Video Wall Functions (Cont.)
Name
processDebugEvent(int)
processDeviceOnLineEvent(boolean)
processPassbackEvent(byte[])
cyclePower()
setPower(ON)
setPower(OFF)
setPower(ps)
setPowerSensor(nld,nIOChan)
processPowerEvent(ON)
getVideoWallConfiguration()
queryVideoWallConfigurationList()
saveVideoWallConfiguration(sConfig)
setVideoWallConfiguration(sConfig)
processVideoWallConfigurationEvent(String)
processVideoWallConfiguration-
ListEvent(String[])
326
Component Channel Level Command
IModuleComponentListener
IModuleComponentListener 251
IModuleComponentListener
IPowerComponent 9
IPowerComponent 27
IPowerComponent 28
IPowerComponent 255
IPowerComponent
IPowerComponentListener 255
IVideoWallComponent
IVideoWallComponent
IVideoWallComponent
IVideoWallComponent
IVideoWallComponentListener
IVideoWallComponentListener
Constant
DEBUG-<state>
DEVICE_COMMUNICATING Feedback Channel: Communication is
POWER
PWR_ON
PWR_OFF
POWER_ON
IOLINK-<dps>,<chan-
nel>
POWER_FB
?VWALLCONFIG
?VWALLCONFIGLIST
VWALLCONFIGSAVE-
<config>
VWALLCONFIG-<con-
fig>
VWALLCONFIG-<con-
fig>
VWALLCONFIGLIST-
<config>
Notes
Debug state changed where <state> is 1-4
for ERROR, WARNING, DEBUG, INFO
established with device while channel is on
When passback is on, each string received
form the device is sent to the NetLinx pro-
gram as a string. Use a DATA_EVENT
event with a STRING handler to caputre
the data from the device.
Momentary Function Channel: Cycle power
when channel is activated
Momentary Function Channel: Power is
turned on when channel is activated
Momentary Function Channel: Power is
turned off when channel is activated
Discrete Function Channel: Power is on
while channel is active
Associate a Power Sensor with the device
where <dps> is the DPS in string form, i.e.
17:1:0, and <channel> is the channel on
the IO device to which the power sensor is
connected.
Feedback Channel: Power state changed,
power is on while channel is on
Query for video wall configuration,
responds with VWALLCONFIG-<config>
Query for the list of available Video Wall
Configurations, responds with multiple
VWALLCONFIGLIST-<config> commands,
one for each valid configuration
Save video wall configuration where <con-
fig> is the configuration name
Recall video wall configuration where <con-
fig> is the configuration name
Video wall configuration changed, where
<config> is the configuration name
Response to Video Wall configuration list
query, responds with multiple VWALLCON-
FIGLIST-<config> commands, one for each
valid configuration
