASSEMBLY CONTINUED Item No. Part No. Description Item No. Part No. Description ..60708-12 ..DLFC, 1 inch F x 3/4 inch F, ..60721-70 ..DLFC, 1 inch F x 1 inch F, NPT, 12.0 GPM NPTF, 7.0 GPM ..
  • Page 19 1600 BRINE VALVE SYSTEM (FOR 9500) Item No. Part No. Description 1 ....1 ..16960 ....Tube, Brine Valve 1 ..16960 ....Tube, Brine Valve, HW 2 ....1 ..10329 ....Fitting, Tube, 3/8 Nut, Brass ..18698 ....Nut, 3/8-inch Tube, W/ Sleeve, HW 3 ....1 ..
  • Page 20 1700 BRINE VALVE SYSTEM (FOR 9500) Item No. Part No. Description Item No. Part No. Description 21 ..... 60039-10 ..Brine Valve Assy. 9500/1700 1 ....1 ..14792 ....Plug, End, Brine Valve 1.0 GPM 2 ....1 ..13201 ....Quad Ring, -020 ..
  • Page 21 1710 BRINE VALVE SYSTEM (FOR 9500) Item No. Part No. Description Item No. Part No. Description 17 ....1 .......Washer, Flow (Specify GPM) 1 ....1 ..41202 ....Brine Valve, 1700, Plastic, 18 ....3 ..15415 ....Fitting, Insert, 1/2-inch, Tube 2 ....1 ..14785-01 ..Retainer, Flow Control 19 ....1 ..
  • Page 22 3/4-INCH METER ASSEMBLY Item No. Part No. Description 1 ....1 ..14613 ....Flow Straightener 2 ....4 ..12473 ....Screw, Hex Washer, 10-24 x 5/8 3 ....1 ..14038 ....Meter Cap Assy, STD, Plastic 4 ....1 ..13847 ....O-ring, -137, Std/560CD, Meter 5 ....1 ..
  • Page 23 1-INCH METER ASSEMBLY FLECK • 23 9000/9100/9500 Service Manual ®...
  • Page 24 1-INCH METER ASSEMBLY Item No. Part No. Description Item No. Part No. Description 1 ..... 4 ..12112 ....Screw, Hex Hd Mach 10-24 ..60389-001NP ..Meter Assy, 1-inch Dual Port, NPT, STD, BRS BDY, 560CD, x 1/2 PDL, W/CLPS 2 ..... 1 ..15218 ....Meter Cap Assy, Brass, ..
  • Page 25 1-1/2 INCH BRASS METER ASSEMBLY Item No. QTY Part No. Description Item No. Part No. Description 12 ..... 60610-02 ..Meter Assy, 1-1/2 inch, NPT, 1 ....1 ..17569 ....Body, Meter, 2850/9500 STD, Brass Paddlewheel 2 ....1 ..13882 ....Post, Meter Impeller ..
  • Page 26 1-1/2 INCH STAINLESS STEEL METER ASSEMBLY IMPORTANT: For valves equipped with electromechanical timers and stainless steel meters, refer to the Meter Dome and Union Orientation section. Item No. Part No. Description Item No. Part No. Description 3 ....1 ..44024 ....Union, 1-1/2 inch, NPT 1 ....1 ..
  • Page 27 9000 SECOND TANK ASSEMBLY Item No. Part No. Description Item No. Part No. Description 1 ....1 ..14864-01 ..Adapter, 9000, 2nd Tank, ..15823-12NP..9000 Tube Assy, 6-inch to Machd w/O-rings 12-inch Dia. Tank (Overall Length 9.75) 2 ....8 ..13305 ....O-ring, -119 ..
  • Page 28 9100 SECOND TANK ASSEMBLY Item No. Part No. Description 1 ....4 ..40678 ....Ring, 9100, Yoke Retainer 2 ....4 ..13287 ....O-ring, -123 3 ....1 ..14865 ....Adapter Assy, 2nd Tank, 9100 4 ....1 ..19054 ....O-ring, -124 5 ....1 ..40538 ....Retainer, 32mm, O-ring Dist, 7000 6 ....1 ..
  • Page 29 9500 SECOND TANK ASSEMBLY Item No. Part No. Description 1 ....1 ..13577 ....O-ring, -226 2 ....1 ..16455 ....O-ring, -347 3 ....8 ..10231 ....Screw, Slot Hex, 1/4 - 20 x 1/2 4 ....4 ..17224 ....O-ring, -224 5 ....1 ..16916-01 ..Adapter, 9500, 2nd Tank, NPT ..
  • Page 30 2300 SAFETY BRINE VALVE 60027 Rev D Item No. Part No. Description Item No. Part No. Description ..60002-34 ..Air Check, #500, 34 inches 1 ....1 ..60027-00 ..Safety Brine Valve, 2300, Long Less Elbow ..60002-36 ..Air Check, #500, 36 inches 2 ....1 ..
  • Page 31 2310 SAFETY BRINE VALVE FLECK • 31 9000/9100/9500 Service Manual ®...
  • Page 32 2310 SAFETY BRINE VALVE Item No. Part No. Description Item No. Part No. Description 14 ....1 ..60002-10 ..Air Check, #500, American 1 ....1 ..19645 ....Body, Safety Brine Valve, Hydro 2310 ..60002-11.38 ..Air Check, #500, 11.38 inches 2 ....1 ..19803 ....Safety Brine Valve Assy Long 3 ....1 ..
