- Page 1 Armstrong Cast Aluminum Fire Pit Table Item#: WARNING 07272...
-
Page 3: Hardware Contents
PACKAGE CONTENTS PACKAGE CONTENTS PART DESCRIPTION QUANTITY Removable Burner Cover Panel Panel Gas Tank Support Bar Gas Tank Support Ring Protective Cover Fire Glass HARDWARE CONTENTS TOOLS Bolt 8x20mm Washer Spring Washer 8mm Bolt 6x25mm Wrench (4 for assembly +1 extra) (4 for assembly +1 extra) (8 for assembly +1 extra) Washer 6mm... - Page 5 ASSEMBLY PREPARATION Before beginning assembly, be sure to empty contents of carton and make sure all parts are present. If any parts are missing, please contact Customer Service at (866)-985-7877, Monday-Friday, 9 a.m. - p.m. EST or email cservice@welltraveled.net. Place all parts on a soft, level surface for assembly. NOTE: it is recommended to use TWO PEOPLE to assemble this gas fire pit.
- Page 6 ASSEMBLY Gas Tank Support Ring over Gas Tank Support Bar and align hole on front of Gas Tank Support Ring with holes at the bottom of Front Door Panel Washer then hole. Tighten with Hex Key Hardware Used: Turn the assembled table base , then place Table Top over Legs, and align the holes on Table Top with holes on the top of Legs.
- Page 7 ASSEMBLY Pour the Fire Glass J around the Burner. Be careful not . to obstruct pilot light housing.Put the Removable Burner Cover on the Burner. When the Protective Cover . DO NOT PUT THE PROTECTIVE FIRE PIT COVER ON A HOT FIRE PIT.
- Page 8 ASSEMBLY Connect hose and regulator to cylinder. The propane gas and cylinder are sold separately. Use a standard 20lb propane cylinder have this book. Storage of an appliance indoors is permissible only if the cylinder is disconnected and removed from the appliance. A cylinder must be stored outdoors in a well-ventilated area out of the reach of children.
-
Page 10: Leak Check
OPERATING INSTRUCTIONS LEAK CHECK WARNING! Hose / Regulator Regulator / Cylinder Connection Connection 2. Apply several drops of solution where hose attaches to regulator. 3. Apply several drops of solution where regulator connects to cylinder. 5. Turn cylinder valve ON. If bubbles appear at any connection there is a leak. - Page 11 FOR YOUR SAFETY OPERATION CHECKLIST:...
- Page 12 OPERATING INSTRUCTIONS NOTE: If burner fails to remain lit, close all valves and wait at least 5 minutes before attempting to light. Figure A Figure B Figure SHUT DOWN: AFTER OPERAT ON...
-
Page 14: Conversion To Natural Gas
CONVERSION TO NATURAL GAS WARNING! To avoid the possibility of burns conversion should only be done when the patio beginning conversion. WARNING! Fire Glass may have sharp edges. Wear safety glasses and gloves when handling. WARNING! connections must be leak tested prior to operating the appliance. emove the from the enclosure. - Page 18 an additional year...
