Dexter Laundry WN0900 Service Manual

Opl washers
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
C-Series OPL Washers
WN0900, WN1200 (100G)
Sta
Starting Serial # W1.15244.001
8533-083-001 (1/18)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WN0900 and is the answer not in the manual?

Questions and answers

Related Manuals for Dexter Laundry WN0900

Summary of Contents for Dexter Laundry WN0900

  • Page 1 C-Series OPL Washers WN0900, WN1200 (100G) Starting Serial # W1.15244.001 8533-083-001 (1/18)
  • Page 2 Equipment Safety Warnings Symbols and Terminology Used in this Equipment Indicates an imminently hazardous situation, which if not avoided, will result in death or serious injury. Indicates a potentially hazardous situation, which if not avoided could result in death or serious injury. Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
  • Page 3 Equipment Safety Warnings Symbols and Terminology Used in this Equipment Warning! Do not operate equipment if door glass is damaged in any way. Warning! Keep clear of rotating parts. Prohibited! Do not enter this equipment or space. Prohibited! Do not step or stand on this equipment. Prohibited! Do not operate without all guards and covers in place.
  • Page 4 Indicates an imminently hazardous situation, which if not avoided, will result in death or seri- ous injury. Indicates a potentially hazardous situation, which if not avoided could result in death or serious injury. Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
  • Page 5 WARNING • All washers must be installed in accordance to all applicable electrical, plumbing and all other local codes. • These installation and operation instructions are for use by qualified personnel only. To avoid injury and electrical shock, do not perform any servicing other than that contained in the installation and op- eration instructions, unless qualified.
  • Page 6 WARNING Children should be supervised to ensure they do not operate or play in or around equipment. Keep all panels in place to protect against electrical shock and injury and add rigidity to washer. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a...
  • Page 7 Warning! Do not operate equipment if door glass is damaged in any way. Warning! Keep clear of rotating parts. Prohibited! Do not enter this equipment or space. Prohibited! Do not step or stand on this equip- ment. Prohibited! Do not operate without all guards and covers in place.
  • Page 8 Prohibited! Do not attempt to open, touch, or pro- ceed before referring to the manual or unless quali- fied. Mandatory! Read all supporting documentation be- fore operating or maintaining equipment. Mandatory! Disconnect power before servicing equipment. Mandatory! Lock out and tag out before servicing this equipment.
  • Page 9 Notes Part # 8533-083-001 1/18...

  • Page 10: Table Of Contents

    Dexter Safety Table of Contents Guidelines Section 1: Machine Mounting & Installation WARNING T-900 ............14 T-1200 ............14 T-900 Installation ...........15 T-1200 Installation..........16 These washers are equipped with devices and features relating to their safe operation. To Section 2: avoid injury or electrical shock, do not perform and service, unless qualified to do so.
  • Page 11 Air Gap ............43 Delta VFD Cooling Fan ........58 Water Valves ..........43 Section 7: Door Lock Assembly Operation .......43 Machine Electrical & Wiring Schematics Adjustment for the Door Lock Start Circuit ...........62 Assembly ........43 & 45 Fill Circuit ............62 Adjusting the Loading Door ......45 Wash Circuit ..........63 Loading Door Removal ........45 Drain, Rinse 1 &...
  • Page 12 Section 10: Maintenance Preventative Maintenance ......113 Part # 8533-083-001 1/18...
  • Page 13 Section 1: Machine Mounting Part # 8533-083-001 1/18...

  • Page 14: Machine Mounting & Installation

    Dexter Commercial T-900 Washer T900 Machine Dimensions Mounting Dimensions T1200 Machine Dimensions Dexter Laundry, Inc. 2211 W. Grimes, Fairfield, Iowa 52556 www.dexterlaundry.com 1-800-524-2954 © Rev. 3. 3/2009, Dexter Laundry, Inc. Dexter reserves the right to change specifications without notice. Part # 8533-083-001 1/18...
  • Page 15 T900 Mounting Pad Dimensions CONCRETE PEDESTAL MOUNTING FLOOR OUTLINE Figure 1-1 Figure 1-2 Part # 8533-083-001 1/18...

  • Page 16: T-1200 Installation

    T1200 Mounting Pad Dimensions CONCRETE PEDESTAL MOUNTING FLOOR OUTLINE Figure 1-1 Figure 1-2 Part # 8533-083-001 1/18...

