- Page 1 ROOF-MOUNTED SMOKE REMOVAL FAN Tower-SV Tower-SH OPERATION MANUAL...
-
Page 2: Table Of Contents
Tower-SV / Tower-SH www.blaubergventilatoren.de CONTENT Introduction Delivery set Structural designation key Dimensions and basic technical data Safety requirements Mounting and installation guidelines Technical maintenance Connection to power mains Troubleshooting and fault handling Storage requirements Manufacturer’s warranty Warranty limitation Warranty card... -
Page 3: Introduction
Tower-SV / Tower-SH www.blaubergventilatoren.de INTRODUCTION The present user manual contains the product description, technical data, operation, installation and mounting guidelines for the roof-mounted smoke removing fan Tower-S. Tower-S fan is a component unit of emergency smoke removing exhaust ventilation systems designed for forced removal of smoke, hot gases and heat that are emitted beyond the serviced premise in case of fire in manufacturing, public, administrative and other non-residential premises. -
Page 4: Structural Designation Key
Tower-SV / Tower-SH www.blaubergventilatoren.de STRUCTURAL DESIGNATION KEY Tower-S Х ХХХХ–ХХХ–ХХ/ХХХХ-X М - Terminal box included Motor speed [RPM] 730, 950, 970, 1460 Electric motor power [kW] 1.5, 5.5, 3, 7.5, 11, 15, 30 Max. transported air temperature [°C] Impeller diameter [mm] 630, 710, 800, 900, 1000, 1100 Air discharge orientation V - vertical;... - Page 5 Tower-SV / Tower-SH www.blaubergventilatoren.de Tower-SV 800-600-5.5/950 11.5 1154 1040 1543 1178 Tower-SH 800-600-5.5/950 11.5 1154 1040 1238 1178 Tower-SV 800-600-15/1460 11.5 1154 1040 1543 1178 Tower-SH 800-600-15/1460 11.5 1154 1040 1238 1178 Tower-SV 900-600-11/970 11.5 1405 1200 1040 1870 1338 Tower-SH 900-600-11/970 11.5 1405...
- Page 6 Tower-SV / Tower-SH www.blaubergventilatoren.de 4 holes Fig. 1...
-
Page 7: Safety Requirements
Tower-SV / Tower-SH www.blaubergventilatoren.de The fig. 1 shows the model with vertical air discharge Tower-SV and the fig. 2 shows the model with horizontal air discharge Tower-SH. Fig. 2 SAFETY REQUIREMENTS Disconnect the fan from power mains prior to any connection, servicing and repair operations. Mounting and maintenance are allowed for duly qualified electricians with valid electrical work permit for electric operations at the units up to 1000 V after careful study of the present user’s manual. -
Page 8: Mounting And Installation Guidelines
Tower-SV / Tower-SH www.blaubergventilatoren.de MOUNTING AND INSTALLATION GUIDELINES Prior to mounting the fan: read the present user manual carefully. check the fan for any mechanical damages resulted in wrong transportation. rotate the impeller by hand and make sure it has smooth running. Follow the applicable safety rules during set-up and operation of the fan. - Page 9 Tower-SV / Tower-SH www.blaubergventilatoren.de Tower-S fan Mounting frame Side panel Fig. 3 FAN DESIGN Tower-SV Fig.4...
- Page 10 Tower-SV / Tower-SH www.blaubergventilatoren.de Tower-SH Fig. 5 1. Support frame 2. Electric motor 3. Protecting hood 4. Terminal box 5. Side panel 6. Intake spigot 7. Connecting flange 8. Exhaust backdraft damper (only for Tower-SV model) 9. Protecting screen (only for Tower-SH model) 10.
-
Page 11: Technical Maintenance
Tower-SV / Tower-SH www.blaubergventilatoren.de TECHNICAL MAINTENANCE Disconnect the fan from power mains and make sure the rotating parts stand still prior to maintenance and servicing operations. Remember to install a warning plate «Do not turn on! Under operation!» before starting any operations on the fan start panel. The fan maintenance means its regular cleaning from dust and dirt. - Page 12 Tower-SV / Tower-SH www.blaubergventilatoren.de Table 3 Voltage, 50 Hz [A] Automatic circuit breaker 12.5 31.5 rated current [A] Recommended cable, n x S, where n is a number of the cable conductors 4х2.5 4х2.5 4х2.5 4х4 4х2.5 4х10 4х4 4х10 4х4 4х10 4х10...
-
Page 13: Troubleshooting And Fault Handling
Tower-SV / Tower-SH www.blaubergventilatoren.de TROUBLESHOOTING AND FAULT HANDLING Problem Possible reasons. Fault handling Check the automatic circuit breaker. Check the Power supply connection error. electric connections. The fan is not started during start-up. Turn the fan off. Remove the motor jamming. Motor is jammed. -
Page 14: Manufacturer's Warranty
Tower-SV / Tower-SH www.blaubergventilatoren.de MANUFACTURER’S WARRANTY By purchasing this product the customer confirms to have read and agreed to the warranty terms. The manufacturing company sets forth the warranty period (service life) of the product as 24 months following the sale date via retail network subject to the customer’s ensuring compliance with the rules of transportation, storage, mounting and operation of the product. -
Page 15: Warranty Card
Tower-SV / Tower-SH www.blaubergventilatoren.de Manufactured on _____________________________ Model Approval mark___________________________________________________________________________ Sold by _________________________________________________________________________________ (name of trading enterprise, stamp of the shop)_____________________________________________ Date of sale _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ ________________________________________________________________________________________... - Page 16 www.blaubergventilatoren.de B81EN-01...
