Video Wall Functions (Cont.)
Name
setImage(source, pos, size)
setImageSource(int)
setPictureMuteOn(state)
setSharpness(level)
setTint(level)
setWindow(pos,size)
setZOrder(position)
setZOrder(value)
zoomIn()
zoomOut()
processBrightnessEvent(int)
processColorEvent(int)
processContrastEvent(int)
processFreezeEvent(boolean)
Standard NetLinx API (SNAPI) R 1.8.0
Component Channel Level Command
IWindowComponent
IWindowComponent
IWindowComponent 211
IWindowComponent
IWindowComponent
IWindowComponent
IWindowComponent
IWindowComponent
IWindowComponent 159
IWindowComponent 158
IWindowComponentListener
IWindowComponentListener
IWindowComponentListener
IWindowComponentListener 214
Constant
IMAGE-
<source>,<x>,<y>,<hei
ght>,<width>
IMAGESOURCE-
<source>
PIC_MUTE_ON
13 SHARP_LVL
14 TINT_LVL
WINDOW-
<x>,<y>,<height>,<widt
h>
WINDOWZORDER-
<position>
WINDOWZORDER-
<value>
ZOOM_IN
ZOOM_OUT
10 BRIGHT_LVL
11 COLOR_LVL
12 CONTRAST_LVL
PIC_FREEZE_FB
Notes
Set the image source, position and size rel-
ative to the window where <source> is 1 to
the maximum source number (see specific
module documentation) and <x> and <y>
are the window coordinates for the upper-
left hand corner of the image and <height>
and <width> are the size of the image to be
displayed in the window. Used to change
the position of the image visible in the win-
dow.
Set the image source for the window where
<source> is 1 to the maximum source num-
ber (see specific module documentation)
Discrete Function Channel: Picture Mute is
on while channel is active
Set sharpness level, range is 0-255
Set tint level, range is 0-255
Set the window position and size relative to
the display where <x> and <y> are the dis-
play coordinates for the upper-left hand
corner of the window and <height> and
<width> are the size of the window to be
displayed in the display. Used to change
the position of the window visible in the dis-
play.
Shuffle the window z-order relative to the
other windows where <postiion> is FRONT,
BACK, FORWARD (up one level), BACK-
WARD (down one level)
Set the Z-order where <value> is 1 to the
maximum z-order of the device, 1 is the
top-most z-order (see specific module doc-
umentation)
Momentary Function Channel: Image size
is enlarged within the window (zoom in/
tele) when channel is activated
Momentary Function Channel: Image size
is reduced within the window (zoom out/
window) when channel is activated
Brightness changed, range is 0-255
Color changed, range is 0-255
Contrast changed, range is 0-255
Feedback Channel: Freeze is on if channel
is on