  • Page 17: Installation

    Section 2: Machine Installation & Operating Instructions Part # 8533-083-001 1/18...

  • Page 18: Basic Installation

    Washer Installation All washers must be installed in accordance with all local, state and national building, electrical, and plumbing codes in effect in the area. Foundation Requirements The washer must be securely bolted to a substantial concrete floor, or mounted upon a suitable base which is securely bolted and machine grouted to a substantial concrete floor.
  • Page 19 To Make Electrical Connections Disconnect all power to the washer. Remove screw and lift out the cover located in the upper left corner of the machine (as viewed from the back). • If power is 208-240-3PH-60Hz, connect L1, L2, L3 and ground. If there is a high leg it must be connected to L3.

  • Page 20: Electrical Connections & Fusing Requirements .19 Machine Chemical Connection

    Liquid Chemical Connection In the left rear corner of the washer is the chemical injection as- sembly. This is where all chemical hose connections are made. The chemical hoses should be inserted into the round pvc pipe a minimum of 14” and a maximum of 18” to eliminate chemical buildup in the pipe and/or restrict water flow to the tub.
  • Page 21 Washer Operating Instructions Safety Door Lock This machine is equipped with a Safety Door Lock that locks the door closed from when the cycle is started until the cycle is complete. The door lock prevents opening the door for up to 3 minutes if the power is interrupted during the cycle.

  • Page 22: Detergent Measurements By Model

    Detergent Measurements By Washer Model 1/3 Cup Maxi Load T-750 Washer 1/2 Cup Mega Load T-900 Washer 1/2 Cup Mega Load T-950 Washer 1/2 Cup Magnum Load T-1200 Washer 2/3 Cup Magnum Load T-1450 Washer Part # 8533-083-001 1/18...

  • Page 23: Machine Programming Instructions

    Section 3: Machine Programming Instructions Part # 8533-083-001 1/18...
  • Page 24 Bath Cycle Time “ct” 0 to 15 minutes for Prewash, Rinse1 and Rinse 3 to 15 minutes for Wash and Final Rinse. For the baths that can, if the time is set to zero, then that bath will be eliminated from the cycle. Bath Water Temperature “t”...
  • Page 25 Cycle 1: Sheets and Pillowcases (Health Care) Bath Bath Cycle Water Water Delay Spin Injection Time (min.) Temp. Level Fill Time (min.) Source Flush Prewash Wash #1(Detergent) Rinse 1 #2 (Bleach) Rinse 2 Rinse 3 Rinse 4 Final Rinse #4 (Sour/Soft) Cycle 2: Towels / Pads / Diapers (Health Care) Bath Bath Cycle...
  • Page 26 Cycle 4: Guest Laundry (Hotel / Motel / Healthcare) Bath Bath Cycle Water Water Delay Spin Injection Time (min) Temp. Level Fill Time (min) Source Flush Prewash Wash (#6(Detergent/Bleach) Rinse 1 Rinse 2 Rinse 3 Rinse 4 Final Rinse #4 (Sour/Soft) Cycle 5: Rags and Mops (Hotel / Motel) Bath Bath Cycle...

  • Page 27: Programming

    Washer Programming Instructions THERE ARE TWO WAYS TO MODIFY PROGRAMMING OF THE V-SERIES OPL SIX (6) PREPROGRAMMED FORMULAS Option 1: Programming can be accomplished manually using the machine controls or by connecting to the machine control using a PDA (personal digital assistant). For instructions on using a PDA with this washer control and software, please contact your local Dexter distributor.

  • Page 28: Rapid Advance Mode

    Rapid Advance Mode To enter the Rapid Advance mode, turn the key CCW. The Rapid Advance setting is not marked next to the key, but turning the CCW until it stops selects this mode. The Rapid Advance mode can be entered from either the Idle mode or during the cycle.

  • Page 29: Trouble Shooting

    Section 4: Trouble Shooting Part # 8533-083-001 1/18...

  • Page 30: Common Troubleshooting Solutions

    Common Troubleshooting Solutions Symptom Probable Cause Suggested Remedy Machine Power Supply Check these areas: Circuit breakers, Voltage, Power leads, does not Power connections. Is front display LED showing a dollar start amount. Door Switch Check for continuity through door switch when door is closed.
  • Page 31 Common Troubleshooting Solutions Symptom Probable Cause Suggested Remedy Hot water Water Valve Coil Check coil continuity at terminals and replace if no continuity. does not Check for 120 V power from main relay PCB enter tub in Water Inlet Check water inlet screens for blockage and clean if necessary wash screens Water...

