CONTACT US FIRST CONTACT US FIRST sauder.com sauder.com sauder.com BEFORE MAKING ANY RETURNS TO THE STORE. BEFORE MAKING ANY RETURNS TO THE RETAILER. sauder.com/service Visit to order replacement parts, view video assembly tips, or chat with a live rep. 1-800-523-3987 Prefer the phone? Give us a ring at Customer Service is available Monday-Friday - 8:30 a.m.
LARGE RIGHT DRAWER SIDE (2) LOWER BACK (2) LARGE DRAWER FRONT (2) LARGE LEFT DRAWER SIDE (2) BACK (2) SMALL DRAWER FRONT (2) SMALL DRAWER BACK (2) RIGHT FRONT LEG (2) D954 D954 D151 D151 D954 D954 www.sauder.com/service 424128 Page 3...
Push a HIDDEN CAM into Insert the CAM SCREW into the HIDDEN CAM. the part. The arrow in the Tighten the HIDDEN CAM. HIDDEN CAM must point toward the hole in the edge of the board. Hole Page 6 424128 www.sauder.com/service...
Step 1 Look for this icon. It means a video assembly tip is available at www.sauder.com/service/tips Find the numbered video or scan the QR code. å Assemble your unit on a carpeted floor or on the empty carton to avoid scratching your unit or the floor.
Page 8
Push two HIDDEN CAMS (1F) into a LOWER BACK (I2). Then, insert the metal end of a CAM DOWEL (2F) into each HIDDEN CAM. Do not tighten the HIDDEN CAMS in this step. Arrow Metal end Page 8 424128 www.sauder.com/service...
Page 9
Step 3 å Fasten the LOWER BACK (I2) to the SHELF (G). Tighten two HIDDEN CAMS. Remember: Righty tighty. Lefty loosey. i t h f a c S u r D E N H I D www.sauder.com/service 424128 Page 9...
Page 10
Step 4 å Push four HIDDEN CAMS (1F) into the LOWER ENDS (C2 and D2). Then, insert the metal end of a CAM DOWEL (2F) into each HIDDEN CAM. Arrow Metal end Page 10 424128 www.sauder.com/service...
Page 11
END. Turn a SCREW into this hole. 35MC 35MA Push the black lever in and pull the SLIDE from the RAIL. GOLD 5/16" FLAT HEAD SCREW (4 used in this step) Open end Finished edge Open end Finished edge www.sauder.com/service 424128 Page 11...
Page 12
Step 6 å Fasten the LOWER ENDS (C2 and D2) to the SHELF (G). Caution Tighten four HIDDEN CAMS. Do not stand the unit upright without the BACK fastened. The unit may collapse. Page 12 424128 www.sauder.com/service...
Page 13
Step 7 å Push four HIDDEN CAMS (1F) into a BOTTOM (F2). Arrow Arrow www.sauder.com/service 424128 Page 13...
Page 14
Fasten the BOTTOM (F2) to the LOWER ENDS (C2 and D2). Use six BLACK 1-7/8" FLAT HEAD SCREWS (2S). å Repeat steps 1-8 to assemble the remaining drawer box. BLACK 1-7/8" FLAT HEAD SCREW (6 used in this step) Page 14 424128 www.sauder.com/service...
Page 15
Turn four CAM SCREWS (8F) into the LEGS (L2 and O2). å Push three HIDDEN CAMS (1F) into the UPPER LEFT END (B). Then, insert the metal end of a CAM DOWEL (2F) into each HIDDEN CAM. Arrow Arrow Metal end Metal end www.sauder.com/service 424128 Page 15...
Page 16
Fasten the UPPER LEFT END (B) to the LEFT LEGS (L2 and O2). Use four BLACK 1-1/8" PAN HEAD SCREWS (9S). å NOTE: Start each SCREW a few turns before completely tightening any of them. BLACK 1-1/8" PAN HEAD SCREW (4 used in this step) Finished edge Page 16 424128 www.sauder.com/service...
