Sauder Shoal Creek Series Manual

Queen platform bed
Hide thumbs Also See for Shoal Creek Series:

Advertisement

Quick Links

Download this manual
sauder.com
Queen Platform Bed
Shoal Creek Collection | 414866
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
You are getting sleepy.
Very sleepy.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-20
Français pg 21-23
Español pg 24-26
Lot # 355798
10/03/13
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987

Advertisement

loading

Related Manuals for Sauder Shoal Creek Series

Summary of Contents for Sauder Shoal Creek Series

  • Page 1 Shoal Creek Collection | 414866 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR Prefer the phone? Call 1-800-523-3987. FUTURE REFERENCE.
  • Page 2 SLAT (5) HEAD UPRIGHT (2) DRAWER BRACE (2) FOOT UPRIGHT (2) RIGHT DRAWER SIDE (2) DRAWER UPRIGHT (2) LEFT DRAWER SIDE (2) RIGHT LONG TOP (1) DRAWER BACK (2) LEFT LONG TOP (1) D986 DRAWER BOTTOM (2) Page 2 414866 www.sauder.com/services...

  • Page 3: Part Identification

    Part Identifi cation D986 D986 www.sauder.com/services 414866 Page 3...

  • Page 4: Hardware Identification

    GOLD 5/16" FLAT HEAD SCREW - 16 SILVER 1-1/8" FLAT HEAD SCREW - 8 15S SILVER 5/8" MACHINE SCREW - 4 30S BLACK 1-9/16" FLAT HEAD SCREW - 10 SILVER 1-1/4" PAN HEAD SCREW - 24 Page 4 414866 www.sauder.com/services...
  • Page 5 Look for this icon. It means a Step 1 video assembly tip is available at www.sauder.com/services/tips Assemble your unit on a carpeted fl oor or on the empty carton å to avoid scratching your unit or the fl oor. NOTE: Assemble the bed in the room of its fi nal location.
  • Page 6 DRAWER BRACES (T). Turn two CAM SCREWS (20F) into the å DRAWER FRONTS (Q and R). Arrow Arrow Hole The arrow in the HIDDEN CAM must point toward the hole in the edge of the board. Page 6 414866 www.sauder.com/services...
  • Page 7 Step 3 NOTE: This bed has the option for the DRAWERS to be on å either side. DRAWERS on the left side of your bed. DRAWERS on the right side of your bed. www.sauder.com/services 414866 Page 7...
  • Page 8 UPRIGHTS. Turn a SCREW into this hole. Open end GOLD 5/16" FLAT HEAD SCREW (4 used in this step) Push the black lever in and pull the SLIDE from the RAIL. Page 8 414866 www.sauder.com/services...
  • Page 9 (4 used in this step) Open end Use the upper diagram if you are putting the DRAWERS on the left. Open end Open end Use the lower diagram if you are putting the DRAWERS on the right. Open end www.sauder.com/services 414866 Page 9...
  • Page 10 å UPRIGHTS (G). Use four BLACK 1-7/8" FLAT These holes must be up. HEAD SCREWS (2S). Finished edge r f a w i t (8 used) BLACK 1-7/8" FLAT HEAD SCREW (4 used in this step) Page 10 414866 www.sauder.com/services...
  • Page 11 D E N i t h S u r f a c The EXTENSION RAILS H I D i t h o D E N should be closer to the fl oor. DRAWERS on the left www.sauder.com/services 414866 Page 11...
  • Page 12 Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To Minimum completely tighten: 190 degrees Page 12 414866 www.sauder.com/services...
  • Page 13 NOTE: END (C) will hang over the UPRIGHTS (H, I, and J). å BLACK 1-7/8" FLAT HEAD SCREW (4 used in this step) Hole is closer to the bottom edge. Hole is closer to the top edge. www.sauder.com/services 414866 Page 13...
  • Page 14 HEAD UPRIGHTS (H) as shown in the lower diagram. Tighten eight HIDDEN CAMS. SILVER 1-1/8" FLAT HEAD SCREW (8 used for the BACK) Unfi nished edge Unfi nished surface Unfi nished edge Maximum Arrow 210 degrees Minimum 190 degrees Finished surface Page 14 414866 www.sauder.com/services...
  • Page 15 Unfi nished surface These two holes must be closer to this edge. Unfi nished edge Maximum Arrow The two Finished 210 degrees holes on the surface oppposite surface must Minimum be closer to 190 degrees this edge. www.sauder.com/services 414866 Page 15...
  • Page 16 (24 used in this step) Rounded edge If the TOPS (K, L, and M) have an unfi nished surface, it should be facing up. The holes in the TOPS (K, L, and M) must be closer to the inside edge. Page 16 414866 www.sauder.com/services...
  • Page 17 F u l l / Q u e e e a d b o a Caution Carefully lift and lower onto the bed. Two person lift required Lift here. SILVER 2” BOLT (4 used for the Headboard) www.sauder.com/services 414866 Page 17...
  • Page 18 FRONT (Q). Tighten one HIDDEN CAM. Fasten the DRAWER BACK (D80) to the DRAWER å SIDES (D50 and D51) and DRAWER BRACE (T). Use fi ve BLACK 1-9/16" FLAT HEAD SCREWS. Repeat this step for the other drawer. å Page 18 414866 www.sauder.com/services...
  • Page 19 Repeat this step for the other drawer. å Open end Open end (2 used) SILVER 5/8" MACHINE SCREW (4 used for the PULLS) (4 screws per drawer) GOLD 5/16" FLAT HEAD SCREW (8 used for the SLIDES) www.sauder.com/services 414866 Page 19...
  • Page 20 This completes assembly. Clean with your favorite furniture polish or a damp cloth. Wipe dry. å And to celebrate, why not share your success story? Loosen the sets of screws in the corner of the drawer to make vertical and horizontal adjustments to the DRAWER FRONTS. 25 lbs. 25 lbs. Page 20 414866 www.sauder.com/services...