  • Page 32: Programming Presets

    Common Troubleshooting Solutions Symptom Probable Cause Suggested Remedy Machine Check VFD by removing inspection panel and record any does not numbers or letters displayed. If no display turn power off to turn machine at breaker for 2 minutes and turn poiwer back on to reset.

  • Page 33: Troubleshooting Machine Fault Errors

    Troubleshooting Machine Fault Errors The following are descriptions of fault codes that will appear on the front of the washer. There is a chart format that shows what fault code that will be displayed at washer front. The codes displayed may or may not stop machine operation. PLEASE NOTE: CHECK DRIVE FAULT CODE BEFORE POWERING MACHINE DOWN! Fault# Description Customer Action...
  • Page 34 Fault# Description Customer Action Wrong size drive installed Check VFD fault code before turning off power.Check to ensure all the harnesses are properly connected to the controller. Check to ensure the VFD drive horsepower is proper for this size of washer. The control can be reset by holding program button on controller during startup (soft reset) Check orange wires at molex connector on controller coming from pressure switch.
  • Page 35 Fault# Description Customer Action The variable frequency Check the data communication cable between the drive (VFD) and the washer computer and the variable frequency drive washer computer are not (VFD). communicating. Step 1: Make sure the cable did not become unplugged during operation.
  • Page 36 Fault# Description Customer Action Step 1: Make sure the cooling fins on the VFD heatsink The temperature sensor inside of the variable and the ventilation louvers on the VFD cooling fan cover frequency drive detects that are clean. Step 2: Start a washer cycle and make sure the internal temperature is the VFD cooling fan operates after the cylinder starts too high.

  • Page 37: Motor Resistance Chart

    VFD unit has been added or Soft reset control. loose connection. Injection relay PCB has been Soft reset control. added to machine or loose connection. Optional water valve PCB Soft reset control. has been added or loose connection Note: Whenever power is turned off to the washer, it must remain off for three minutes for drive to reset.

  • Page 38: Variable Frequency Drive Control Digital Readout Faults

    Variable Frequency Drive Control Digital Readout Faults Fault# Description Customer Action VFD received an illegal Reset drive. command. Possible controller problem Illegal data address, VFD Reset drive. received an address not available to the controller. Illegal data value received Reset drive. at VFD.
  • Page 39 Variable Frequency Drive Control Digital Readout Faults Fault# Description Customer Action OL or Overload of the drive or (Check drive fault code before powering down). Check motor the washer motor to ensure it turns freely. Check the wiring for loose connections to the drive and motor.
  • Page 40 Notes Part # 8533-083-001 1/18...

  • Page 41: Machine Service Procedures

    Section 5: Machine Service Procedures Part # 8533-083-001 1/18...

  • Page 42: Lower Service Panel Removal

    Top Panel Removal Top Soap Dish Step 1: Remove 4 screws that hold detergent dispenser to top panel. (for T750, T900, T950) Step 2: Unlock top panel lock. Step 3: Raise top panel, slide to the rear to release from back clips and lift off. Top Panels Removal Front Soap Dish Step 1: Unlock top panel locks.

  • Page 43: Air Gap

    Vacuum Breaker (also called an air gap) In the left rear of the cabinet is the vacuum breaker. It guides the water to the tub and dispenser and prevents a back flow of water. Water Valves Remove top panel to access water valves. (see Removing Top Panel) The two dual outlet water and/or single coil valves are mounted to the rear channel with two screws each.
  • Page 44 Door cam Flat blade screw on check position door switch latching Step 3: With switch actuator bracket adjusted you Step 4: Check for switch actuation at partial will now need to adjust single switch by turn of cam as in operation above. Door loosening 2 flat brade screws and allowing handle goes from horizontal to six o’clock swivel of switch.

  • Page 45: Adjusting The Loading Door

    Adjusting the Loading Door The door can be adjusted by changing the number of shims behind the door hinge and the door lock assembly. The vertical fit of the door to the tub can be altered by loosening the door hinge bolts and raising or lowering the door before retightening.

  • Page 46: Loading Door Disassembly

    Loading Door Disassembly Step 1: Remove the loading Step 2: While holding down on Step 3: Work all the way around door as outlined above. the door glass, lift up the gasket and the glass Lay the door on a flat on the door ring and roll is out.

