O-Series OPL Express Washers
WN0650, WN0750, WN0950, &
WN1450 (Express Washers 200G)
Parts & Service Manual
Sta
Starting Serial # W1.
8533-110-001 11/20

Advertisement

Table of Contents
loading

Related Manuals for Dexter Laundry O Series

Summary of Contents for Dexter Laundry O Series

  • Page 1 O-Series OPL Express Washers WN0650, WN0750, WN0950, & WN1450 (Express Washers 200G) Parts & Service Manual Starting Serial # W1. 8533-110-001 11/20...
  • Page 2 Equipment Safety Warnings Symbols and Terminology Used in this Equipment Indicates an imminently hazardous situation, which if not avoided, will result in death or serious injury. Indicates a potentially hazardous situation, which if not avoided could result in death or serious injury. Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
  • Page 3 Equipment Safety Warnings Symbols and Terminology Used in this Equipment Warning! Do not operate equipment if door glass is damaged in any way. Warning! Keep clear of rotating parts. Prohibited! Do not enter this equipment or space. Prohibited! Do not step or stand on this equipment. Prohibited! Do not operate without all guards and covers in place.
  • Page 4 Indicates an imminently hazardous situation, which if not avoided, will result in death or serious injury. Indicates a potentially hazardous situation, which if not avoided could result in death or serious injury. Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
  • Page 5 WARNING • All washers must be installed in accordance to all ap- plicable electrical, plumbing and all other local codes. • These installation and operation instructions are for use by qualified personnel only. To avoid injury and electri- cal shock, do not perform any servicing other than that con- tained in the installation and operation instructions, unless qualified.
  • Page 6 WARNING Children should be supervised to ensure they do not operate or play in or around equipment. Keep all panels in place to protect against electrical shock and injury and add rigidity to washer. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their...
  • Page 7 Warning! Do not operate equipment if door glass is dam- aged in any way. Warning! Keep clear of rotating parts. Prohibited! Do not enter this equipment or space. Prohibited! Do not step or stand on this equipment. Prohibited! Do not operate without all guards and covers in place.
  • Page 8 Prohibited! Do not attempt to open, touch, or proceed be- fore referring to the manual or unless qualified. Mandatory! Read all supporting documentation before oper- ating or maintaining equipment. Mandatory! Disconnect power before servicing equipment. Mandatory! Lock out and tag out before servicing this equipment.
  • Page 9 Notes Part # 8533-110-001 11/20...

  • Page 10: Table Of Contents

    Dexter Safety Guide- Table of Contents lines Section 1: Machine Mounting & Installation WARNING T-650 ..............14 T-750 ..............15 T-950 ..............15 These washers are equipped with devices and T-1450 ............... 16 features relating to their safe operation. To avoid injury or electrical shock, do not perform and service, unless T-650 Installation ..........
  • Page 11 Section 7: Drain Valve Cleaning ........54 Detergent Dispenser .........54 Machine Electrical & Wiring Schematics Vacuum Breaker / Air Gap ........55 Start Circuit ............72 Water Valves .............55 Fill Circuit ............73 Door Lock Assembly Operation......55 Wash Circuit ............73 Adjustment for the Door Lock Drain, Rinse 1 &...
  • Page 12 Section 10: Electric Heated 60 Hz Models -13 Parts............139-141 Diagrams & Schematics......142-145 Section 11: Electric Heated 50 Hz Models -68 Parts............147-149 Diagrams & Schematics......150-153 Section 12: Maintenance Preventative Maintenance ......156 Part # 8533-110-001 11/20...
  • Page 13 Section 1: Machine Mounting Part # 8533-110-001 11/20...
  • Page 14 Specifications for below models are outlined in this book: T-650 WN0650XB-12EO 208-240 volts 60hz Single Phase or Three Phase T-750 WN0750XB-12EO 208-240 volts 60hz. Single Phase or Three Phase T-950 WN0950XB-12EO 208-240 volts 60hz Single Phase or Three Phase T-1450 WN1450XB-12EO 208-240 volts 60hz Single Phase or Three Phase...
  • Page 15 T-750 Machine Dimensions T-950 Machine Dimensions Part # 8533-110-001 11/20...
  • Page 16 T-1450 Machine Dimensions Part # 8533-110-001 11/20...
  • Page 17 T-650 Mounting Dimensions        Part # 8533-110-001 11/20...
  • Page 18 T-750 Mounting Dimensions CONCRETE PEDESTAL MOUNTING FLOOR OUTLINE Figure 1-1 Figure 1-2 Part # 8533-110-001 11/20...
  • Page 19 T-950 Mounting Dimensions CONCRETE PEDESTAL MOUNTING FLOOR OUTLINE Figure 1-1 Figure 1-2 Part # 8533-110-001 11/20...
  • Page 20 T-1450 Mounting Pad Dimensions Part # 8533-110-001 11/20...
  • Page 21 Notes Part # 8533-110-001 11/20...
  • Page 22 Notes Part # 8533-110-001 11/20...

