Welcome To FileTransfer2
Use the Send tab for transferring files from the PC running FileTransfer2 and the target Master
Controller or System Device.

Send Tab

The Transfer List table in the Send tab indicates the files that are currently in the Files To Send
queue. Each row in the table represents a single System file, and could be any of the supported
system file types.
The columns in the table display the following file information for each file in the queue:
The Reboot option always reboots the Master, regardless of the device mapping
associated with the file itself. For example, TPD/TP4 files are transferred directly to
the panel, but the Reboot option will reboot the Master - not the panel that received
the file.
You are responsible for ordering your transfers correctly. If you choose to reboot after
a transfer and then immediately attempt to transfer to another device that is on the
bus of the master that is rebooting, the device will more than likely not be available
and the transfer will fail.
2
Use the Receive tab for transferring files from a Master Controller or System Device to
the PC.
The Menu bar provides access to the main functions of the program.
The Transfer Command Buttons allow you to control transfer functions.
The Load Options provide flexibility in how you can add files to the Transfer List.
The Transfer Status Window displays the status of each file transfer operation.
Workspace: displays the name of the currently open Workspace file
Project: displays the name of the active Project
System: displays the name of the active System
File: displays the name of the file in the Files To Send queue
Reboot: click the checkbox in this column to reboot the target device when the transfer is
complete
By default, the Reboot option is enabled (for Workspace files only), so that the System
Master will automatically reboot after the transfer is complete.
It is usually necessary to reboot a NetLinx master after a TKN file transfer. However, it is
not always desirable to have the reboot occur immediately after the file is transferred.
The Reboot checkbox allows you the flexibility of specifying when the reboot should
occur.
Connection: displays the communications settings associated with this file.
Mapping: displays the device-file mapping information (Device:Port:System) associated
with this file.
Options (TPD and TP4 files only): displays any optional file information associated with
the selected file (via either the TPD Transfer Options or TP4 Transfer Options dialog,
