Summary of Contents for Dexter Laundry EXPRESS PLUS S-975
- Page 1 OUT OF BALANCE MANAGEMENT AND EXCESSIVE VIBRATION RESET...
-
Page 2: Out Of Balance Load
OUT OF BALANCE LOAD... - Page 3 OUT OF BALANCE LOAD • During a spin, the message shown to the right may be displayed. • This is a normal message when the washer is attempting to better distribute an out of balance clothes load before accelerating to the full spin speed. You do not need to stop the cycle or reset the washer.
- Page 4 EXCESSIVE VIBRATION RESET...
-
Page 5: Excessive Vibration
EXCESSIVE VIBRATION • If a clothes load is excessively out of balance, the maximum displacement switch could be tripped during operation due to excessive tub movement. This screen indicates that the switch has been tripped and that the washer will need to be reset: Note: You can locate these instructions in the Operator’s Manual on Page 18 linked here: https://www.dexter.com/upl/downloads/products/documents/65c3a027344f131b2b2d8.pdf... - Page 6 EXCESSIVE VIBRATION RESET • To reset the washer, first pull out the black plunger on the switch which is located behind the front panel on the left side of the washer tub. You can access this switch in three ways. Access Points: Black plunger Option 2:...
- Page 7 EXCESSIVE VIBRATION RESET • Then follow the instructions on the display to reset the washer. • Enter the management section by pressing the green start button. Enter the 4-digit management passcode using the arrow keys to change the number and the start button to select each number. After entering the 4 digits, press start to confirm: Start button Start button...
- Page 8 EXCESSIVE VIBRATION RESET • Scroll down using the arrow button to “General Settings” then press the start button: Exit General Settings Start button...
- Page 9 EXCESSIVE VIBRATION RESET • Scroll down using the arrow button to “Excessive Vibration” then press the start button: Start button...
- Page 10 EXCESSIVE VIBRATION RESET • Press the down arrow button to change from “Reset” to “Ready”, then press the start button: Start button...
- Page 11 EXCESSIVE VIBRATION RESET • (1) Press the red stop button to exit this screen. Press the red stop button a second time until the screen below appears. (2) Press the down arrow to change from “Cancel” to “Confirm” and (3) then press the green start button to confirm and save the change: Stop button Start button...
- Page 12 EXCESSIVE VIBRATION RESET • Press stop button to exit this screen. Continue to press the stop button until you have returned to the Ready screen: Stop button...
- Page 13 EXCESSIVE VIBRATION RESET • The washer may display the red Excessive Vibration screen a second time. If so, please repeat the previous steps on the screen to reset the washer. You will not need to physically reset the plunger on the switch a second time.