  • Page 23: Installation

    Section 2: Machine Installation & Operating Instructions Part # 8533-110-001 11/20...
  • Page 24 Allow a minimum 24 inches (610 mm) of clearance behind the rear of the machine to provide access for motor service. Contact a Dexter laundry equipment distributor for recommended steel mounting bases. If an elevated concrete pedestal is desired, it should be embedded into the existing floor. See Machine Mounting Detail Figures for floor thickness and bolt sizes.
  • Page 25 If power is 400V-3PH-50Hz, connect L1, L2, L3, N, and Earth. If there is a high leg, it must NOT be connected to L1 or L2. However, failure due to a voltage surge on the high leg is not covered by equipment warranty. Contact Dexter Laundry with any questions. (Only Heated Washers may be connected to 400V-3PH power).
  • Page 26 60 HZ CONTROL TRANSFORMER CONNECTIONS NOTE: transformer must be set at proper tap for proper operation. The controls transformer is located inside the control trough and steps a range of 208 to 240 volts down to 115VAC and 24VAC. There are two terminals on the controls transformer for the primary (incoming) power.
  • Page 27 INJECTION SOURCE CONNECTIONS The washer control may be programmed to send ten 120VAC output signals for 60Hz models (or 24VAC for 50Hz) for a chemical injection system. The signals are not intended as a power source and must be limited to less than 100 milliamps of current. There is a separate terminal block for connection of the external injection signals.
  • Page 28 OPERATING INSTRUCTIONS STARTING THE WASHER 1) Turn on power to the washer. A)Load the laundry. Place laundry into the cylinder and latch the door securely. Be sure laundry does not get caught between the door gasket and tub front when closing the door. Maximum load is the dry weight capacity listed in the specification sheet.
  • Page 29 EMERGENCY STOP / SAFETY DOOR LOCK This machine is equipped with a safety door lock that locks the door when the cycle is started until the cycle is complete. The door lock prevents opening the door for up to 3 minutes if the power is interrupted during the cycle.
  • Page 30 Injection Source Details Detergent Measurements The washer control may be programmed to send output By Washer Model signals for a chemical injection system. There is a separate terminal block for connection of the external injection sig- nals. For the injection sources, program codes 0 through 6 are as shown in the table below.
  • Page 31 Notes Part # 8533-110-001 11/20...
  • Page 32 Notes Part # 8533-110-001 11/20...

  • Page 33: Machine Programming Instructions

    Section 3: Machine Programming Instructions Part # 8533-110-001 11/20...
  • Page 34 O-SERIES WASHERS PROGRAMMING WITH DEXTERLIVE Our O-Series washers are simple and easy to program with DexterLive.com. This guide will provide an overview of some of the features DexterLive offers and how to create the cycles that fit your location’s specific needs. Set-Up an Account and Location If you don’t already have a DexterLive account, it is easy to register at DexterLive.com.
  • Page 35 General Settings General settings will set the global parameters for your location. These parameters will impact all washers and dryers added to that location. Setting Options Notes Machine Display Language Multiple Changes the language of cycles, stages, and prompts that are displayed on the control. Individual cycles can still be set for different languages.
  • Page 36 Cycles The cycle page allows you to add, edit, copy, delete, or reorder cycles. Legend Edit Cycle Select anywhere on the cycle description (cycle name, target temp, material, or target) to open the cycle details for editing. Reorder Select and hold to move a cycle up or down in the listing. This will Cycle change the order it is displayed on the control.
  • Page 37 Cycle Settings A cycle can be edited by clicking on the cycle name in the Cycles page. The name and language can be customized for that specific cycle. Changing the language for a cycle will change the status, stage names, and prompts displayed during that particular cycle. Tip: If a location has multi-lingual employees, the same cycle can be duplicated and programmed for different languages.
  • Page 38 Soak Time 0 – 60 minutes Time from when fill is complete to when agitation begins. Agitation Time 0 – 30 minutes Time load will tumble. Bath Agitation Type Normal Aggressiveness of the tumble Delicate action. Tip: For wet clean or super- Custom 1-3 delicate applications, create your own custom agitation type in the...
  • Page 39 Optional Settings These settings will only apply to that specific model type. For instance, optional settings for the T-950 will not apply to a T-650. These will need to be set individually by model. Custom Agitation DexterLive has the ability to create 3 custom agitation types. These custom agitations will enable you to create cycles such as a wet clean cycle with “rocking”...
  • Page 40 Tip: See example below for how a custom agitation can be used to create a wet clean cycle. Example: Wet Clean Parameter Stage 1: Stage 2: Stage 3: Stage Stage 5: Stage 6: Prewash Soak Soak 4: Soak / Rinse Final Rinse Wash Temperature...
  • Page 41 Programming Once all cycles are set, the programming file (called userconfig.xml) can be downloaded following the instructions on the programming tab DexterLive.com. At the machine, you can enter management view by pressing up on the idle screen. Simply insert the USB, scroll to Import User Data, and begin using your customized washer cycles. Part # 8533-110-001 11/20...
  • Page 42 Notes Part # 8533-110-001 11/20...

  • Page 43: Trouble Shooting

    Section 4: Trouble Shooting Part # 8533-110-001 11/20...

  • Page 44: Common Troubleshooting Solutions Pages

    Common Troubleshooting Solutions Symptom Probable Cause Suggested Remedy Machine Power Supply Check these areas: Circuit breakers, Voltage, Power leads, does not Power connections. Is front display LED display lit? start Door Switch Check for continuity through door switch when door is closed.
  • Page 45 Symptom Probable Cause Suggested Remedy Hot water Water Valve Coil Check coil continuity at terminals and replace if no continuity. does not Check for 120 VAC power (60 Hz) from main relay PCB. (24 VAC enter tub in for 50 Hz models) wash Water Inlet Check water inlet screens for blockage and clean if necessary...
  • Page 46 Common Troubleshooting Solutions Symptom Probable Cause Suggested Remedy Machine Check VFD by removing inspection panel and record any does not numbers or letters displayed. If no display turn power off to turn machine at breaker for 2 minutes and turn power back on to reset.
  • Page 47 Fault# Description Customer Action HEAT_RISE_OUT_OF_ Operating temperature is above Check operating thermistor RANGE (target temperature + upper hysteresis) and above 220F (104C) NO_HEAT_RISE Operating temperature is Check operating thermistor below (target temperature + Check gas lower hysteresis) and operating Check combustion temperature has not increased by 2F in 15 minutes PROX_SENSOR_OUT_...

