Sauder Entertainment Credenza Installation Manual

Camarin collection
Hide thumbs Also See for Entertainment Credenza:

Advertisement

Quick Links

Download this manual See also: Instruction Booklet
sauder.com
Entertainment Credenza
Camarin Collection | 414802
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
Entertaining what
entertains you.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-24
Français pg 23-25
Español pg 26-28
Lot # 362999
06/25/14
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987

Advertisement

loading
Need help?

Need help?

Do you have a question about the Entertainment Credenza and is the answer not in the manual?

Questions and answers

Related Manuals for Sauder Entertainment Credenza

Summary of Contents for Sauder Entertainment Credenza

  • Page 1 Camarin Collection | 414802 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987. English pg 1-24 Français pg 23-25...
  • Page 2 • Check the size and weight of your TV. Compare it to the diagram below – before you begin assembly! • This Sauder unit is designed for use with televisions weighing less than 95 pounds. Never use with a TV that weighs more.
  • Page 3 LEFT FRONT/RIGHT REAR LEFT UPRIGHT (1) BOTTOM (1) FOOT (2) RIGHT DRAWER SIDE (2) SHELF (1) RIGHT FRONT/LEFT REAR FOOT (2) LEFT DRAWER SIDE (2) BACK (1) CENTER FOOT (2) DRAWER BACK (2) ADJUSTABLE SHELF (1) D720 D720 www.sauder.com/services 414802 Page 3...
  • Page 4 LL BLACK 1-9/16" FLAT HEAD SCREW - 8 BLACK 1-15/16" FLAT HEAD SCREW - 10 BLACK 9/16" LARGE HEAD SCREW - 35 GOLD 1" MACHINE SCREW - 2 OO GOLD 5/16" FLAT HEAD SCREW - 16 NAIL - 48 Page 4 414802 www.sauder.com/services...
  • Page 5 Look for this icon. It means a Step 1 video assembly tip is available at www.sauder.com/services/tips Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. Push ten HIDDEN CAMS (Y) into the ENDS (A and B), å...
  • Page 6 UPRIGHT (C). Use eight GOLD 5/16" FLAT HEAD Righty tighty. SCREWS (OO) through holes #1 and #3. Lefty loosey. Rounded edge Roller end GOLD 5/16" FLAT HEAD SCREW (8 used in this step) Roller end Finished edge Page 6 414802 www.sauder.com/services...
  • Page 7 Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To Minimum completely tighten: 190 degrees www.sauder.com/services 414802 Page 7...
  • Page 8 Fasten the SHELF (H) to the UPRIGHT (E). Use two å BLACK 1-15/16" FLAT HEAD SCREWS (KK). BLACK 1-15/16" FLAT HEAD SCREW (2 used in this step) Finished edge Maximum Arrow 210 degrees Minimum 190 degrees Page 8 414802 www.sauder.com/services...
  • Page 9 UPRIGHT (D) into the holes in the SHELF (H). r f a w i t l e s S u r f a c H I D D E N i t h Finished edge Maximum Arrow 210 degrees Minimum 190 degrees www.sauder.com/services 414802 Page 9...
  • Page 10 Fasten the RIGHT END (A) to the TOP (F) and SHELF (H). å Tighten four HIDDEN CAMS. i t h f a c S u r D E N H I D Rounded edge Maximum Arrow 210 degrees Minimum 190 degrees Page 10 414802 www.sauder.com/services...
  • Page 11 Fasten the BOTTOM (G) to the ENDS (A and B) and å UPRIGHTS (C and D). Use eight BLACK 1-15/16" FLAT HEAD SCREWS (KK). BLACK 1-15/16" FLAT HEAD SCREW (8 used in this step) Rounded edge www.sauder.com/services 414802 Page 11...
  • Page 12 Use eight BLACK 9/16" LARGE HEAD SCREWS (NN). Then, fasten the FEET (R and S) to the SIDE SKIRTS (L). å Use eight BLACK 9/16" LARGE HEAD SCREWS (NN). BLACK 9/16" LARGE HEAD SCREW (16 used in this step) Finished edge Page 12 414802 www.sauder.com/services...
  • Page 13 FEET (R and S). Fasten the SIDE SKIRTS (L) and FEET (R and S) to å the BOTTOM (G). Use eight BLACK 9/16" LARGE HEAD SCREWS (NN). BLACK 9/16" LARGE HEAD SCREW (8 used CORNER BRACKETS) www.sauder.com/services 414802 Page 13...
  • Page 14 Step 10 Fasten three METAL BRACKETS (DD) to the FRONT å SKIRT (K) and BOTTOM (G). Use six BLACK 9/16" LARGE HEAD SCREWS (NN) BLACK 9/16" LARGE HEAD SCREW (6 used in this step) Page 14 414802 www.sauder.com/services...
  • Page 15 CENTER FEET (T). Use two BLACK 9/16" LARGE HEAD SCREWS (NN). NOTE: There are no pre-drilled holes in the CENTER å FEET. The screws will tighten into the grooves. BLACK 9/16" LARGE HEAD SCREW (5 used FOOT BRACKET) Groove www.sauder.com/services 414802 Page 15...
  • Page 16 NOTE: Perforations have been provided for access å through the BACK. Carefully cut out the holes needed. These holes must line up over the SHELF (H) and UPRIGHTS (C and D). NAIL (48 used in this step) Page 16 414802 www.sauder.com/services...
  • Page 17 Fasten the DRAWER BACK (D73) to the DRAWER SIDES (D16 and D17). Use four BLACK 1-9/16" FLAT HEAD SCREWS (LL). å NOTE: Be sure the DRAWER BOTTOM (D720) inserts into the groove of the DRAWER BACK (D73). å Repeat this step for the remaining drawer. å www.sauder.com/services 414802 Page 17...
  • Page 18 Repeat this step for the other drawer. å Roller end Screw head - turn CAM to line up holes in the SLIDES with holes in DRAWER SIDES Roller end GOLD 5/16" FLAT HEAD SCREW (8 used in this step) Page 18 414802 www.sauder.com/services...
  • Page 19 Step 15 Fasten a KNOB (EE) to the DRAWER FRONT (M). Use a å GOLD 1" MACHINE SCREW (MM). Repeat this step for the other drawer. å GOLD 1" MACHINE SCREW (2 used for the KNOBS) www.sauder.com/services 414802 Page 19...
  • Page 20 Lift the front of the drawer up and slide it into the unit. Repeat this for the other drawer. å Place the roller on the SLIDE behind the roller on the RAIL. Page 20 414802 www.sauder.com/services...
  • Page 21 - The TV must weigh less than 95 lbs. - The base of the TV must be able to sit completely on this shelf. 30 lbs. total 95 lbs. 25 lbs. 40 lbs. 15 lbs. 15 lbs. (4 used) www.sauder.com/services 414802 Page 21...
  • Page 22 #4. The higher the screw in the oblong hole, the higher your drawer front will be. The lower the screw, the lower the drawer front. Page 22 414802 www.sauder.com/services...

