Clean & Clear
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS
PUMP SAFETY INSTRUCTIONS ------------------------------------------------------- 2
SECTION II.
HOW YOUR FILTER WORKS----------------------------------------------------------- 2
SECTION III. CHECK VALVE INSTALLATION INSTRUCTIONS ----------------------------------- 3
SECTION IV. INSTALLATION --------------------------------------------------------------------------- 4
SECTION V.
INITIAL START-UP AND RESTART INSTRUCTIONS. ------------------------------ 6
SECTION VI. CLEANING THE FILTER------------------------------------------------------------------ 6
SECTION VII. WINTERIZING THE FILTER ------------------------------------------------------------- 8
SECTION VIII. CLEANING THE HIGH FLOW MANUAL AIR RELIEF VALVE --------------------- 8
SECTION IX. TROUBLE SHOOTING -------------------------------------------------------------------- 9
SECTION X.
PUMP INSTRUCTIONS ------------------------------------------------------------------ 9
SECTION XI. TECHNICAL DATA --------------------------------------------------------------------- 11
A. FILTER AND TANK ------------------------------------------------------------------------------------ 11
B. MAXIM PUMP ----------------------------------------------------------------------------------------- 12
C. DYNAMO PUMP --------------------------------------------------------------------------------------- 13
Attention Installer. This manual contains important information about the installation,
operation and safe use of this product. This information should be given to the owner/
operator of this equipment.
Before installing this product, read and follow all warning notices and instructions accompanying this
filter. Failure to follow safety warnings and instructions can result in severe injury, death, or property
damage. Call (800) 831-7133 for additional free copies of these instructions.
Pentair Pool Products
1620 Hawkins Ave., Sanford, NC 27330 • (919) 774-4151
10951 West Los Angeles Ave., Moorpark, CA 93021 • (805) 523-2400
REV. F 5-1-01
™
Filter System Owner's Manual
SAVE THESE INSTRUCTIONS
Table of Contents
Important Notice
WARNING
1
P/N 99101100
Advertisement
Table of Contents
Related Manuals for Pentair 99101100
Summary of Contents for Pentair 99101100
-
Page 1: Table Of Contents
Call (800) 831-7133 for additional free copies of these instructions. Pentair Pool Products 1620 Hawkins Ave., Sanford, NC 27330 • (919) 774-4151 10951 West Los Angeles Ave., Moorpark, CA 93021 • (805) 523-2400 REV. F 5-1-01 ™ Filter System Owner's Manual Table of Contents Important Notice WARNING P/N 99101100... -
Page 2: Section I. Pump Safety Instructions
In general, proper pool sanitation requires a free chlorine level of 1 to 2 PPM and a PH range of 7.2 to 7.6. P/N 99101100 WARNING REV. F 5-1-01... -
Page 3: Section Iii. Check Valve Installation Instructions
If possible, plug the return line to prevent siphoning. If this can not be done, disconnect the union fitting from the outlet port of the filter and quickly place the return hose into the pool. Remove the drain cap to empty the water from the filter. REV. F 5-1-01 WARNING WARNING P/N 99101100... -
Page 4: Section Iv. Installation
Tighten the union fittings on the plumbing connector by hand until tight. If water leakage occurs at these connections, adjust connections with a wrench making sure not to exceed 1/ 4 of a turn. P/N 99101100 Diagram 1. Detail C Detail D Detail B Detail A Diagram 2. - Page 5 Slide the two tabs on the Chlorinator Base into the slots on the system base; see Diagram 4. REV. F 5-1-01 Figure 1. Skimmer POOL Skim- Diagram 3. Tabs Diagram 4. Figure 2. Return Return Fitting Slots P/N 99101100...
-
Page 6: Section V. Initial Start-Up And Restart Instructions
Remove the filter lock ring by depressing the two spring loaded locking blocks and rotating the ring counter clockwise until the ring is free from the filter body. Remove the filter lid using the lifting handles on the lid. P/N 99101100 WARNING REV. F 5-1-01... - Page 7 Poor water clarity may obscure objects in the water which while swimming and diving could cause severe personal injury and death. Never swim in a pool with poor water clarity. REV. F 5-1-01 WARNING WARNING P/N 99101100...
-
Page 8: Section Vii. Winterizing The Filter
5/16" drill bit through the valve body. Verify that the O-rings are in good condition, properly positioned, and lubricated with a silicone base lubricant. Reinstall the valve stem and cover assembly with a downward and clockwise motion until it snaps into position. P/N 99101100 REV. F 5-1-01... -
Page 9: Section X. Pump Instructions
Open valve or remove obstruction in return line. Clean the filter element (see Cleaning Filter instructions). Restrict flow to capacity of filter. Clean basket in strainer. Disassemble and clean pump. Clean skimmer basket. Remove obstruction in lines. Open valves in suction line. WARNING Remedy P/N 99101100... - Page 10 ALWAYS MAINTAIN PROPER WATER LEVEL IN THE POOL. Water level must be half way up the skimmer opening. A low water level can cause the pump motor to run dry which will damage the mechanical seal and cause external leakage. P/N 99101100 CAUTION CAUTION CAUTION REV.
-
Page 11: Section Xi. Technical Data
Union Nut 39102800 Union O-ring 178543 Pump Connector 39107400 Outlet Connector 51516100 Check Valve Kit 178540 System Base Assy. 178541 Chlorinator Base 79304700 Union, Body, for Chlorinator Attach. 98200700 Bolt 98317100 T-nut 39201400 Pump Support REV. F 5-1-01 P/N 99101100... -
Page 12: Maxim Pump
5 39153300 Impeller, 1 hp, 50 cycle 5 39153400 Impeller, 1½ hp, 50 cycle 6 39101500 O-ring, volute 7 98210400 Screw, faceplate, 8-32 x 5/8 in., S Series P/N 99101100 Replacement Parts Find Part 98215000 No.10 lock washer, internal star 98215200 Nut, hex, 10-24 Maxim pump 8 39106800 Pot, Union Nut, face plate, wear ring assy. -
Page 13: Dynamo Pump
19 35-2207 Adaptor, 1½ in. quick connect, 2 req. 20 35-2206 Nut, 1½ in. quick connect, 2 req. 21 35-4571 O-ring, 2 req. 22 35-4103 Pot assy. (continued on next page) SNAP TAB 24, 24A SNAP TAB MOTOR - SEE NOTE 1 SNAP TAB SLOT Description P/N 99101100... -
Page 14: Replacement Parts
28a35-6546 Switch - 3 pos. toggle 29 15-5193 Wire - 6 in. jumper 30 35-4658 Insulation - foam strip adhesive backing 31 35-4659 Window - light sensor SAVE THESE INSTRUCTIONS. P/N 99101100 Replacement Parts Part Description SNAP TAB 24, 24A... - Page 15 REV. F 5-1-01 P/N 99101100...