  • Page 48: Errors

    Fault# Description Customer Action OH_THERMISTOR_ There is an open circuit across Check OH Thermistor OPEN the OH thermistor terminals or connections the measured temperature is Check OH Thermistor below -33 degrees F (above 310 resistance Mohms) DRIVE_ Failure to reset VFD, communication Check VFD cable COMMUNICATION_ retry failure over 3 times...
  • Page 49 Fault# Description Customer Action PORT_EXP_INIT Could not initialize port Check I2C connections expander(s) PORT_EXP_READ Could not read port expander Check I2C connections PORT_EXP_SET Could not set output on port Check I2C connections expander PORT_EXP_OLAT Could not latch output on port Check I2C connections expander Check voltage on output...
  • Page 50 Fault# Description Customer Action SLOW_DRAIN_ Water level has not reached Check water drain ERROR empty level when draining for 5 Check drain valve minutes Check drain valve relay Check pressure sensor INVALID_FILL Fill type specified does not match Contact software available types engineering.
  • Page 51 Drive Motor Inverter Type Motor-Winding Resistance Chart T-650 O-Series Express Washer Resistance Motor Winding Wire # Minimum Maximum T-650 1PH or 3PH 60Hz Main (wash & spin) T1 & T2 2.25 2.61 Dexter #9376-319-001 T2 & T3 2.25 2.61 T1 & T3 2.25 2.61 T-750 O-Series Express Washer...
  • Page 52 Notes Part # 8533-110-001 11/20...

  • Page 53: Machine Service Procedures

    Section 5: Machine Service Procedures Part # 8533-110-001 11/20...

  • Page 54: Top Panel Removal

    Top Panel Removal Top Soap Dish Step 1: Remove 4 screws that hold detergent dispenser to top panel. (for T-750, T-900, T-950) Step 2: Unlock top panel lock. Step 3: Raise top panel, slide to the rear to release from back clips and lift off. Top Panels Removal Front Soap Dish Step 1: Unlock top panel locks.

  • Page 55: Water Valves

    Vacuum Breaker (also called an air gap) In the left rear of the cabinet is the vacuum breaker. It guides the water to the tub and dispenser and prevents a back flow of water. Water Valves Remove top panel to access water valves. (see Removing Top Panel) The two dual outlet water and/or single coil valves are mounted to the rear channel with two screws each.
  • Page 56 Door cam Flat blade screw on door check position switch latching Step 3: With switch actuator bracket adjusted you Step 4: Check for switch actuation at partial will now need to adjust single switch by turn of cam as in operation above. Door loosening 2 flat blade screws and allowing handle goes from horizontal to six o’clock swivel of switch.

  • Page 57: Adjusting The Loading Door

    Adjusting the Loading Door The door can be adjusted by changing the number of shims behind the door hinge and the door lock assembly. The vertical fit of the door to the tub can be altered by loosening the door hinge bolts and raising or lowering the door before retightening.

  • Page 58: Loading Door Disassembly

    Loading Door Disassembly Step 1: Remove the loading door Step 2: While holding down on Step 3: Work all the way around as outlined above. Lay the door glass, lift up the gasket and the glass the door on a flat surface on the door ring and roll is out.

  • Page 59: Thermoactuators

    Door Locking Gear Motor Assembly The door locking gear motor is rotated shut with control voltage to lock the door and releases when voltage is removed. It is located in the left front corner of the washer. (Original locking solenoid models can be converted to the new assembly) Thermoactuators Door Lock Gear Motor...
  • Page 60 Cylinder (basket) Step 1: Remove the top panel as described previously. Step 2: Remove lower service panel as described previously. Step 3: Remove front panel as described previously. Step 4: Remove masking ring as described previously. Step 5: Remove door lock assembly. (Leave wires & pull rod in place) Step 6: Remove clothes door.
  • Page 61 Water Seals Replacement Step 1: Remove cylinder from washer (see Cylinder (basket) removal). Step 2: Remove water seals from the seal mounting plate on Guard Ring & Mating Ring the cylinder shaft. These are removed with your fingers. Step 3: The primary and secondary seals that mount on the sealing ring may be slid over the shaft and seated on the metal sealing ring with your fingers.
  • Page 62 Reassembly of the Cylinder Step 1: Use the hub of the drive pulley, a stack of 5/8” flat washers and a 3” long 5/8” bolt to pull the cylinder shaft through the bearings. After the 3” bolt a 2” long bolt will be required to finish pulling the cylinder shaft through.

  • Page 63: T-650 Bolt Torque Chart

    T-650 Bolt Torque Chart Bolt Size Where Used Torque 1/2”x 1 1/4” bolt Tub End of Bearing Hsing. 9545-017-009 70-110 ft/lbs 5/8”x 1 1/2” bolt Tub End of Bearing Hsing. 9545-060-001 120-150 ft/lbs 1/2”x 1 1/4” bolt Mtg. of Tub to Cradle Asy. 9545-017-009 70-110 ft/lbs 5/8”x 2 1/2”bolt Mtg.
  • Page 64 Notes Part # 8533-110-001 11/20...
  • Page 65 Section 6: Service Electrical Components Part # 8533-110-001 11/20...

  • Page 66: Control Mounting Trough

    Control Mounting Trough Remove top panel to access control trough. It sets on the right side of the machine and holds the control PCB’s, transformers, and pressure switch. Main Data Communication Cable Goes between front PCB board and Variable Frequency Drive unit mounted center rear of machine. It has telephone type connectors at each end and is inserted at Controller PCB and the Variable Frequency Drive.

  • Page 67: Power Connection Terminal Block

    Power Connection Terminal Block This terminal block sets at the very back of the control trough. Incoming power to the washer should connect here. (see Electrical under Installation and Operation Section for exact connections) Rear Delta Variable Frequency Drive: Main power is connected to terminals L1, L2, and L3 on the Delta drive. If the washer is connected to a three phase source, there should be voltage present on all three terminals.
  • Page 68 Pressure Sensor Electronic The Electronic Pressure Sensor comes standard on all models. The Pressure sensor is adjustable. The Level Chart Factory settings chart will let you know the starting values for each machine and by following the Switch position chart you can adjust the water levels in 1/4 inch increments from that starting value. ...
  • Page 69 Water Level C                                      ...
  • Page 70 Notes Part # 8533-110-001 11/20...
  • Page 71 Section 7: Electrical Wiring Diagrams & Schematics Part # 8533-110-001 11/20...

  • Page 72: Start Circuit

    Electrical Path Circuit Schematics Start Circuit Power travels into the machine on L1, L2, and (L3 if 3 phase used). Power from the L1 & L2 supplies power to the 12VDC power supply. This power being sent to the Control PCB. 115VAC, 24VAC, and the VAC Neutral is cre- ated by the control transformer.