  • Page 47: Outer Cabinet Removal

    Door Locking Gear Motor Assembly The door locking gear motor is rotated shut with control voltage to lock the door and releases when voltage is removed. It is located in the left front corner of the washer. (Original l ocking solenoid models can be converted to the new assembly) Thermoactuators Door Lock Gear Motor...

  • Page 48: Tub Back, Bearing And Cylinder Assembly

    Cylinder (basket) Step 1: Remove the top panel as described previously. Step 2: Remove lower service panel as described previously. Step 3: Remove front panel as described previously. Step 4: Remove masking ring as described previously. Step 5: Remove door lock assembly. (Leave wires & pull rod in place) Step 6: Remove clothes door.
  • Page 49 Water Seals Replacement Step 1: Remove cylinder from washer (see Cylinder (basket) removal). Step 2: Remove water seals from the seal mounting plate on Guard Ring & Mating Ring the cylinder shaft. These are removed with your fingers. Step 3: The primary and secondary seals that mount on the sealing ring may be slid over the shaft and seated on the metal sealing ring with your fingers.
  • Page 50 Reassembly of the Cylinder Step 1: Use the hub of the drive pulley, a stack of 5/8” flat washers and a 3” long 5/8” bolt to pull the cylinder shaft through the bearings. After the 3” bolt a 2” long bolt will be required to finish pulling the cylinder shaft through.

  • Page 51: T-900, T-1200 Bolt Torque Chart

    T-900, T-1200 Bolt Torque Chart Bolt Size Where Used Torque 7/16” Stainless Cap Screw Outer Tub to Bearing Housing 60-80 ft/lbs 3/4” Bolt Bearing Housing to Frame 200-300 ft/lbs 1/2” Bolt Outer Tub Clamping Band to Frame 70-110 ft/lbs 1/2” Bolt Outer Tub Clamping Band - Top 30-40 ft/lbs 3/8”...
  • Page 52 Notes Part # 8533-083-001 1/18...
  • Page 53 Section 6: Service Electrical Components Part # 8533-083-001 1/18...

  • Page 54: Control Mounting Trough

    Control Mounting Trough Remove top panel to access control trough. (see Removing Top Panel) It sets on the right side of the machine and holds the control PCB’s, transformers,and pressure switch. Main Data Communication Cable Goes between front PCB board and Variable Frequency Drive unit mounted center rear of machine. It has telephone type connectors at each end and is inserted at Controller PCB and the Variable Frequency Drive.

  • Page 55: Pressure Switch

    Pressure Switch Caution (Not recommended by Factory!) Changing Factory preset adjustment voids all factory water usage specifications. The pressure switch sets the water level in the washer. As the water level rises, it compresses the air in the pressure switch hose. When the washer reaches the desired water level, the compressed air in the pressure switch hose opens the contacts in the switch, shutting off the water.
  • Page 56 Pressure Sensor Electronic The Electronic Pressure Sensor comes standard on all models Starting Septembet, 1st 2015. Machines Level Chart manufactured before this date can be upgraded with Kit 9732-213-001. The Pressure sensor is adjustable. The Factory settings chart will let you know the starting values for each machine and by following the Switch position chart you can adjust the water levels in 1/4 inch increments from that starting value.
  • Page 57 Water Level Ch                                      ...

  • Page 58: Power Connection Terminal Block

    Power Connection Terminal Block This terminal block sets at the very back of the control trough. Incoming power to the washer should connect here. (see Electrical under Installation and Operation Section for exact connections) Rear Delta Variable Frequency Drive: Main power is connected to terminals L1, L2, and L3 on the Delta drive. If the washer is connected to a three phase source, there should be voltage present on all three terminals.
  • Page 59 MAXIMUM SPIN SPEED ADJUSTMENT: If desired, the washer can be adjusted to limit the maximum extract spin speed for all wash cycles. To make this adjustment, a jumper wire must either be installed or removed on the Variable Frequency  Drive (VFD), depending on the washer model and desired speed.
  • Page 60 Notes Part # 8533-083-001 1/18...
  • Page 61 Section 7: Electrical Wiring Diagrams & Schematics Part # 8533-083-001 1/18...

  • Page 62: Start Circuit

    Electrical Path Circuit Schematics Start Circuit Power travels into the machine on L1 & L2 & (L3) ( if 3 phase used). 208- 240VAC goes to a Control Transformer ( must be checked at start -up to coincide with machine operating voltage) that steps the voltage down to 115VAC for the controls.

