Regency HAMPTON Greenfire GF60-2 Owner's Manual

Freestanding cast iron pellet stove
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS
PELLET-BURNING ROOM HEATER. FAILURE TO FOLLOW THESE INSTRUCTIONS
COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
Contact your building or fire officials about restrictions and installation inspection
WARNING:
Improper installation, adjustment, alteration, service
or maintenance can cause injury, property damage,
or loss of life. Refer to this manual. For assistance or
additional information consult an authorized
installer or service agency.
Tested by:
IMPORTANT: SAVE THESE INSTRUCTIONS
920-586a
FPI FIREPLACE PRODUCTS INTERNATIONAL, LTD. 6988 Venture St., Delta, BC, Canada V4G 1H4
Greenfire
OWNER'S MANUAL
Freestanding Cast Iron
requirements in your area.
Do not store or use gasoline or other flammable
vapours and liquids in the vicinity of this or any other
appliance.
Installation and service must be performed by an
authorized installer or service agency.
GC60-2
®
Pellet Stove
French Manual: https://bit.ly/3v9xArf
Manuel en Français : https://bit.ly/3v9xArf
FOR YOUR SAFETY:
07.17.24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HAMPTON Greenfire GF60-2 and is the answer not in the manual?

Questions and answers

Related Manuals for Regency HAMPTON Greenfire GF60-2

Summary of Contents for Regency HAMPTON Greenfire GF60-2

  • Page 1 Greenfire GC60-2 ® OWNER’S MANUAL Freestanding Cast Iron Pellet Stove French Manual: https://bit.ly/3v9xArf Manuel en Français : https://bit.ly/3v9xArf PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS PELLET-BURNING ROOM HEATER. FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH. Contact your building or fire officials about restrictions and installation inspection requirements in your area.

  • Page 2: To The New Owner

    The authority having jurisdiction should be consulted before installation to determine the need to obtain a permit. Emissions and Efficiency: This manual describes the installation and operation of the Regency GC60-2 pellet heater. This heater is U.S. ENVIRONMENTAL PROTECTION AGENCY certified to comply with 2020 particulate emission standards.

  • Page 3: Table Of Contents

    Table of Contents Introduction..................4 Rating Label Location..............4 Fuel Quality................4 Safety Warnings & Recommendations............5 Safety Decal ..................6 Safety Warnings & Recommendations............7 Dimensions & Specifications..............7 Operating Instructions................9 Control Board Functions.............9 Automatic Safety Features of Your Pellet Stove......9 Operating Your Pellet Stove............10 Turning Your Pellet Stove Off............11 Slider/Damper Set-Up...............11 Routine Cleaning and Maintenance............12 Warranty...................16...

  • Page 4: Introduction

    FUEL FEED RATES: Due to different fuel densities and sizes, fuel feed rates may vary. This may require an adjustment to the slider damper setting or to the auger feed trim setting. Since Regency Fireplace Products Ltd. has no control over the quality of fuel that you use, we assume no liability for your choice in fuels.

  • Page 5: Safety Warnings & Recommendations

    Safety Warnings & Recommendations Please read this entire Owner’s Manual before installing or operating your Hampton Pellet Stove. Failure to follow these instructions may result in property damage, bodily injury or even death. Any unauthorized modification of the appliance or use of replacement parts not recommended by the manufacturer is prohibited.

  • Page 6: Safety Decal

    Safety Decal This is a copy of the safety label that accompanies each GC60-2. We have printed a copy of the contents here for your reference. On the GC60-2 the safety label is located on the underside of the hopper lid. Sidewall Hampton GC60-2 Cast Pellet Stove Owner’s Manual...

  • Page 7: Safety Warnings & Recommendations

    SINCE REGENCY FIREPLACE PRODUCTS LTD. HAS NO CONTROL OVER THE INSTALLATION OF YOUR STOVE, REGENCY FIREPLACE PRODUCTS LTD. GRANTS NO WARRANTY IMPLIED OR STATED FOR THE INSTALLATION OR MAINTENANCE OF YOUR STOVE. THEREFORE, REGENCY FIREPLACE PRODUCTS LTD.
  • Page 8 Specifications imenSionS 23" (584mm) 3” Fresh Air Intake 4” Exhaust 28.7" (729mm) 29.4" 28" (748mm) (713mm) 31.7" (806mm) 4” Exhaust 28.4" 18.5" (722mm) (470mm) Figure 1: Dimensions of GC60-2. peciFicationS Input rating when using: Wood Pellets/Corn - 55,000BTU (16.1KW•hr) & Wheat/Barley - 53,000BTU (15.5KW•hr). Table 1: GC60-2 Specifications.