  • Page 73: Fill Circuit

    Agitation Circuit When the 12VDC signal closes the K5 in the Control PCB it closes the loop in the yellow wire from the VFD terminal MI6 back to the DCM on the white/yellow through the stop button. This enables the Drive to operate and allow motion.

  • Page 74: Extract Circuit

    Level Achieved / Stage Completion / Drain When the water level in the basket reaches the preset level pressure, the switch moves it's switch contacts to the full or closed position. This causes the main control PCB to signal the relay PCB to shut off the water valve coils.
  • Page 75 Notes Part # 8533-110-001 11/20...
  • Page 76 WN0650XB-12EO1 Schematic Part # 8533-110-001 11/20...
  • Page 77 WN0650XB-12EO1 Diagram Part # 8533-110-001 11/20...
  • Page 78 WN0650XB-12EO2 Schematic Part # 8533-110-001 11/20...
  • Page 79 WN0650XB-12EO2 Diagram Part # 8533-110-001 11/20...
  • Page 80 WN0750XB-12EO1 Schematic Part # 8533-110-001 11/20...
  • Page 81 WN0750XB-12EO1 Diagram Part # 8533-110-001 11/20...
  • Page 82 WN0750XB-12EO2 Schematic Part # 8533-110-001 11/20...
  • Page 83 WN0750XB-12EO2 Diagram Part # 8533-110-001 11/20...
  • Page 84 WN0950XB-12EO1 Schematic Part # 8533-110-001 11/20...
  • Page 85 WN0950XB-12EO1 Diagram Part # 8533-110-001 11/20...
  • Page 86 WN0950XB-12EO2 Schematic Part # 8533-110-001 11/20...
  • Page 87 WN0950XB-12EO2 Diagram Part # 8533-110-001 11/20...
  • Page 88 WN1450XB-12EO1 Schematic Part # 8533-110-001 11/20...
  • Page 89 WN1450XB-12EO1 Diagram Part # 8533-110-001 11/20...
  • Page 90 WN1450XB-12EO2 Schematic Part # 8533-110-001 11/20...
  • Page 91 WN1450XB-12EO2 Diagram Part # 8533-110-001 11/20...
  • Page 92 Notes Part # 8533-110-001 11/20...

  • Page 93: Parts Data

    Section 8: Parts Data WN0650XB-12EO 208-240 Volts 60 Hz Single Phase or Three Phase WN0750XB-12EO 208-240 Volts 60 Hz Single Phase or Three Phase WN0950XB-12EO 208-240 Volts 60 Hz Single Phase or Three Phase WN1450XB-12EO 208-240 Volts 60 Hz Single Phase or Three Phase Part # 8533-110-001 11/20...
  • Page 94 C-Series OPL Accessories WN0650XA-12EO 208-240 Volts 60 Hz Single Phase or Three Phase WN0750XA-12EO 208-240 Volts 60 Hz Single Phase or Three Phase WN0950XA-12EO 208-240 Volts 60 Hz Single Phase or Three Phase WN1450XA-12EO 208-240 Volts 60 Hz Single Phase or Three Phase Description T-650 T-750...

  • Page 95: Wiring Harness Part # By Model

    Wiring Harness Part # by Model Description T-650 T-750 T-950 T-1450 Cableassy-usb,snapin 9806-024- 9806-024- 9806-024- 9806-024- Cableassy-data,rs485,40" 9806-023- 9806-023- 9806-023- 9806-023- Wiringharness-doorlock 9627-936- 9627-936-001 9627-936-001 9627-936- Wiringharn-pwrtermblk/VFD/ps 9627-932-001 9627-932-001 9627-932-001 9627-932-001 Wiringharnes-15pin,injection 9627-935-001 9627-935-001 9627-935-001 9627-935-001 Wiringharness-15pin,non-inj 9627-934-001 9627-934-001 9627-934-001 9627-934-001 Wireasy-blu,17"...

  • Page 96: Cabinet And Front Panel Group Part # By Model

    Cabinet and Front Panel Group Part # by Model Large Door Description T-650 T-750 T-950 T-1450 Panel, Side- stainless 9989-644-001 9989-645-001 Panel, Side- stainless 9989-644-002 9989-645-002 9454-839-001 9454-836-001 Bolt-1/4-20x1/2 (side panel Front to Rear) 9545-018-013 9545-018-013 9545-018-013 Nut 1/4-20UNC (side panel) 8640-414-006 8640-414-006 8640-414-006...
  • Page 97 15,16 15,16 Description T-650 T-750 T-950 T-1450 Screw Mtg., Flat Head 10Bx1 3/4 9545-008-014 9545-008-014 9545-008-014 9545-008-014 Washer, Finish 8641-585-001 8641-585-001 8641-585-001 8641-585-001 Nut, Spring 8640-399- 8640-399- 8640-399- 8640-399-008 Key, Top- # 6324 6292-006-007 6292-006-007 6292-006-007 6292-006-007 Washer Flat 5/16 8641-581-008 8641-581-008 8641-581-008...

  • Page 98: Soap Dish

    Cabinet and Front Panel Group Part # by Model Front Soap Dish 4, 5 Gasket and Soap Dish Tub Front Here Here Part # 8533-110-001 11/20...
  • Page 99 Top Mount Detergent Dispenser Description T-650 T-750 T-950 T-1450 Dispenser Soap 9122-005- 9122-005- 9122-005-004 Gasket Dispenser 9206-416- 9206-416- 9206-416-001 Hose, Dispenser to tub 9242-450- 9242-450- 9242-450-001 Clamp 8654-117-008 8654-117-008 8654-117-008 Nut, Spring ss 8640-399- 8640-399- 8640-399-007 Flow resistors 9475-002- 9475-002- 9475-002-002 Flow resistors Optional (Smaller) 9475-002-...
  • Page 100 Front Mount Detergent Dispenser Description T-650 T-750 T-950 T-1450 Bolt,#10-32 x 1 1/4”SS 9545-012-026 Special Washer, Rubber 8641-222-000 Tub Front 9974-012-001 Washer-Flat, 1/4 8641-581-018 Nut, #10-32UNF 8640-413-002 Spacer Plastic #10x1/2 Soap Dispenser (no lid) 9807-087-001 Det. Dispenser Mtg Gasket to Tub frnt 9206-425-001 Bracket Soap box mounting 9029-122-002...

