Using FileTransfer2
6. Click OK to save the new TCP/IP communication settings with the selected file.

Configuring Serial Communication Settings

With a Transfer selected in the Transfer List:
1. Click the Edit command button, and select Communication Settings to open the
Communication Settings dialog.
2. Specify the Platform Selection (NetLinx Master or Axcess Master).
3. Select Serial as the Transport Connection Option.
4. Click Edit Settings to open the Serial Settings dialog.
5. Select a COM port and specify the communication settings for serial port communications.
The default settings are:
6. Click OK to return to the Communication Settings dialog.
7. Click OK to save the new Serial communication settings with the selected file.

Configuring Modem Communication Settings

With a Transfer selected in the Transfer List:
1. Click the Edit command button, and select Communication Settings to open the
Communication Settings dialog.
2. Specify the Platform Selection (NetLinx Master or Axcess Master).
3. Select Modem as the Transport Connection Option.
4. Click Edit Settings to open the Modem Settings dialog.
5. Select a COM port and specify the communication settings for modem communications. The
default settings are:
6. Click OK to return to the Communication Settings dialog.
20
Comm Port — COM1
Baud Rate — 38400
Data Bits — 8
Parity — None
Stop Bits — 1
Flow Control — None
Comm Port — COM1
Baud Rate — 38400
Data Bits — 8
Parity — None
Stop Bits — 1
Flow Control — None
Phone Number — Enter the telephone number of the master.
