Wagner Aluminum Round Fire Pit
ATTACH YOUR
RECEIPT HERE
Keep a copy of your proof of
purchase or order confirmation
which will be needed if you
need to contact us about
warranty coverage.
Purchase Date:
Questions, problems, missing parts?
Before returning to your retailer, our exceptional customer service is available.
Call us toll-free at (866) 985-7877, email us at cservice@welltraveled.net, or go online and
live chat at www.wtliving.com. Our hours are: 9 a.m. – 6 p.m., EST, Monday – Friday.
Item#: 62988
WARNING
FOR YOUR SAFETY
1. Improper installation, adjustment,
alteration, service or maintenance can
cause injury or property damage.
2. Read the installation, operation, and
maintenance instructions thoroughly
before installing or servicing this
equipment.
3. Failure to follow these instructions
could result in fire or explosion, which
could cause property damage, personal
injury, or death.
WARNING
For Outdoor Use Only
WARNING
This product can expose you to chemicals including
Carbon Monoxide, Lead, Chromium (hexavalent
compounds), Di(2-ethylhexyl) phthalate (DEHP) and
Diisononyl phthalate (DINP), which are known to the
State of California to cause cancer and birth defects
or other reproductive harm. For more information, go
to www.P65Warnings.ca.gov.
Manual updated Feb 2019
Advertisement
Table of Contents
Related Manuals for Fire Sense Wagner 62988
Summary of Contents for Fire Sense Wagner 62988
- Page 1 Comfort, Quality & Style Since 1998 Wagner Aluminum Round Fire Pit Item#: 62988 WARNING FOR YOUR SAFETY 1. Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. 2. Read the installation, operation, and maintenance instructions thoroughly before installing or servicing this equipment.
-
Page 2: Table Of Contents
www.wtliving.com TABLE OF CONTENTS Table of Contents Page 2 Page 2 Before You Begin Package Contents Page 3 Safety Information Page 4 Assembly Pages 5-8 Operating Instructions Pages 9-12 Care and Maintenance Page 13 Troubleshooting Page 14 Warranty Information Page 15 BEFORE YOU BEGIN Please read and understand this entire manual before attempting to assemble, operate or install this appliance. -
Page 3: Package Contents
Remo va ble Burner Cover Burner Table Top Door Panel Panel 1 Panel 2 Panel 3 Door Frame Leg Support Leg Tank Support Bar Tank Support Ring Protective Cover Fire Glass Washer/Spring Washer/ Bolt 6x25mm Bolt 6x18mm Washer M6 Stud (8x30mm) Nut (8mm) Qty: 6 Qty: 13... -
Page 4: Safety Information
SAFETY INFORMATION SAFETY INFORMATION DANGER DANGER This appliance has been tested to and complies FOR YOUR SAFETY — If you smell gas: EXPLOSION—FIRE HAZARD with the ANSI Z21.97-2014, Outdoor Decorative • Keep solid combustibles, such as building 1. Shut off gas to the appliance. Gas Appliances CGA CR 97-003 Outdoor Gas materials, paper, or cardboard a safe distance 2. -
Page 5: Assembly Pages
ASSEMBLY PREPARATION Before beginning assembly, empty contents of carton and make sure all parts are present. Place all parts on a soft, level surface for assembly. NOTE: It is best to use TWO PEOPLE to assemble this gas fire pit. Estimated Assembly Time: 60 Minutes | DO NOT over tighten hardware! Assemble the fire pit base: Locate Door Panel D, three Side Panels E/F/G Door Frame Leg H , and 2 Support Legs I . - Page 6 ASSEMBLY Turn the assembled panels down,then attach Tank Support Bar J to Panel 2 and Panel 3 F/G by aligning holes at each end of Tank Support Bar with holes at the bottom of Panel 2 and Panel 3. Insert bolt Q through Washer R into holes ,tighten loosely with Allen Wrench T.
- Page 7 ASSEMBLY Place the Burner B into the hole in the Table Top C. Controls should face door. Pour the Fire Glass L around the Burner B. Be careful not to obstruct the pilot light housing. Put the Removable Burner Cover K on the Burner. Contact us for assistance: (866) 985-7877 | www.wtliving.com...
-
Page 8: Assembly
ASSEMBLY Connect hose and regulator to cylinder. (The propane gas and cylinder are sold separately.) Use a standard 20lb propane cylinder only. Use this fire pit only with a propane vapor withdrawal supply system. See chapter 5 of the standard storage and handling of liquefied petroleum gas, ANSI/NFPA 58. -
Page 9: Operating Instructions Pages
OPERATING INSTRUCTIONS A dented, rusted or damaged propane cylinder may be hazardous and should be checked by your cylinder supplier. Never use a propane cylinder with a damaged valve connection. The propane cylinder must be constructed and marked in accordance with the specifications for LP gas cylinders of the U.S. - Page 10 OPERATING INSTRUCTIONS LEAK CHECK WARNING! • Perform all leak tests outdoors. • Extinguish all open flames • NEVER leak test when smoking. • Do not use the fire pit until all connections have been leak tested and do not leak. Hose / Regulator Regulator / Cylinder Connection...
- Page 11 OPERATING INSTRUCTIONS CAUTION DANGER! Do not attempt to operate until you have read and understand all General Safety FOR OUTDOOR USE ONLY Information in this manual, all assembly is complete, and leak test has been CARBON MONOXIDE HAZARD performed. Never use this product inside a house or other BEFORE TURNING GAS SUPPLY ON: unventilated or enclosed areas.
-
Page 12: Operating Instructions
OPERATING INSTRUCTIONS OPERATION CHECKLIST: WARNING For a safe and pleasant heating experience, perform this check FOR YOUR SAFETY before each use: Be careful when attempting to manually ignite this fire pit. Holding in the control knob for more than 10 seconds before BEFORE OPERATING: igniting the gas will cause a ball of flame I am familiar with entire owner’s manual and understand all... -
Page 13: Care And Maintenance
CARE & MAINTENANCE STORAGE: To enjoy years of outstanding performance from your fire pit, make sure Between Uses: you perform the following maintenance activities on a regular basis: • Turn control knob OFF. • Disconnect LP source. 1. Use warm soapy water for cleaning. Never use flammable or corrosive •... -
Page 14: Troubleshooting
TROUBLESHOOTING CORRECTIVE ACTION PROBLEM POSSIBLE CAUSE Wait until the propane cylinder warms up and becomes Propane cylinder is frosted over unfrosted Burner will not light Clear blockage Blockage in orifice Control knob is not in ON position Turn control knob to ON Gas pressure is low Turn cylinder valve OFF and replace cylinder Outdoor temperature is less than... -
Page 15: Warranty Information
THE PURCHASER. EXTEND YOUR WARRANTY When you purchase a Fire Sense, Patio Sense, or Avalon Home product, you have the peace of mind in knowing that it comes with a one-year warranty. Extend your warranty for an additional year when you write a review of your purchase on www.wtliving.com within 365 days of purchase.