  • Page 101: Rear View Access Part # By Model

    Rear View Access Part # by Model Description T-650 T-750 T-950 T-1450 Drive Motor, 3 Phase (Inverter duty) 9376-319-001 9376-329-001 9376-329-001 9376-328-001 Rod, Motor Mtg 9497-222-004 9497-222-004 9497-222-004 9497-222-004 Collar, Shaft (w/set screws) 9076-052-002 New motor bushing support 9053-082-001 9053-082-001 9053-082-001 9053-082-001 Clamp for motor bushing...
  • Page 102 10,11 12,13,14 10,11 12,13,14 Description T-650 T-750 T-950 T-1450 Hose-Overflow 9242-449- 9242-449- 9242-449-003 9242-449- Clamp Hose Over Flow 8654-117-018 8654-117-018 8654-117-018 8654-117-018 Drain Valve 9379-202-001 9379-202-001 9379-202-001 9379-202-001 Hose, Drain Valve to Tube 9242-464- 9242-456- 9242-459-001 9242-459- Clamp 8654-117-014 8654-117-014 8654-117-014 8654-117-014 Hose-drainvalve,outlet...

  • Page 103: Rear Channel

    Rear Channel Parts Group Description T-650 T-750 T-950 T-1450 Channel Assembly Rear 9947-032-001 9947-027-001 9947-028-001 9947-029-001 Screw #10Bx1/2 9545-008-026 9545-008-026 9545-008-026 9545-008-026 Nut, Spring 8640-399-008 Plug, 7/8” 9456-041-006 9456-041-006 9456-041-006 Bushing, 7/8” 9053-067-002 9053-067-002 9053-067-002 Bracket-Terminal Block Assy 9029-265-001 9029-265-001 9029-265-001 9029-265-001 Screw, 10Bx1/2...
  • Page 104 Description T-650 T-750 T-950 T-1450 Vacuum Breaker 9610-001- 9610-001- 9610-001- 9610-001- Bracket-Vacuum Breaker 9029-077-001 9029-077-001 9029-077- 9029-266- Vacuum Breaker Cap 0935-135-002 0935-135-002 0935-135- 0935-135- Screw, 10Bx1/2 9545-008-026 9545-008-026 9545-008- 9545-008- Clamp, Vacuum Breaker End 8654-117-014 8654-117-014 8654-117- 8654-117- Hose, Vacuum Breaker to Tub Injection Tube 9242-461-001 9242-461-001 9242-461- 9242-461- Part # 8533-110-001 11/20...

  • Page 105: Cylinder, Seals & Bearings Part # By Model

    Cylinder, Seals & Bearings Part # by Model Key Description T-650 T-750 T-950 T-1450 Housing, Bearing- Assembly (items #2-#6) 9803-187-001 9803-187-001 9803-187-001 9803-209-001 Housing, Bearing 9241-181-004 9241-181-004 9241-181-004 9241-195-003 Bearing, Front (LARGE) 9036-159-005 9036-159-005 9036-159- 9036-162-002 Bearing, Rear (SMALL) 9036-159-006 9036-159-006 9036-159- 9036-162-001...
  • Page 106 19,20 21,22,23,24 11 G 12,13 14,15,16,17 Description T-650 T-750 T-950 T-1450 Cylinder Assy 9848-145-001 9848-136-002 9848-136-001 9848-141-001 Tub Front 9974-014-002 9974-011-001 9974-011-001 9974-012-001 Gasket, Tub Front 9206-421-004 9206-421-002 9206-421-002 9206-421-003 Ring Assy, Tub Mtg-Front Clamp 9950-063-001 9950-055-001 9950-055-001 9950-061-001 Bolt, Top Front Ring 3/8”-16 x 3” 9545-029-009 9545-029-009 9545-029-009 9545-029-009...
  • Page 107 Door Lock Assembly (All Models) Description All Models Description All Models Lock Assy, Complete (#1-22) 9885-031-001 Ring, Retaining 9487-200-005 (includes #1 thru #22) Washer 8641-581-031 Plate Assy, Door Lock 9982-346-001 Switch, Latching Sensing 9539-461-008 Washer, Flat (SS or Brass) 8641-581-030 Shield, Switch 9550-169-003 Actuator, Latching Switch...
  • Page 108 Gear Motor Door Lock Assembly Description T-650 T-750 T-950 T-1450 Actuator Assembly (Includes 1-10, Rod NOT 9892-015-003 9892-015-003 9892-015-003 9892-015-003 included) Screw Pnhdcr, 10-32 UNFx0 .75 9545-012-029 9545-012-029 9545-012-029 9545-012-029 Cross Recessed Pan Hd Tapping screw 9545-031-011 9545-031-011 9545-031-011 9545-031-011 Screw -Hxwshrhdslsems, 6-32 x 3/16 9545-044-003 9545-044-003...
  • Page 109 Large Door & Hinge Group Description T-650 T-750 T-950 T-1450 Door Hinge Assembly (mounts to tub front) 9955-030-001 9955-031-001 9955-031-001 9955-031-001 Door Assembly Complete 9960-309-001 9960-310-001 9960-310-001 9960-310-001 Door Ring 180 degree large hinge 9487-265-002 9487-275-001 9487-275-001 9487-275-001 Door Gasket 9206-419-001 9206-431-001 9206-431-001...
  • Page 110 Description T-650 T-750 T-950 T-1450 Shaft Assembly (includes 11-13) 9913-136-001 9913-136-001 9913-136-001 9913-136-001 Shaft, Door Locking 9537-195-002 9537-195-002 9537-195-002 9537-195-002 Cam, Locking 9095-051- 9095-051- 9095-051- 9095-051- Pin, Groove (1 1/4) 9451-181-005 9451-181-005 9451-181-005 9451-181-005 Pin, Groove (3/4) 9451-181-004 9451-181-004 9451-181-004 9451-181-004 Spring, Lock Cam 9534-360-...
  • Page 111                    Top Soap Box 4 Valve Design Top Soap Box Design  Part # 8533-110-001 11/20...

