SOFTMOUNT INDUSTRIAL WASHER
MODEL S-975 EXPRESS PLUS
ON-PREMISE O-SERIES CONTROL
WARNING - THIS WASHER IS EQUIPPED WITH DEVICES AND FEATURES RELATING TO ITS SAFE
OPERATION. TO AVOID INJURY OR ELECTRICAL SHOCK, DO NOT PERFORM ANY SERVICING UNLESS
QUALIFIED TO DO SO.
IT IS THE RESPONSIBILITY OF THE OWNER TO CHECK THIS EQUIPMENT ON A FREQUENT
BASIS TO ASSURE ITS SAFE OPERATION.
A machine should NOT be allowed to operate if any of the following occur:
-
Excessively high water level.
-
If machine is not connected to a properly grounded circuit.
-
If the door does not remain securely locked during the entire cycle.
-
Vibration or shaking from an inadequate foundation.
WARNING - SAFETY PRECAUTIONS
Do not operate washer before removing the shipping braces.
-
Always shut off power and water supply before servicing.
-
-
Do not overload the washer.
-
Do not open door when cylinder is in motion or it contains water.
-
Do not bypass any safety devices of this washer, including the maximum displacement switch.
-
Do not use volatile or flammable substances in or near this washer.
-
Keep all panels in place. They protect against shock and injury and add rigidity to the washer.
PREVENTIVE MAINTENANCE REQUIREMENTS
DAILY
Check that the loading door remains securely locked and cannot be opened during an entire
-
cycle.
Clean the top, front, and sides of the cabinet to remove residue.
-
Clean the soap dispenser and lid and check that all dispenser mounting screws are in-place and
-
tight.
-
Check the loading door for leaks. Clean the door seal of all foreign matter.
Leave the loading door open to aerate the washer when not in use.
-
QUARTERLY
-
Make sure the washer is inoperative by switching off the main power supply.
Check the suspension springs and dampers for wear. Retighten bolts if necessary.
-
Check the V-belts for wear and proper tension.
-
Clean lint and other foreign matter from around motor.
-
Check all water connections for leaks.
-
Check the drain valve for leaking and that it opens properly.
-
Wipe and clean the inside of the washer and check that all electrical components are free of
-
moisture and dust.
Remove and clean water inlet hose filters. Replace if necessary.
-
Check anchor bolts (if used). Retighten if necessary.
-
IMPORTANT: Replace all panels that were removed to perform daily and/or quarterly maintenance.
8514-305-001 REV PR PAGE 1
OPERATOR'S MANUAL
INSTALLATION & OPERATION
INSTRUCTIONS
Please read this information and retain for reference.
Advertisement
Table of Contents
Related Manuals for Dexter Laundry S-975 EXPRESS PLUS
Summary of Contents for Dexter Laundry S-975 EXPRESS PLUS
- Page 1 SOFTMOUNT INDUSTRIAL WASHER MODEL S-975 EXPRESS PLUS ON-PREMISE O-SERIES CONTROL OPERATOR’S MANUAL INSTALLATION & OPERATION INSTRUCTIONS Please read this information and retain for reference. WARNING - THIS WASHER IS EQUIPPED WITH DEVICES AND FEATURES RELATING TO ITS SAFE OPERATION. TO AVOID INJURY OR ELECTRICAL SHOCK, DO NOT PERFORM ANY SERVICING UNLESS QUALIFIED TO DO SO.
-
