- Page 1 Centrifugal roof fan tower-aM USER’S MANUAL...
-
Page 2: Table Of Contents
tower-aM www.blaubergventilatoren.de CONTENTS Safety requirements ..................................3 Purpose ........................................ 5 Delivery set ......................................5 Designation key ....................................5 Technical data ....................................6 Mounting and set-up .................................. 7 Connection to power mains ..............................8 Technical maintenance ................................10 Storage and transportation regulations .......................... 12 Manufacturer’s warranty ................................ -
Page 3: Safety Requirements
tower-aM www.blaubergventilatoren.de SAFETY REQUIREMENTS This unit is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the unit by a person responsible for their safety. Children should be supervised to ensure that they do not play with the unit. - Page 4 tower-aM www.blaubergventilatoren.de All operations described in this manual must be performed by qualified personnel only, properly trained and qualified to install, make electrical connections and maintain ventilation units. Do not attempt to install the product, connect it to the mains, or perform maintenance yourself. This is unsafe and impossible without special knowledge.
-
Page 5: Purpose
Name Number 1 pc. User’s manual 1 pc. Packing box 1 pc. DESIGNATION KEY Tower-AM 150 (220/60) Power supply parameters other than 220 V/50 Hz (Voltage/Frequency) Impeller diameter [mm] Fan designation: Tower-AM — centrifugal roof fan with a round cover. -
Page 6: Technical Data
TECHNICAL DATA Tower-AM Dimensions [mm] Weight Model [kg] Tower-AM 150 Tower-AM 200 Tower-AM 250 10,1 Tower-AM 315 12,3 D — flange connection dimensions. -
Page 7: Mounting And Set-Up
tower-aM www.blaubergventilatoren.de MOUNTING AND SET-UP BEFORE MOUNTING MAKE SURE THE CASING DOES NOT CONTAIN ANY FOREIGN OBJECTS (E.G. FOIL, PAPER). WHILE INSTALLING THE UNIT ENSURE CONVENIENT ACCESS FOR SUBSEQUENT MAINTENANCE AND REPAIR. The fan is designed for mounting on a roof directly above a ventilation shaft or an air duct. The installation procedure and installation sequence are shown below. -
Page 8: Connection To Power Mains
tower-aM www.blaubergventilatoren.de CONNECTION TO POWER MAINS DISCONNECT THE POWER SUPPLY PRIOR TO ANY OPERATIONS WITH THE UNIT. CONNECTION OF THE UNIT TO POWER MAINS IS ALLOWED BY A QUALIFIED ELECTRICIAN WITH A WORK PERMIT FOR THE ELECTRIC UNITS UP TO 1000 V AFTER CAREFUL READING OF THE PRESENT USER’S MANUAL. - Page 9 Recommended cable, n x S, where n is a number Automatic circuit breaker Model of the cable conductors and S is the cable cross rated current [A] section [mm²] Tower-AM 150...250 3x0,5 ~230 V Tower-AM 315 3x0,5 РЕ 50 (60) Hz...
-
Page 10: Technical Maintenance
tower-aM www.blaubergventilatoren.de TECHNICAL MAINTENANCE DISCONNECT THE UNIT FROM POWER SUPPLY BEFORE ANY MAINTENANCE OPERATIONS! MAKE SURE THE UNIT IS DISCONNECTED FROM POWER MAINS BEFORE REMOVING THE PROTECTION. PRIOR TO COMMENCING ANY TECHNICAL MAINTENANCE PUT UP A PROHIBITORY SIGN ON THE FAN STARTING PANEL: “DO NOT SWITCH ON! MEN AT WORK!”... -
Page 11: Troubleshooting
tower-aM www.blaubergventilatoren.de TROUBLESHOOTING Problem Possible reasons Elimination The fan will not start. No power supply. Check the mains switch. Check the electrical connections according to the wiring diagram. Jammed motor. Carefully check the fan impeller for possible seizure and eliminate it, if necessary. If the impeller is in order, replace the electric motor. -
Page 12: Storage And Transportation Regulations
tower-aM www.blaubergventilatoren.de The fan supplies less air than Wrong calculation of the ventilation network and Re-calculate the network parameters and select a expected. wrong selection of the fan. matching fan. The network resistance exceeds the design Re-arrange the ventilation network to decrease its calculations. -
Page 13: Manufacturer's Warranty
tower-aM www.blaubergventilatoren.de MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/EU of the European Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and of the Council and CE-marking Council Directive 93/68/EEC. - Page 14 tower-aM www.blaubergventilatoren.de...
-
Page 15: Certificate Of Acceptance
tower-aM www.blaubergventilatoren.de CERTIFICATE OF ACCEPTANCE Unit Type Centrifugal roof fan Model Serial Number Manufacture Date Quality Inspector’s Stamp SELLER INFORMATION Seller Address Phone Number E-mail Purchase Date This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are acknowledged and accepted. - Page 16 www.blaubergventilatoren.de B292EN-01...