Page 17
Step 11 å Fasten the SHELF (G) and BOTTOM (F2) to the LEFT LEGS (L2 and O2). Tighten four HIDDEN CAMS. www.sauder.com/service 424128 Page 17...
Page 18
Turn four CAM SCREWS (8F) into the LEGS (K2 and P2). å Push three HIDDEN CAMS (1F) into the UPPER RIGHT END (A). Then, insert the metal end of a CAM DOWEL (2F) into each HIDDEN CAM. Arrow Metal end Arrow Metal end Page 18 424128 www.sauder.com/service...
Page 19
Use four BLACK 1-1/8" PAN HEAD SCREWS (9S). å NOTE: Start each SCREW a few turns before completely tightening any of them. BLACK 1-1/8" PAN HEAD SCREW (4 used in this step) Finished edge Edge with CAM DOWELS www.sauder.com/service 424128 Page 19...
Page 20
Step 14 å Fasten the LEGS (K2 and P2) to the SHELF (G) and BOTTOM (F2) . Tighten four HIDDEN CAMS. Page 20 424128 www.sauder.com/service...
Page 21
NOTE: Be sure the BRACKETS are even with the edges of the SKIRTS. å Fasten the SKIRTS (Q2) to the BOTTOM (F2). Use four BLACK 9/16" LARGE HEAD SCREWS (1S). BLACK 9/16" LARGE HEAD SCREW (8 used in this step) www.sauder.com/service 424128 Page 21...
Page 22
Turn four CAM SCREWS (8F) into the LEGS (L2 and N2). å Push three HIDDEN CAMS (1F) into the remaining UPPER LEFT END (B). Then, insert the metal end of a CAM DOWEL (2F) into each HIDDEN CAM. Arrow Arrow Metal end Metal end Page 22 424128 www.sauder.com/service...
Page 23
Rome. This can be built å NOTE: Start each SCREW a few turns before completely in a day. tightening any of them. BLACK 1-1/8" PAN HEAD SCREW (4 used in this step) Edge with CAM DOWELS Finished edge www.sauder.com/service 424128 Page 23...
Page 24
Step Step 18 å Fasten the SHELF (G) and BOTTOM (F2) to the LEGS (L2 and N2). Tighten four HIDDEN CAMS. Page 24 424128 www.sauder.com/service...
Page 25
Turn four CAM SCREWS (8F) into the RIGHT LEGS (K2 and M2). å Push three HIDDEN CAMS (1F) into the remaining UPPER RIGHT END (A). Then, insert the metal end of a CAM DOWEL (2F) into each HIDDEN CAM. Arrow Metal end Arrow Metal end www.sauder.com/service 424128 Page 25...
Page 26
Use four BLACK 1-1/8" PAN HEAD SCREWS (9S). å NOTE: Start each SCREW a few turns before completely tightening any of them. BLACK 1-1/8" PAN HEAD SCREW (4 used in this step) Finished edge Edge with CAM DOWELS Page 26 424128 www.sauder.com/service...
Page 27
Step 21 å Fasten the RIGHT LEGS (K2 and M2) to the SHELF (G) and BOTTOM (F2) . Tighten four HIDDEN CAMS. www.sauder.com/service 424128 Page 27...
Page 28
NOTE: Be sure the BRACKETS are even with the edges of the SKIRTS. å Fasten the SKIRTS (Q2) to the BOTTOM (F2). Use four BLACK 9/16" LARGE HEAD SCREWS (1S). BLACK 9/16" LARGE HEAD SCREW (8 used for the METAL BRACKETS Page 28 424128 www.sauder.com/service...
Page 29
2. Tighten the FASTENER with a Phillips screwdriver as tight as possible. Dowel end Step 23 å Push two SAUDER TWIST-LOCK® FASTENER (12F) into the large holes in the LARGE BACK (H). Do not tighten the TWIST-LOCK® FASTENERS in this step. www.sauder.com/service 424128...