  • Page 112: Water Inlet Part # By Model

    Water Inlet Part # by Model Description T-650 T 750 T-950 T-1450 Injector Assembly 9883-005-001 9883-005-001 9883-012-001 9885-011-001 Valve, Water Inlet (dual outlet) (see Water 9379-183-012 9379-183-012 9379-183-012 9379-183-012 Inlet Valve Breakdown for individual parts) Screw, Valve Mtg 9545-008-026 9545-008-026 9545-008-026 9545-008-026 Valve Water Inlet (single outlet)

  • Page 113: Water Inlet Valve Breakdown

    Water Inlet Valve Breakdown Part # by Model Description T-650 T-750 T-950 T-1450 Valve, Water Inlet (includes 1 thru 6) 9379-183-012 9379-183-012 9379-183-012 9379-183-012 Screen, Inlet end of valve 9555-056-001 9555-056-001 9555-056-001 9555-056-001 Coil Assy., 120 V Invensys 9089-017-001 9089-017-001 9089-017-001 9089-017-001 Diaphragm Invensys (EPDM)
  • Page 114 Description T-650 T-750 T-950 T-1450 Single Coil Water Valve Muel- 9379-194-001 9379-194-001 Valve Water Body Complete 9379-194-002 9379-194-002 (no coil) Diaphragm Mueller 9118-055-001 9118-055-001 Filter Mueller 9183-046-001 9183-046- Coil Mueller 9089-051-001 9089-051-001 Part # 8533-110-001 11/20...

  • Page 115: Drain Valve Group Part # By Model

    Drain Valve Group Part # by Model Key Description Part Number Valve, Drain (includes #2 thru #11 9379-202-001 Body, Valve (w/ball) 9064-072-001 Motor & Gear Train (complete) 9914-137-023 Plate, Motor Mtg 9452-538-001 Screw 8639-994-001 Spring, Drive 9534-339-001 Screw 9545-054-001 Screw 9545-054-002 Seal, V Packer 9532-134-001...

  • Page 116: Chassis And Drain Part # By Model

    Chassis and Drain Part # by Model Key Description T-650 T-750 T-950 T-1450 Base Assy,Frame 9945-143-002 9945-112-002 9945-155-002 9945-133-002 Outer Tub Assy. 9930-169-001 9930-148-002 9930-158-001 9930-155-001 Tub & Cylinder Assy. 9869-035-004 9869-025-005 9869-027-004 9869-026-001 Tub Front 9974-014-002 9974-011-001 9974-011-001 9974-012-001 Gasket, Tub Front 9206-421-004 9206-421-002...
  • Page 117 7, 8, 9 Part # 8533-110-001 11/20...
  • Page 118 Description T-650 T-750 T-950 T-1450 Contrlsasy-trgh, opl,60hz 9857-243-001 9857-244-001 9857-245-001 9857-246-001 Troughassy-control 9839-019-001 9839-019-001 9839-019-001 9839-019-001 Transformer-dualsecondary 8711-017-001 8711-017-001 8711-017-001 8711-017-001 Screw-hxwshrhdundct,#10bx1/2 9545-008-026 9545-008-026 9545-008-026 9545-008-026 Lockwasher-exttooth,#10 8641-582-006 8641-582-006 8641-582-006 8641-582-006 Terminalblockassembly-power 9897-026-005 9897-026-005 9897-026-005 9897-026-005 Screw-panhdcr,#8abx1/2 9545-045-012 9545-045-012 9545-045-012 9545-045-012 Wiringharn-ctrl,graph,can,wshr 9627-922-002...

  • Page 119: Electrical Components - Top Compartment

    Electrical Components - Top Compartment Part # 8533-110-001 11/20...
  • Page 120 Description T-650 T-750 T-950 T-1450 Panel Control Assembly(panel only) 9989-599-001 9989-600-001 9989-600-001 9989-601-001 Screw-Hxwshrhdundct #10Bx 1/2”(Control Panel 9545-008-026 9545-008-026 9545-008-026 9545-008-026 To side Panel) Plate -Latch, Top 9452-625-001 9452-625-001 9452-625-001 9452-625-001 Nut Hexkeps #8-32 8640-412-005 8640-412-005 8640-412-005 8640-412-005 Post-locator,top 9467-024-001 Nut-hexkeps,#6-32 8640-411-003 Locator Panel...