  • Page 63: Wash Circuit

    Wash Circuit As the washer fills the tub through the back of the machine with either one or both the C1 Cold and H1 Hot Water Valves, the Wash Basket will tumble one direction for 12 seconds, pause, and then reverse di- rection for 12 seconds.
  • Page 64 Notes Part # 8533-083-001 1/18...
  • Page 65 Notes Part # 8533-083-001 1/18...

  • Page 66: Diagrams & Schematics

    WN0900XA-12 Schematic Part # 8533-083-001 1/18...
  • Page 67 WN0900XA-12 Diagram Volt Wiring Schematic Part # 8533-083-001 1/18...
  • Page 68 WN1200XA-12 Schematic Part # 8533-083-001 1/18...
  • Page 69 WN1200XA-12 Diagram Part # 8533-083-001 1/18...
  • Page 70 Notes Part # 8533-083-001 1/18...

  • Page 71: Parts Data

    Section 8: Parts Data WN0750XA-12EV 208-240 volts 60hz. Single Phase or Three Phase WN0900XA-12EV 208-240 volts 60hz Single Phase or Three Phase WN0950XA-12EV 208-240 volts 60hz Single Phase or Three Phase WN1200XA-12EV 208-240-volts 60hz Single Phase or Three Phase WN1450XA-12EV 208-240 volts 60 hz Single Phase or Three Phase...

  • Page 72: A-Series Accessories

    C-Series OPL Accessories WN0750XA-12EV 208-240 volts 60hz. Single Phase or Three Phase WN0900XA-12EV 208-240 volts 60hz Single Phase or Three Phase WN0950XA-12EV 208-240 volts 60hz Single Phase or Three Phase WN1200XA-12EV 208-240-volts 60hz Single Phase or Three Phase WN1450XA-12EV 208-240 volts 60 hz Single Phase or Three Phase Description...

  • Page 73: Wiring Harness Part # By Model

    Wiring Harness Part # by Model Description T900 T1200 Wiring Harness (Add Bleach Lite assy included) 9794-001-001 9794-001-001 Wiring Harness, Door Lock 9627-791-005 9627-791-005 Wiring Harness, Drain,Thermo,DoorSol 9627-796-002 9627-796-002 Data Cable 9806-015-001 9806-015-003 Wiring Harness P20/P21 9627-793-001 9627-793-001 Wiring Harness P8/P16 9627-794-001 9627-794-001 Wiring Harness WaterValve/P19...

  • Page 74: Cabinet And Front Panel Group Part # By Model

    Cabinet and Front Panel Group Part # by Model Large Door Description T900 T1200 Panel, Side (Left or Right) - stainless 9454-839-001 9454-814-001 Bolt-1/4-20x1/2 (side panel Front to Rear) 9545-018-013 9545-018-013 Nut 1/4-20UNC (side panel) 8640-414-006 8640-414-006 Strap Assy (Side to base) 9966-012-001 9966-012-002 Shim (side panel)
  • Page 75 15,16 15,16 Description T900 T1200 Screw Mtg., Flat Head 10Bx1 3/4 9545-008-014 9545-008-014 Washer, Finish 8641-585-001 8641-585-001 Nut, Spring 8640-399-008 8640-399-008 Label-Risk of injury (Black) 8507-759-001 8507-759-001 Key, Top- # 6324 6292-006-007 6292-006-007 Washer Flat 5/16 8641-581-008 8641-581-008 Cam, Lock-Top 9095-049-001 9095-049-001 Nut, 9/32 - 28 Hex...

  • Page 76: Soap Dish

    Cabinet and Front Panel Group Part # by Model Front Soap Dish 4, 5 12 11 Gasket and Soap Tub Front Here Dish Here Part # 8533-083-001 1/18...
  • Page 77 Top Mount Detergent Dispenser Description T900 T1200 Dispenser Soap 9122-005-004 Gasket Despinsor 9206-416-001 Hose, Despinsor to tub 9242-450-001 Clamp 8654-117-008 Nut, Spring ss 8640-399-007 Flow restictors 9475-002-002 Flow restictors Optional (Smaller) 9475-002-003 Door, Dispenser 9108-095-005 Pin, Plain 9451-191-001 Post, Door Mounting 9467-025-001 Screw- 8B x 1/2 9545-045-002...