  • Page 33 2350 SAFETY BRINE VALVE Item No. Part No. Description 1 ....1 ..60038 ....Safety Brine Valve, 2350 1A ....1 ..61024 ....Actuator Assy, 2350 Brine 2 ....1 ..60028-30 ..Float Assy, 2350, 30-inch Wht ....1 ..60026-30SAN .Float Assy, 2350, 30-inch Hot Water 3 ....1 ..
  • Page 34 BYPASS VALVE ASSEMBLY (METAL) 60040SS Rev T 60041SS Rev U Item No. Part No. Description 1 ....1 ..40614 ....Bypass Body, 3/4-inch ..40634 ....Bypass Body, 1-inch, SS 2 ....1 ..14105 ....Seal, Bypass, 560CD 3 ....1 ..11972 ....Plug, Bypass 4 ....1 ..
  • Page 35 BYPASS VALVE ASSEMBLY (PLASTIC) 60049 Rev G Item No. Part No. Description Item No. Part No. Description 1 ....2 ..13305 ....O-ring, -119 ..41026-02 ..Yoke, 1-inch, BSP, Cast, 2 ....2 ..13255 ....Clip, Mounting MACHD, SS 3 ....2 ..13314 ....Screw, Slot Ind Hex, ..
  • Page 36 GENERAL SERVICE HINTS FOR METER CONTROL Problem: Softener delivers hard water Reason: Reserve capacity has been exceeded. Correction: Check salt dosage requirements and reset program wheel to provide additional reserve. Reason: Program wheel is not rotating with meter output. Correction: Pull cable out of meter cover and rotate manually. Program wheel must move without binding and clutch must give positive clicks when program wheel strikes regeneration stop.
  • Page 37 TROUBLESHOOTING Problem Cause Correction Water conditioner fails to Electrical service to unit has been Assure permanent electrical service (check fuse, regenerate. interrupted plug, pull chain, or switch) Timer is defective. Replace timer. Power failure. Reset time of day. Hard water. By-pass valve is open.
  • Page 38 9000/9100/9500 METER FLOW DATA 9000 Meter Flow Data 9100 Meter Flow Data 9500 Meter Flow Data 38 • FLECK 9000/9100/9500 Service Manual ®...
  • Page 39 9000/9100/9500 INJECTOR FLOW DATA (1600 SERIES INJECTORS) FLECK • 39 9000/9100/9500 Service Manual ®...
  • Page 40 9500 INJECTOR FLOW DATA (1600 &1700 SERIES INJECTORS) 1600 Series Injectors 1700 Series Injectors 40 • FLECK 9000/9100/9500 Service Manual ®...
  • Page 41 9000 CONTROL DIMENSIONS FLECK • 41 9000/9100/9500 Service Manual ®...
  • Page 42 9100 CONTROL DIMENSIONS 42 • FLECK 9000/9100/9500 Service Manual ®...
  • Page 43 9500 CONTROL DIMENSIONS FLECK • 43 9000/9100/9500 Service Manual ®...
  • Page 44 WATER CONDITIONER FLOW DIAGRAMS 3 Tanks Switching Position 1 In Service Position (Meter Initiated Regeneration) 4 Brine Draw Position 2 Backwash Position 5 Slow Rinse 44 • FLECK 9000/9100/9500 Service Manual ®...
  • Page 45 WATER CONDITIONER FLOW DIAGRAMS CONTINUED 8 In Service Position, Tanks Switched 6 Brine Tank Fill Position 7 Rapid Rinse Position FLECK • 45 9000/9100/9500 Service Manual ®...
  • Page 46 9000/9500 WIRING DIGRAM 46 • FLECK 9000/9100/9500 Service Manual ®...
  • Page 47 SERVICE ASSEMBLIES Brine Line Flow Controls (9000/9100): 60381-06 ��������������������� Injector Assy, 1700, #6, Cold & HW 150° 60022-12 ��������������������� BLFC, �125 GPM, 5000/5600/9000/9100 60480-01 ��������������������� Injector Assy, 1600, #1, Plastic, Cold 60022-25 ��������������������� BLFC, �25 GPM, 5000/5600/9000/9100 Water 60022-50 ��������������������� BLFC, �50 GPM, 5000/5600/9000/9100 60480-02 ���������������������...
  • Page 48 SERVICE ASSEMBLIES CONTINUED 60610-22 ��������������������� Meter, 2850/9500, 1-1/2 inch Ext/BSP Second Tank Assemblies (9000): Metric 14202-01 ��������������������� Screw, Hex Washer Mach, 8-32 x 5/16 60610-22NP ���������������� Meter, 2850/9500, 1-1/2 inch Ext/BSP 18-8 S�S� Metric/Nickel Plated 13255 ��������������������������� Clip, Mounting 60611-01HW ��������������� Meter, 2850/9500, 1-inch Sleeve, 15078-01 ���������������������...
  • Page 50 © 2018 Pentair Residential Filtration, LLC. All rights reserved. §For a detailed list of where Pentair trademarks are registered, please visit waterpurification.pentair.com/brands. Pentair trademarks and logos are owned by Pentair plc or its affiliates. Third party registered and unregistered trademarks and logos are the property of their respective owners.
  • Page 52 © 2018 Pentair Residential Filtration, LLC. All rights reserved. §For a detailed list of where Pentair trademarks are registered, please visit waterpurification.pentair.com/brands. Pentair trademarks and logos are owned by Pentair plc or its affiliates. Third party registered and unregistered trademarks and logos are the property of their respective owners.

This manual is also suitable for:

Fleck 9000Fleck 9500Fleck 9500sxtFleck 9500/1700sxtFleck 9100sxt
