Doc.No.DOC1118350
PRODUCT NAME
Main Line Filter
Mist Separator
Micro Mist Separator
MODEL / Series / Product Number
AFF70DS-(F,N)10-(J,V)-P1
AFF80DS-(F,N)14-(J,V)-P1
AFF90DS-(F,N)20-(J,V)-P1
AM70DS-(F,N)10-(J,V)-P1
AM80DS-(F,N)14-(J,V)-P1
AM90DS-(F,N)20-(J,V)-P1
AMD70DS-(F,N)10-(J,V)-P1
AMD80DS-(F,N)14-(J,V)-P1
AMD90DS-(F,N)20-(J,V)-P1
Advertisement
Table of Contents
Related Manuals for SMC Networks AFF70DS-F10-J-P1
Summary of Contents for SMC Networks AFF70DS-F10-J-P1
- Page 1 Doc.No.DOC1118350 PRODUCT NAME Main Line Filter Mist Separator Micro Mist Separator MODEL / Series / Product Number AFF70DS-(F,N)10-(J,V)-P1 AFF80DS-(F,N)14-(J,V)-P1 AFF90DS-(F,N)20-(J,V)-P1 AM70DS-(F,N)10-(J,V)-P1 AM80DS-(F,N)14-(J,V)-P1 AM90DS-(F,N)20-(J,V)-P1 AMD70DS-(F,N)10-(J,V)-P1 AMD80DS-(F,N)14-(J,V)-P1 AMD90DS-(F,N)20-(J,V)-P1...
-
Page 2: Table Of Contents
Contents Page 1. Safety Instructions 2. Application 3. Standard specifications 8-10 4. How to Order 5. Structural Drawing, Replacement Parts 6. Trouble Shooting 7. How to Replace the Element 14-16 8. Disassembly Drawing 9. Dimensions... -
Page 3: Safety Instructions
Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations. -
Page 4: Limited Warranty And Disclaimer/Compliance Requirements
Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act. - Page 5 Precautions for Design Warning 1. Do not use the product if no leakage is allowed due to the environment, or if the fluid is not air. 2. If the air equipment is mounted on the outlet of the product, particles will be generated from the equipment and required cleanliness may not be obtained.
- Page 6 3. Connect piping/fittings using the recommended torque while holding the female thread side tightly. Insufficient tightening torque leads to cause of loosening or sealing failure, and excessive tightening torque leads to cause of breakage of screws. Tightening without holding the female thread may cause product breakage, injury or accident. Recommended tightening torque Unit: N m Thread size...
- Page 7 Air Source Warning 1. Use clean air. Do not use compressed air containing chemicals, organic solvent, synthetic oil or corrosive gas as it may be cause of breakage of components or operation failure. 2. Install an air dryer or after cooler on upstream side. Air containing excess drainage may cause malfunction.
- Page 8 6. Check the drain the bowl regularly, discharge it before it reaches the element. Operation with condensate caught in the equipment or the piping may lead to operation failure of the equipment, splashing from the outlet, and unexpected accidents. 7. Clean the bowl regularly. Clean the inside of the bowl with detergent to remove foreign matter and grease.
-
Page 9: Application
2. Application Series Product name Application This product aims at eliminating excess Main Line Filter saturated water and solid foreign matter (1μm) in the air line. This product aims at eliminating oil mist and Mist Separator solid foreign matter (0.1μm) in the air line. - Page 10 3-2.AM Series Model AM70DS AM80DS AM90DS Port size 1 1/2 Fluid Ambient and fluid temperature °C -5～60(No freezing) Note1) Proof pressure 1.5 (2.4 Note1) Max. operating pressure 1.0 (1.6 Min. operating pressure Nominal filtration rating µm 0.1 (99% Filtered particle size) Outlet side oil mist concentration mg/m (ANR)
- Page 11 3-3.AMD Series Model AMD70DS AMD80DS AMD90DS Port size 1 1/2 Fluid Ambient and fluid temperature °C -5～60(No freezing) Note1) Proof pressure 1.5 (2.4 Note1) Max. operating pressure 1.0 (1.6 Min. operating pressure Nominal filtration rating µm 0.01 (99.9% Filtered particle size) Outlet side mg/m (ANR)
-
Page 12: How To Order
4. How to Order ＜Air preparation filter＞ Filter type Notr4)Note5) Accessory Symbol Product name Symbol Description Main Line With branch port plugs Filter Note 4) Branch port plugs are square-head type. Mist Note 5) Two plugs are included and not assembled. Separator Micro Mist Separator... -
Page 13: Structural Drawing, Replacement Parts
5. Structural Drawing, Replacement Parts Component parts Part name Body Element Bowl Flange Stopper Branch port plugs Drain guide Ball Valve Replacement parts Part No. Part name 70DS 80DS 90DS AFF-EL70DS AFF-EL80DS AFF-EL90DS （Gray） Element AM-EL70DS AM-EL80DS AM-EL90DS （Light Blue） AMD-EL70DS AMD-EL80DS AMD-EL90DS... -
Page 14: Trouble Shooting
6. Trouble Shooting Trouble Page for Possible causes Countermeasure Category Failure reference As pressure drop 1. Clog of the element. Replace the element. is large, fluid does P14-16 not flow. Air leakage from 1. O-ring of the bowl Replace the O-ring. O-ring is between the body is damaged. -
Page 15: How To Replace The Element
7. How to Replace the Element Warning Before replacement, make sure that no pressure remains in the product. After replacement, confirm that the product satisfies specific functions and no external leakage occurs before operating it. Applicable Work Procedure model category AFF70DS Disassembly While holding the body in place, use a spanner to loosen the 4 hexagon head bolts on the... - Page 16 Applicable Work Procedure model category AFF70DS Assembly Insert an element (new) into the bowl and mount an O-ring (new) for the bowl. If the support 1） AFF80DS ring is removed, mount the support ring before the O-ring for the bowl. 【Point】Ensure that the element inserting direction is correct.
- Page 17 Applicable Work Procedure model category 【When it is difficult to insert the new element into the body】 AFF70DS Assembly AFF80DS Please apply lubricant to the connection (body) of the O-ring for the element. AFF90DS At this time, pay attention that lubricant is not stuck to the element surface and internal surface of the bowl and body (parts other than the element connection).
-
Page 18: Disassembly Drawing
8. Disassembly Drawing Hexagon head bolts (6) Branch port plugs (1) Body O-ring for the element (2) Element O-ring for the bowl Support ring Guide (4) Flange (5) Stopper (3) Bowl (7) Drain guide -17-... -
Page 19: Dimensions
9. Dimensions Model 21.3 68.7 34.3 68.7 AFF,AM,AMD 70DS 1 1/2 30.3 80.7 43.3 80.7 AFF,AM,AMD 80DS AFF,AM,AMD 90DS 36.6 80.7 49.6 80.7 Note) The thread type for each port will be the same as the selected thread type. Drain port Drain cock Drain guide Model... - Page 20 Revision history Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © SMC Corporation All Rights Reserved...