  • Page 121: Control Panel Part # By Model

    Control Panel Part # by Model Part # 8533-110-001 11/20...
  • Page 122 Labels and Diagrams All O-Series Models Description T-650 T-750 T-950 T-1450 Operators Manual 8514-290-001 8514-290-001 8514-290-001 8514-290-001 Wiringlabel-diagram/inform 9507-011-001 9507-013-001 9507-004-001 9507-012-001 Wiringlabel-schematic 9508-011-001 9508-013-001 9508-004-001 9508-012-001 Instruct-washerinstall 8507-448-001 8507-448-001 8507-448-001 8507-448-001 Instructions-chemicalhoseinstl 8507-268-001 8507-268-001 8507-268-001 8507-268-001 Instruct-transformerconn,60hz 8507-449-001 8507-449-001 8507-449-001 8507-449-001 Card-warranty(dexter)
  • Page 123 Notes Part # 8533-110-001 11/20...
  • Page 124 WN0650XB-12EO1 Diagram Part # 8533-110-001 11/20...
  • Page 125 WN0650XB-12EO1 Schematic Part # 8533-110-001 11/20...
  • Page 126 WN0650XB-12EO2 Diagram Part # 8533-110-001 11/20...
  • Page 127 WN0650XB-12EO2 Schematic Part # 8533-110-001 11/20...
  • Page 128 WN0750XB-12EO1 Schematic Part # 8533-110-001 11/20...
  • Page 129 WN0750XB-12EO1 Diagram Part # 8533-110-001 11/20...
  • Page 130 WN0750XB-12EO2 Schematic Part # 8533-110-001 11/20...
  • Page 131 WN0750XB-12EO2 Diagram Part # 8533-110-001 11/20...
  • Page 132 WN0950XB-12EO1 Schematic Part # 8533-110-001 11/20...
  • Page 133 WN0950XB-12EO1 Diagram Part # 8533-110-001 11/20...
  • Page 134 WN0950XB-12EO2 Schematic Part # 8533-110-001 11/20...
  • Page 135 WN0950XB-12EO2 Diagram Part # 8533-110-001 11/20...
  • Page 136 WN1450XB-12EO1 Schematic Part # 8533-110-001 11/20...
  • Page 137 WN1450XB-12EO1 Diagram Part # 8533-110-001 11/20...
  • Page 138 WN1450XB-12EO2 Schematic Part # 8533-110-001 11/20...
  • Page 139 WN1450XB-12EO2 Diagram Part # 8533-110-001 11/20...
  • Page 140 Notes Part # 8533-110-001 11/20...
  • Page 141 Section :9 Parts 50Hz WN0650XB-39XO 230 Volts 60 Hz Single Phase WN0750XB-39XO 230 Volts 60 Hz Single Phase WN0950XB-39XO 230 Volts 60 Hz Single Phase WN1450XB-39XO 230 Volts 60 Hz Single Phase Part # 8533-110-001 11/20...
  • Page 142 Transformer, Electrical Filter -39 models WN0650XB-39XO 230 Volts 50 Hz Single Phase WN0750XB-39XO 230 Volts 50 Hz Single Phase WN0950XB-39XO 230 Volts 50 Hz Single Phase WN01450XB-39XO 230 Volts 50 Hz Single Phase Key Component T-650 T-750 T-950 T-1450 Circuit Breaker 5198-211-002 5198-211-002 5198-211-002...
  • Page 143 Drain Valve Group Part 50 HZ Key Description Part Number Valve, Drain (includes #2 thru #11 9379-202-002 Body, Valve (w/ball) 9064-072-001 Motor & Gear Train (complete) 9914-137-022 Plate, Motor Mtg 9452-538-001 Screw 8639-994-001 Spring, Drive 9534-339-001 Screw 9545-054-001 Screw 9545-054-002 Seal, V Packer 9532-134-001 Washer...
  • Page 144 Gear Motor Door Lock Assembly 24VAC Description T-650 T-750 T-950 T-1450 Actuator Assembly (Includes 1-10, Rod NOT 9892-015-002 9892-015-002 9892-015-002 9892-015- included) Bracket Assy, Slide - Unlock 9985-190-001 9985-190-001 9985-190-001 9985-190- Bracket Assy, Slide - Unlock 9985-189-001 9985-189-001 9985-189-001 9985-189- Bracket Slide Lock 9029-204-001 9029-204-001...
  • Page 145 Notes Part # 8533-110-001 11/20...
  • Page 146 WN0650XB-39XO1 Schematic                                       ...
  • Page 147 WN0650XB-39XO1 Diagram Part # 8533-110-001 11/20...
  • Page 148 WN0650XB-39XO2 Schematic Part # 8533-110-001 11/20...
  • Page 149 WN0650XB-39XO2 Diagram Part # 8533-110-001 11/20...
  • Page 150 WN0750XB-39XO1 Schematic                                       ...
  • Page 151 WN0750XB-39XO1 Diagram BUTTONS Part # 8533-110-001 11/20...
  • Page 152 WN0750XB-39XO2 Schematic Part # 8533-110-001 11/20...
  • Page 153 WN0750XB-39XO2 Diagram Part # 8533-110-001 11/20...
  • Page 154 WN0950XB-39XO1 Schematic Part # 8533-110-001 11/20...
  • Page 155 WN0950XB-39XO1 Diagram BUTTONS Part # 8533-110-001 11/20...
  • Page 156 WN0950XB-39XO2 Schematic Part # 8533-110-001 11/20...
  • Page 157 WN0950XB-39XO2 Diagram Part # 8533-110-001 11/20...
  • Page 158 WN1450XB-39XO1 Schematic                                       ...
  • Page 159 WN1450XB-39XO1 Diagram BUTTONS Part # 8533-110-001 11/20...
  • Page 160 WN1450XB-39XO2 Schematic Part # 8533-110-001 11/20...
  • Page 161 WN1450XB-39XO2 Diagram Part # 8533-110-001 11/20...
  • Page 162 Notes Part # 8533-110-001 11/20...
  • Page 163 Section :10 Parts Electric Heated 60Hz WN0650EB-13XO 208-240 Volts 60 Hz 3 Phase WN0950EB-13XO 208-240 Volts 60 Hz 3 Phase Part # 8533-110-001 11/20...