Page 30
Step 24 å Carefully stand your unit upright. å Fasten the BACKS (J2) to the UPPER ENDS (A and B). Tighten four HIDDEN CAMS. Page 30 424128 www.sauder.com/service...
Page 31
Step Step 25 å Push two HIDDEN CAMS (1F) into the LARGE BACK (H). å Turn two CORD CLIPS (9P) into the LARGE BACK (H). Arrow Arrow www.sauder.com/service 424128 Page 31...
Page 32
Fasten the LARGE BACK (H) to the CENTER REAR LEGS (N2 and P2). Tighten two HIDDEN CAMS. Notch N E R S T E i t h ® F A f a c S u r - L O I S T Page 32 424128 www.sauder.com/service...
Page 33
SCREWS (3S) through holes #1 and #3. å NOTE: The CABINET RAILS are marked "CABINET RIGHT" and "CABINET LEFT" for easy identification. GOLD 5/16" FLAT HEAD SCREW (8 used for the CABINET RAILS) Roller end Roller end www.sauder.com/service 424128 Page 33...
Page 34
Fasten the TOP (E2) to the UPPER ENDS (A and B). Tighten eight HIDDEN CAMS. å Turn two CORD CLIPS (9P) into the bottom surface of the TOP (E2). The large hole is closer to this edge. Page 34 424128 www.sauder.com/service...
Page 35
Fasten the SMALL DRAWER BACK (D66) to the SMALL DRAWER SIDES (D18 and D19). Use four BLACK 1-9/16" FLAT HEAD SCREWS (30S). å NOTE: Be sure the DRAWER BOTTOM (D954) inserts into the groove of the SMALL DRAWER BACK (D66). å Repeat this step for the remaining small drawer. www.sauder.com/service 424128 Page 35...
Page 36
SLIDES with holes in SILVER 1/2" MACHINE SCREW DRAWER SIDES (4 used for the PULL) Roller end 176K Drawer Slide GOLD 5/16" FLAT HEAD SCREW (8 used for the SLIDES) Center the screw in the oval hole. Page 36 424128 www.sauder.com/service...
Page 37
Fasten the LARGE DRAWER BACK (D151) to the LARGE DRAWER SIDES (D28 and D29). Use four BLACK 1-9/16" FLAT HEAD SCREWS (30S). å NOTE: Be sure the DRAWER BOTTOM (D954) inserts into the groove of the LARGE DRAWER BACK (D151). å Repeat this step for the remaining large drawer. www.sauder.com/service 424128 Page 37...
Page 38
(4 used for the PULL) Open end Screw head - turn CAM to line up holes in the SLIDES with holes in DRAWER SIDES Open end 176K GOLD 5/16" FLAT HEAD SCREW (8 used for the SLIDES) Page 38 424128 www.sauder.com/service...
Page 39
å Slide another FILE GLIDE (15B) onto the other end of the FILE RODS (7B), then press this FILE GLIDE over the LARGE LEFT DRAWER SIDE (D29). å Repeat this step for the remaining large drawer. www.sauder.com/service 424128 Page 39...
Page 40
EXTENSION RAILS on the unit and push the drawer into the unit until the drawer is fully inserted. The drawer will push in hard until it is all the way in, then it will slide in and out easier. Page 40 424128 www.sauder.com/service...
Page 41
Step Step 35 å Using your hammer, gently tap a CAM COVER (75P) onto each HIDDEN CAM. www.sauder.com/service 424128 Page 41...
Page 42
å This completes assembly. Clean with a damp cloth. Wipe dry. And to celebrate, why not share your success story at sauder.com or Loosen screw #3 a 1/4 turn, turn the cam a 1/4 turn maximum in both the clockwise and counter-clockwise directions to make adjustments, and then tighten screw #3.
