Kuryakyn 7411 Installation

Z O M B I E L E V E R S f O R h O N D A
fITS: MODELS WITh CABLE OPERATED CLUTChES: hONDA:'88-'07 ShADOW VT600,
'98 & UP ShADOW VT750(ALL MODELS), '94-'04 MAGNA 750, '91-'06 NIGhThAWk CB750,
'95-'07 ShADOW VT1100/C2/C2-2/T, '97-'07 ShADOW VT1100C, '03 & UP VTX 1300 (ALL MODELS)
'04 & UP ShADOW VT750 AERO/SPIRIT
PARTS INCLUDED
1 Zombie Clutch Lever
1 Zombie Brake Lever
2 Lever Bushing
2 Grooved Emblem
2 Zombie Emblem
1 Alcohol Pad
1 Installation Instructions
Please read and understand entire instructions before starting installation.
ThANk YOU fOR ChOOSING küRYAkYN!
IN ORDER TO PROTECT YOU AND OThERS fROM POSSIBLE INjURY
AND/OR PROPERTY DAMAGE OR LOSS, PLEASE PAY CLOSE ATTENTION
TO ALL INSTRUCTIONS, WARNINGS, CAUTIONS AND ATTENTION NOTES
REGARDING ThE USE AND CARE Of ThIS PRODUCT.
WARNING! THIS INDICATION ALERTS YOU TO THE FACT THAT IGNORING THE
CONTENTS DESCRIBED HEREIN CAN RESULT IN POTENTIAL DEATH OR
SERIOUS INJURY.
CAUTION! This indication alerts you to the fact that ignoring the contents described herein
can result in potential injury or material damage.
ATTENTION! This indication alerts you to the fact that ignoring the contents described herein
may negatively affect product performance and functionality.
TOOLS SUGGESTED
Set of hex wrenches, and combination wrenches
STRICTLY OBSERVE ThE fOLLOWING GUIDELINES IN ORDER TO USE ThE
PRODUCT PROPERLY AND AVOID POTENTIALLY DANGEROUS ACCIDENTS.
PROCEDURE: CLUTCh LEVER
STEP 1 Read and understand all steps in the instructions before starting the installation. Park
the motorcycle on a hard, level surface and turn off the ignition.
STEP 2 Tighten the cable adjustment screw on the clutch perch in toward the lever to gain
adequate slack for removing the clutch cable.
STEP 3 When you have enough slack in the cable, you can remove the cable from the lever
by lining up the slot on the adjustment screw and removing the cable from the lever.
STEP 4 Remove the hardware that secures the lever to the perch.
7411-11HD-1108
-cont.-
I N S TA L L AT I O N
7 4 1 1
CUSTOMER SERVICE
877.370.3604 (toll free)
INSTALLATION QUESTIONS
techsupport@kuryakyn.com
LIMITED WARRANTY
Küryakyn warrants that any Küryakyn products sold
hereunder, shall be free of defects in materials and
workmanship for a period of one (1) year from the
date of purchase by the consumer excepting the
• Küryakyn shall have no obligation in the event
the customer is unable to provide a receipt showing
the date the customer purchased the product(s).
• The product must be properly installed,
maintained and operated under normal conditions.
• Küryakyn makes no warranty, expressed or
implied, with respect to any gold plated products.
• Küryakyn shall not be liable for any consequential
and incidental damages, including labor and
paint, resulting from failure of a Küryakyn product,
failure to deliver, delay in delivery, delivery in
nonconforming condition, or for any breech of con-
tract or duty between Küryakyn and a customer.
• Küryakyn products are often intended for use
in specific applications. Küryakyn makes no
warranty if a Küryakyn product is used in
applications other than intended.
• Küryakyn electrical products are warranted for
one (1) year from the date of purchase by the con-
sumer. Components of Küryakyn products containing
L.E.D.s will be warranted for defects in materials and
workmanship for 3 years from the date of purchase.
• Küryakyn makes no warranty of any kind in
regard to other manufacturer's products distributed
by Küryakyn. Küryakyn will pass on all warranties
made by the manufacturer and where possible, will
expedite the claim on behalf of the customer,
but ultimately, responsibility for disposition of the
warranty claim lies with the manufacturer.
ABOUT OUR CATALOG
You'll find all our innovations for H-D, GL and
Metric Cruisers in our annual catalogs. Order
online today–select the "CATALOGS" icon. Each
Küryakyn product comes with a Proof-of-Purchase
®
good for a complimentary catalog.
Be sure to ask your local dealer about other
Küryakyn ® products, the motorcycle parts and
accessories designed for riders by riders.
©2005 Küryakyn USA
or call 715.247.2983
following provisions:
Details in packaging.
® All Rights reserved.