  • Page 23: Français

    élément et conserver le livret pour future référence. EXTRÉMITÉ DROITE ......1 35GA ÉLÉMENT DROITE .......2 Pour contacter Sauder EXTRÉMITÉ GAUCHE ....1 35GB ÉLÉMENT GAUCHE .....2 en ce qui concerne cet MONTANT DROIT......1 35GC TIROIR DROIT ......2 élément, faire référence...
  • Page 24 ÉTAPE 5 ci-dessous avant de commencer l'assemblage ! • Cette unité Sauder est conçue pour les téléviseurs pesant moins de 43 Fixer le MONTANT DROIT (C) à la TABLETTE (H). Serrer deux kg. Ne jamais utiliser avec des téléviseurs plus lourds.
  • Page 25 TÊTE PLATE 8 mm DORÉES (OO) à travers les trous nº 1 et nº 3. REMARQUE : La tête de vis dans l'EXCENTRIQUE doit être visible à travers le trou fendu dans la COULISSE. Répéter cette étape pour l'autre tiroir. www.sauder.com/services 414802 Page 25...

  • Page 26: Español

    EXCÉNTRICO ESCONDIDO ......10 et conserver le livret pour future référence. EXTREMO IZQUIERDO ........... 1 PASADOR DE EXCÉNTRICO ......10 Pour contacter Sauder PARAL DERECHO ............... 1 CUBIERTA DE ESQUINA ........1 en ce qui concerne cet PARAL IZQUIERDO ............1 SOPORTE DE PATA ............1 élément, faire référence...
  • Page 27 PASO 5 antes de comenzar el ensamblaje! • Esta unidad Sauder está diseñada para ser usada con televisores cuyo Fije el PARAL DERECHO (C) al ESTANTE (H). Apriete dos peso sea inferior a 43 Kg. Nunca la use para un televisor de mayor peso.
  • Page 28 CABEZA PERDIDA de 8 mm (OO) a través de los agujeros No. 1 y No. 3. NOTA: La cabeza de tornillo del EXCÉNTRICO debe ser visible a través del agujero alargado de la CORREDERA. Repita este paso para el otro cajón. Page 28 414802 www.sauder.com/services...

  • Page 29: Safety

    équipé. • Blessure physique. Le mobilier peut être très lourd. • Ne pas pousser le mobilier, surtout sur la moquette. Se faire aider par une autre personne pour soulever l’élément et le mettre en place. www.sauder.com/services 414802 Page 29...
  • Page 30 • Lesión física. El mobiliario puede ser • No empuje la unidad, especialmente muy pesado. sobre un piso alfombrado. Pide la ayuda de otra persona en levantar la unidad y colocarla en lugar. Page 30 414802 www.sauder.com/services...

  • Page 31: Warranty

    GARANTIE LIMITÉE DE 5 ANS 1. Sauder Woodworking Co. (Sauder®) off re une couverture de garantie limitée à l’ a cheteur 4. La présente garantie ne s’ a pplique qu’ a ux défauts garantis qui se produisent pour initial du présent produit pendant une période de cinq ans à...

  • Page 32: Page.

    Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