  • Page 164 WN0650XB-13E0 Parts Key Component T-650 T-950 LABEL-WARNING,HIGHVOLTAGE 8502-614-004 8502-614-004 LABEL-QUALITY 8511-001-002 8511-001-002 LABEL-FUSING&INSTALLATION 8502-619-006 NUT-HEXKEPS,#8-32 8640-412-005 8640-412-005 NUT-HEXKEPS,#10-32UNF,2B 8640-413-002 8640-413-002 LOCKWASHER-EXTTOOTH,#10 8641-582-006 8641-582-006 BUSHING-INSULATED,1” 9053-067-004 9053-067-004 STUD-SELFCLINCHING,#10-32X1/2 9531-042-002 9531-042-002 SCREW-HXWSHRHDUNDCT,#10BX1/2 9545-008-026 SCREW-HXWSRHDSL,10-32TTX1/2GRN 9545-008-027 SCREW-PNHDCR,6ABX3/4 9545-031-010 9545-031-010 TERMINALBLOCKASSEMBLY-POWER 9897-033-002 9897-033-002 LABEL-FUSING&INSTALLATION 8502-619-006 NUT-ELASTICSTOP,#6-32 8640-411-002...
  • Page 165 WN0650XB-13E0 Parts Key Component T-650 T-950 CHNLASY-REAR,CMP,T-650,-13OOPL 9947-043-009 CHNLASY-REAR,CMP,T-950,-13OOPL 9947-046-007 RELAY 5192-285-004 5192-285-004 RELAY-HEATERS,60AMP 5192-291-001 5192-291-001 WIREASY-GRN/YEL,4” 8220-001-484 WIREASY-GRN/YEL,4” 8220-001-484 WIREASY-RED,19” 8220-063-040 8220-063-040 WIREASY-WHT/ORG,9” 8220-063-041 8220-063-041 WIREASY-GRN/YEL,11” 8220-064-055 8220-064-055 WIREASY-WHT/RED,81/2” 8220-064-066 8220-064-066 WIREASY-RED,17” 8220-078-025 8220-078-025 WIREASY-JUMPER,BLK/YEL,4-8” 8220-085-004 WIREASY-JUMPER,BLK/YEL,4-8” 8220-085-004 WIREASY-JUMPER,BLK/ORG,6-8” 8220-085-005 WIREASY-JUMPER,BLK/ORG,6-8”...
  • Page 166 WN0650EB-13XO1 Schematic Part # 8533-110-001 11/20...
  • Page 167 WN0650EB-13XO1 Diagram Part # 8533-110-001 11/20...
  • Page 168 WN0650EB-13XO2 Schematic Part # 8533-110-001 11/20...
  • Page 169 WN0650EB-13XO2 Diagram Part # 8533-110-001 11/20...
  • Page 170 WN0950EB-13XO1 Schematic Part # 8533-110-001 11/20...
  • Page 171 WN0950EB-13XO1 Diagram Part # 8533-110-001 11/20...
  • Page 172 WN0950EB-13XO2 Schematic Part # 8533-110-001 11/20...
  • Page 173 WN0950EB-13XO2 Diagram Part # 8533-110-001 11/20...
  • Page 174 Notes Part # 8533-110-001 11/20...
  • Page 175 Section :11 Parts Electric Heated 50Hz WN0650EB-68XO 400 Volts 50 Hz 3 Phase WN0950EB-68XO 400 Volts 50 Hz 3 Phase Part # 8533-110-001 11/20...
  • Page 176 Key Component T-650 T-950 LABEL-WARNING,HIGHVOLTAGE 8502-614-004 8502-614-004 LABEL-QUALITY 8511-001-002 8511-001-002 SEALER-PIPE 8538-132-000 NUT-HEXKEPS,#8-32 8640-412-005 8640-412-005 NUT-HEXKEPS,#10-32UNF,2B 8640-413-002 8640-413-002 LOCKWASHER-EXTTOOTH,#10 8641-582-006 8641-582-006 BUSHING-INSULATED,1” 9053-067-004 9053-067-004 STUD-SELFCLINCHING,#10-32X1/2 9531-042-002 9531-042-002 SCREW-HXWSHRHDUNDCT,#10BX1/2 9545-008-026 9545-008-026 SCREW-HXWSRHDSL,10-32TTX1/2GRN 9545-008-027 9545-008-027 SCREW-PNHDCR,6ABX3/4 9545-031-010 9545-031-010 TERMINALBLOCKASSEMBLY-POWER 9897-033-002 9545-030-002 RELAY 5192-285-004 5192-285-004 RELAY-HEATERS,40AMP(240VAC)
  • Page 177 Key Component T-650 T-950 STRAP-FAN,LANYARD 9544-067-001 9544-067-001 SCREW-PNHDCR,#8-32X3/4 9545-010-001 9545-010-001 SCREW-RDHDSLTDMACH,#10-32 9545-012-004 9545-012-004 SCREW-HXWSHDSL,6BX3/8 9545-031-003 9545-031-003 SCREW-HXWSHRHD,#6-32X11/2 9545-044-009 9545-044-009 SCREW-HXWSHRHD,#6-32X5/8 9545-044-012 9545-044-012 WIRINGHARNESS-PWRSUP,V2.0,HTD 9627-923-002 9627-923-002 WIRINGHARN-PWR/VFD/PS,50HZHTD 9628-007-001 9628-007-001 WIRINGHARNESS-HEATASY,2.0,50HZ 9628-008-001 9628-008-001 WIRINGHARNESS-MAIN,HTD,2.0,24V 9628-009-001 9628-009-001 HOUSINGASSY-SUMP,DRAIN,HTD 9803-219-001 9803-191-001 VALVEASSY-DRAIN,T-650HTD,24V 9819-026-004 CNTRL-TRGH.T650OPL,OHTD-68 9857-243-004 9857-245-004 TUB&CYLASSY-CMP,T-650,OPL-HTD...
  • Page 178 WN0650EB-68XO1 Schematic Part # 8533-110-001 11/20...
  • Page 179 WN0650EB-68XO1 Diagram Part # 8533-110-001 11/20...
  • Page 180 WN0650EB-68XO2 Schematic Part # 8533-110-001 11/20...
  • Page 181 WN0650EB-68XO2 Diagram Part # 8533-110-001 11/20...
  • Page 182 WN0950EB-68XO1 Schematic Part # 8533-110-001 11/20...
  • Page 183 WN0950EB-68XO1 Diagram Part # 8533-110-001 11/20...
  • Page 184 WN0950EB-68XO2 Schematic Part # 8533-110-001 11/20...
  • Page 185 WN0950EB-68XO2 Diagram Part # 8533-110-001 11/20...
  • Page 186 Notes Part # 8533-110-001 11/20...
  • Page 187 Section :12 Maintenance Part # 8533-110-001 11/20...
  • Page 188 Preventative Maintenance Daily Step 1: Check that the loading door remains securely locked and cannot be opened during an entire cycle. Step 2: Clean the top, front, and sides of the cabinet to remove residue. Step 3: Clean the soap dispenser and lid and check that all dispenser mounting screws are in-place and tight.

This manual is also suitable for:

T-650T-750T-950T-1450Wn0650xb-12eoWn0750xb-12eo ... Show all

Table of Contents