  • Page 78: Rear View Access Part # By Model

    Rear View Access Part # by Model Description T900 T1200 Drive Motor, 3 Phase (Inverter duty) 9376-308-001 9376-329-001 Rod, Motor Mtg 9497-222-004 9497-222-004 Collar, Shaft (w/set screws) (old) 9076-052-002 9076-052-002 Motor Bushing (plastic) 9053-074-002 9053-074-002 New motor bushing support 9053-082-001 9053-082-001 Clamp for motor bushing 8654-117-019...
  • Page 79 10,11 12,13,14 10,11 12,13,14 Description T900 T1200 Injection- tube assy 9883-012-001 9883-012-001 Hose, Injection Tube to Tub 9242-461-001 9242-461-001 Clamp, Injection Hose 8654-117-014 8654-117-014 Hose-Overflow 9242-449-003 9242-449-003 Clamp Hose Over Flow 8654-117-008 8654-117-008 Drain Valve 9379-200-001 9379-200-001 Hose, Drain Valve to Tube 9242-457-001 9242-457-001 Clamp...

  • Page 80: Rear Chanel

    Description T900 T1200 Channel, Rear 9081-169-001 9081-169-001 Screw #10Bx1/2 9545-008-026 9545-008-026 Nut, Spring 8640-399-008 8640-399-008 Plug, 7/8” 9456-041-006 9456-041-006 Bushing, 7/8” 9053-067-002 9053-067-002 Braacket-Terminal Block Assy 9029-265-001 9029-265-001 Screw, 10Bx1/2 9545-008-026 9545-008-026 Strip-Terminal marker, Power 9558-025-001 9558-025-001 Terminal Block-Power 9897-033-002 9897-033-002 Screw-6ABx3/4 9545-031-010...
  • Page 81 26 25 36 35 Description T900 T1200 Vacuum Breaker 9610-001-001 9610-001-001 Bracket-Vacume Breaker 9029-077-001 9029-077-001 Screw, 10Bx1/2 9545-008-026 9545-008-026 Clamp, Vacuum Breaker End 8654-117-014 8654-117-014 Hose, Vacuum Breaker to Tub Injection Tube 9242-461-001 9242-461-001 Part # 8533-083-001 1/18...

  • Page 82: Cylinder, Seals & Bearings Part # By Model

    Cylinder, Seals & Bearings Part # by Model Description T900 T1200 Housing, Bearing- Assembly (items #2-#6) 9803-187-001 9803-187-001 Housing, Bearing 9241-181-004 9241-181-004 Bearing, Front (LARGE) 9036-159-006 9036-159-006 Bearing, Rear (SMALL) 9036-159-005 9036-159-005 Spacer, Bearing 9538-170-001 9538-170-001 Ring, Bearing Retainer 9487-238-004 9487-238-004 Tub Assembly 9930-157-001...
  • Page 83 19,20 21,22,23,24 11 G 12,13 14,15,16,17 Description T-900 T1200 Cylinder Assy 9848-136-001 9848-137-002 Tub Front 9974-011-001 9974-011-002 Gasket, Tub Front 9206-421-002 9206-421-002 Ring Assy, Tub Mtg-Front Clamp 9950-055-001 9950-055-001 Bolt, Top Front Ring 3/8”-16 x 3” 9545-029-009 9545-029-009 Nut WCAD 3/8”-16 8640-415-001 8640-415-001 Part # 8533-083-001 1/18...

  • Page 84: Door Lock Part # By Model

    Door Lock Assembly (All Models) Key Description All Models Key Description All Models Lock Assy, Complete (#1-22) 9885-024-001 Ring, Retaining 9487-200-005 (includes #1 thru #22) Washer 8641-581-031 Plate Assy, Door Lock 9982-346-001 Switch, Latching Sensing 9539-461-008 Washer, Flat (SS or Brass) 8641-581-030 Shield, Switch 9550-169-003...
  • Page 85 Gear Motor Door Lock Assembly Description T900 T1200 Actuator Assembly (Includes 1-10, Rod NOT 9892-014-001 9892-014-001 included) Screw Pnhdcr, 10-32 UNFx0 .75 9545-012-027 9545-012-027 Cross Recessed PAn Hd Tapping screw 9545-031-011 9545-031-011 Screw -Hxwshrhdslsems, 6-32 x 3/16 9545-044-003 9545-044-003 Motor & Gear Assembly 120v 9914-137-015 9914-137-015 Spring - Extension...

