Using FileTransfer2

Adding Files From a Specific Project/System

In the Send tab:
1. Select File > Load Workspace/AXW/FTL File or click the Load Workspace command button
to open the Open File dialog.
2. Set the File of Type drop-down to NetLinx Studio Files (*.apw).
3. Locate and select the Workspace file that contains the Project/System with the file(s) you want
to add, and click Open. This opens the Quick Load dialog.
4. In the Selection Options section:
5. Click in the checkboxes to specify which file types in the selected System to add.
6. Click OK to close the Quick Load dialog and add the files to the File To Send queue.

Adding Individual System Files From the Open Workspace file

With a Workspace (or Workspace To-Go) file open, use the Add command button (in the Send tab)
to select individual System files to add to the Files To Send queue:
1. Click the Add command button to open the Select Files For File Transfer dialog.
2. Open the Current Workspace tab.
3. Click OK to add the selected file(s).

Adding Orphan Files

In the Send tab:
1. Click the Add command button to open the Select Files For File Transfer dialog.
2. Open the Other tab. Use this tab if the file(s) you want to transfer are not included in the open
Workspace. This tab consists of a display of the different types of files that can be transferred
to the Master or System devices on the bus:
16
Select Active System to add files from the active System in the open Workspace.
Select a Project-System to add files from a specific Project/System in the open
Workspace.
This tab consists of a display of the (compiled) Source Code (.AXS), Token (.TKN),
User-Interface (.TPD/.TP4) and IR (.IRL) files contained in the currently open
Workspace.
Use the options in the Current Workspace tab to locate and select file(s) for transfer to the
Master or System devices on the bus. Use this tab if the file(s) you want to transfer are
included in the open Workspace.
IR Codes (*.IRL/*.IRV)
NetLinx Source Code (*.SRC)
Compiled NetLinx Source Code (*.TKN)
Compiled Axcess Source Code (*.TOK)
Touch Panel Design File (*.TPD)
TP4 Touch Panel (*.TP4)