  • Page 9: Operating Instructions

    Operating Instructions ontRoL oaRd unctionS Note: The Control Panel is located underneath the units Cast Hopper Lid which is attached to a safety switch that will immediatley stop the auger. The switch will stop operation of the stove and display a #4 flash code if the lid is not closed within two minutes.

  • Page 10: Manual Mode

    Operating Instructions peRating eLLet tove THE UNIT WILL NOT OPERATE WITH THE DOOR OR ASH BOX OPEN. Open the hopper lid only to re-fuel or to adjust the controls. The unit will shut down if the hopper lid is left open for longer than two minutes. CAUTION: When operating during adverse weather, such as high winds or freezing rain, if the unit exhibits Premium Grade Pellets dramatic changes in combustion stop using the unit immediately.

  • Page 11: Turning Your Pellet Stove Off

    Operating Instructions uRning eLLet tove • MANUAL and HI / LOW mode: To turn the unit OFF, simply press the ON / OFF button. This will stop the feed of pellets. The blowers will continue to operate and cool the stove down. When cool enough, the stove will turn off. • AUTO / OFF mode: To turn the unit OFF, turn the Thermostat down or Timer off.

  • Page 12: Routine Cleaning And Maintenance

    Routine Cleaning and Maintenance The following list of components should be inspected and maintained routinely to ensure that the appliance is operating at its optimum and giving you excellent heat value. The appliance, flue gas connector and the chimney flue require regular cleaning. Check them for blockage prior to re-lighting after a prolonged shut down period.
  • Page 13 Routine Cleaning and Maintenance 10. Set the fire grate in place, it should sit level on the front and back of the burn pot liner. Lock it in with the lever on the burn pot. 11. Close the door. Heat eXcHangeR tubeS (Weekly) The Heat Exchanger Tube’s Cleaning Rake Handle is located above the firebox door.

  • Page 14: Cleaning Painted Surfaces

    Routine Cleaning and Maintenance EXHAUST PASSAGES (Biannually) Firebox Baffle 1. Open the firebox door by lifting the handle. 2. Remove the burn pot assembly Firebox Liner and clean all the parts. 3. Lubricate screws with penetrating oil. 4. Lift the baffle, remove the firebox Firebox Lower liner, and lift out the firebox lower.
  • Page 15 Notes Hampton GC60-2 Cast Pellet Stove Owner’s Manual...

  • Page 16: Warranty

    WARRANTY Indoor Pellet Product Warranty Limited Lifetime Warranty FPI Fireplace Products International Ltd. (for Canadian customers) and Fireplace Products US, Inc. (for US customers) (collectively referred to herein as “FPI”) extends this Limited Lifetime Warranty to the original purchaser of this Appliance provided the product remains in the original place of installation. The items covered by this Limited Lifetime Warranty and the period of such coverage are set forth in the table below.
  • Page 17 WARRANTY may, at its own discretion, fully discharge all of its obligations under warranty by refunding the verified purchase price of the product to the original purchaser. The purchase price must be confirmed by the original Bill of Sale. The authorized selling dealer, or an alternative authorized FPI dealer if pre-approved by FPI, is responsible for all in-field diagnosis and service work related to all warranty claims.
  • Page 18 WARRANTY cardboard, coal or coal products, oil-based products, waxed cartons, compressed pre- manufactured logs), lack of regular maintenance and upkeep, acts of God, weather-related problems from hurricanes, tornados, earthquakes, floods, lightning strikes/bolts or acts of terrorism or war, which result in a malfunction of the Appliance are not covered under the terms of this Limited Lifetime Warranty.
  • Page 19 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form at http://www.regency-fire.com/Customer-Care/Warranty-Registration.aspx...
  • Page 20 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
  • Page 21 Hampton GC60-2 Cast Pellet Stove Owner’s Manual...

  • Page 22: Recycling

    By recycling your used appliances, you divert waste from your local landfills and help the environment. You also reduce the need for raw materials to manufacture new products. Contact your local municipality for appliance recycling services, local recycling programs, or appliance removal services to ensure your Regency appliance components, and packaging are properly recycled. Hampton GC60-2 Cast Pellet Stove Owner’s Manual...
  • Page 24 Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial #: ____________________________________________________________ Printed in Canada Regency, Hampton and Greenfire are registered and / or proprietary trademarks of FPI Fireplace Products International Ltd. © Copyright 2024, FPI Fireplace Products International Ltd. All rights reserved.