  • Page 86: Loading Door Part # By Model

    Large Door & Hinge Group (After #514975) Description T900 T1200 Door Hinge Assembly (mounts to tub front) 9955-031-001 9955-031-001 Door Assembly Complete 9960-310-001 9960-310-001 Door Ring 180 degree large hnge 9487-275-001 9487-275-001 Door Gasket 9206-431-001 9206-431-001 Door Glass Window 9635-020-001 9635-020-001 Red Wire (Door Close Switch) 8220-063-028...
  • Page 87 Description T-900 T1200 Shaft, Door Locking 9537-195-002 9537-195-002 Cam, Locking 9095-040-002 9095-040-002 Pin, Groove (1 1/4) 9451-181-005 9451-181-005 Pin, Groove (3/4) 9451-181-004 9451-181-004 Spring, Lock Cam 9534-360-002 9534-360-002 Handle, Door 9244-091-001 9244-091-001 Pin, Door Handle (groove) 9451-181-005 9451-181-005 Part # 8533-083-001 1/18...
  • Page 88                    Top Soap Box 4 Valve Design Top Soap Box Design  Part # 8533-083-001 1/18...

  • Page 89: Water Inlet Part # By Model

    Water Inlet Part # by Model Description T900 T1200 Injector Assembly 9883-012-001 9885-012-001 Valve, Water Inlet (dual outlet) (see Water Inlet Valve 9379-183-012 9379-183-012 Breakdown for individual parts) Screw, Valve Mtg 9545-008-026 9545-008-026 Valve Water Inlet (single outlet) 9379-194-001 9379-194-001 Screw, Valve M4x0.7x8mm 9495-064-001 9545-064-001...

  • Page 90: Water Inlet Valve Breakdown L

    Water Inlet Valve Breakdown Part # by Model Description T900 T1200 Valve, Water Inlet (includes 1 thru 6) 9379-183-012 9379-183-012 Screen, Inlet end of valve 9555-056-001 9555-056-001 Coil Assy., 120 V Invensys 9089-017-001 9089-017-001 Diaphragm Invensys (EPDM) 9118-049-001 9118-049-001 Diaphragm Invensys (Viton) 9118-049-002 9118-049-002 Diaphragm Invensys (EPDM NSF)
  • Page 91 Key Description T900 T1200 Single Coil Water Valve Mueller 9379-194-001 Valve Water Body Complete 9379-194-002 (no coil) Diaphragm Mueller 9118-055-001 Filter Mueller 9183-046-001 Coil Mueller 9089-051-001 Part # 8533-083-001 1/18...

  • Page 92: Drain Valve Group Part # By Model

    Drain Valve Group Part # by Model Key Description Part Number Valve, Drain (includes #2 thru #11 9379-202-001 Body, Valve (w/ball) 9064-072-001 Motor & Gear Train (complete) 9914-137-023 Plate, Motor Mtg 9452-538-001 Screw 8639-994-001 Spring, Drive 9534-339-001 Screw 9545-054-001 Screw 9545-054-002 Seal, V Packer 9532-134-001...
  • Page 93 Notes Part # 8533-083-001 1/18...

  • Page 94: Chassis And Drain Part # By Model

    Chassis and Drain Part # by Model Description T-900 T-1200 Base Assy,Frame 9945-128-002 9945-125-002 Outer Tub Assy. 9930-157-001 9930-150-001 Tub & Cylinder Assy. 9869-027-003 9869-022-001 Tub Front 9974-011-001 9974-011-002 Gasket, Tub Front 9206-421-002 9206-421-002 Ring Assy, Tub Mtg-Front Clamp 9950-055-001 9950-055-001 Bolt, Top Front Ring 3/8”-16 x 3”...
  • Page 95 7, 8, 9 Part # 8533-083-001 1/18...
  • Page 96 Description T900 T1200 Trough Assy,Controls 208-240 volt (all parts below 9857-216-001 9857-217-001 #2-#43) Trough only 9839-018-001 9839-018-001 Screw, Trough Sides 9545-008-026 9545-008-026 Lockwasher Exttooth #10 8641-582-006 8641-582-006 Angle Support Trough 9003-271-001 Screw, Trough Bracket 9545-008-026 9545-008-026 Channel-Trough Mounting 9081-108-001 9801-110-001 Screw-10Bx1/2 9545-008-026 9545-008-026...