  • Page 21: Liste De Pièces

    élément et conserver le livret pour future référence. EXTRÉMITÉ DE TÊTE ............. 1 (ENSEMBLE DE GLISSIÈRE ILLUSTRÉ À PART) Pour contacter Sauder EXTRÉMITÉ DE PIED ............1 GLISSIÈRE D'EXTENSION .........2 en ce qui concerne cet LONGUE EXTRÉMITÉ SUPÉRIEURE COULISSE D'EXTENSION .........2...
  • Page 22 VIS dans le trou indiqué dans le schéma agrandi. Ensuite, enfi ler la cartouche interne de la GLISSIÈRE D'EXTENSION vers l'intérieur pour trouver l'autre trou qui est aligné sur le trou dans les MONTANTS. Faire tourner une VIS dans ce trou. Page 22 414866 www.sauder.com/services...
  • Page 23 Utiliser dix VIS TÊTE PLATE 48 mm NOIRES (2S). DROIT (Q) sera le plus près de la TÊTE DE LIT. Ceci complète l'assemblage. Nettoyer à l’ a ide d’une encaustique pour meubles ou d’un chiff on humide. Essuyer. www.sauder.com/services 414866 Page 23...

  • Page 24: Lista De Partes

    EXTREMO DEL PIE ............... 1 RIEL DE EXTENSIÓN ..............2 Pour contacter Sauder EXTREMO LARGO SUPERIOR POSTERIOR ... 1 CORREDERA DE EXTENSIÓN..........2 en ce qui concerne cet EXTREMO LARGO INFERIOR POSTERIOR....1 EXCÉNTRICO ESCONDIDO ..........26...
  • Page 25 A continuación deslice el cartucho interno del RIEL DE EXTENSIÓN hacia el interior para encontrar el otro agujero que se alinea con el agujero de los PARALES. Atornille un TORNILLO dentro de este agujero. www.sauder.com/services 414866 Page 25...
  • Page 26 NOTA: Si los cajones están en el otro lado de la cama, el CAJÓN DERECHA (Q) estará más cerca a la CABECERA. Esto completa el ensamblaje. Limpie con su pulimento para muebles preferido o un paño húmedo. Seque con un paño. Page 26 414866 www.sauder.com/services...

  • Page 27: Year Limited Warranty

    GARANTIE LIMITÉE DE 5 ANS 1. Sauder Woodworking Co. (Sauder®) off re une couverture de garantie limitée à l’ a cheteur 4. La présente garantie ne s’ a pplique qu’ a ux défauts garantis qui se produisent pour initial du présent produit pendant une période de cinq ans à...
  • Page 28 Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