  • Page 97: Electrical Components - Top Compartment

    Electrical Components - Top Compartment Mechinical Pressure Switch Electronic Pressure Sensor Part # 8533-083-001 1/18...

  • Page 98: Control Panel Part # By Model

    Control Panel Part # by Model Description T900 T1200 Panel Control Assembly(panel only) After Serial 9989-480-001 9989-456-001 #530673 Nameplate,Control Panel (one piece) Black 9412-224-001 9412-229-001 Screw-Hxwshrhdundct #10Bx 1/2”(Control Panel To 9545-008-026 9545-008-026 side Panel) Plastic Shield over main PCB 9550-184-001 9550-184-001 Nut Hexkeps #8-32 8640-412-005...
  • Page 99 5, 6 Part # 8533-083-001 1/18...

  • Page 100: Labels And Diagrams All Wcad Models

    Labels and Diagrams All C-Series Models Description T900 T1200 Operators Manual 8514-243-001 8514-245-001 Wiring Schematic & Diagram 9506-558-001 9506-562-001 Transient Voltage Surge Suppressor Infomational 8507-330-001 8507-330-001 Instructions Spin Direction 8507-275-001 8507-275-001 Label High Voltage Warning 8502-614-004 8502-614-004 Label Fusing & Installation 8502-619-003 8502-619-003 Label Quality...
  • Page 101 Notes Part # 8533-083-001 1/18...
  • Page 102 Notes Part # 8533-083-001 1/18...

  • Page 103: Parts

    Section :9 Parts 50Hz Models: Parts in this section used only in these models. All other parts are same as standard 60 Hz pages. Wiring Diagrams & Schematics WN0750XA-39XV 208-240 volts 60hz. Single Phase or Three Phase WN0900XA-39XV 208-240 volts 60hz Single Phase or Three Phase WN0950XA-39XV...
  • Page 104 Transformer, Electrical Filter -39 models Key Component T900 T1200 Circuit Breaker 5198-211-002 5198-211-002 Harness, Power Terminal block 9627-747-006 9627-747-006 Assembly, Control Trough 9857-216-003 9857-217-002 Instructions, Transformer Connect 8507-449-002 8507-449-002 Control Transformer 8711-004-003 8711-004-003 Transformer, Step Down 8711-009-003 8711-009-003 Strip, Marker-Injection 9558-028-002 9558-028-002 Wiring Schematic &...
  • Page 105 Drain Valve Group Part 50 HZ Key Description Part Number Valve, Drain (includes #2 thru #11 9379-202-002 Body, Valve (w/ball) 9064-072-001 Motor & Gear Train (complete) 9914-137-022 Plate, Motor Mtg 9452-538-001 Screw 8639-994-001 Spring, Drive 9534-339-001 Screw 9545-054-001 Screw 9545-054-002 Seal, V Packer 9532-134-001 Washer...
  • Page 106 Gear Motor Door Lock Assembly 24V AC Description T900 T1200 Actuator Assembly (Includes 1-10, Rod NOT included) 9892-015-002 9892-015-002 Bracket Assy, Slide Lock Actuator 9985-190-001 9985-190-001 Bracket Assy, Slide - Unlock 9985-189-001 9985-189-001 Bracket Slide Lock 9029-204-001 9029-204-001 Spacer, Plastic 9538-157-021 9538-157-021 Arm - Door Lock...
  • Page 107 Notes Part # 8533-083-001 1/18...

  • Page 108: 50Hz Diagrams & Schematics

    T900 230/50/1 Voltage Schematic Part # 8533-083-001 1/18...
  • Page 109 T900 230/50/1 Voltage Diagram Part # 8533-083-001 1/18...
  • Page 110 T1200 230/50/1 Voltage Schematic Part # 8533-066-001 5/11...
  • Page 111 T1200 230/50/1 Voltage Diagram Part # 8533-066-001 5/11...
  • Page 112 Notes Part # 8533-083-001 1/18...
  • Page 113 Section :10 Maintenance Part # 8533-083-001 1/18...
  • Page 114 Preventative Maintenance Daily Step 1: Clean the top and the cabinet to remove residue. Step 2: Clean the soap dispenser and soap lid Step 3: Check the drain for leaking and proper draining. Step 4: Check the loading door for leaks. Step 5: Clean the door seal of all foreign material.
  • Page 115 Notes Part # 8533-083-001 1/18...
