Summary of Contents for Sauder Jaclyn Smith 416404

  • Page 1 Jaclyn Smith Gatsby Collection | 416404 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.
  • Page 2 BOTTOM MOLDING (1) TOP (1) DRAWER BRACE (6) BOTTOM (1) RIGHT DRAWER SIDE (6) CENTER SUPPORT (1) LEFT DRAWER SIDE (6) BACK (1) DRAWER BACK (6) FRONT SKIRT (1) D733 DRAWER BOTTOM (6) RIGHT DRAWER FRONT (3) Page 2 416404 www.sauder.com/services...
  • Page 3 Part Identifi cation D733 D733 www.sauder.com/services 416404 Page 3...
  • Page 4 BLACK 9/16" LARGE HEAD SCREW - 12 BLACK 1-7/8" FLAT HEAD SCREW - 6 GOLD 5/16" FLAT HEAD SCREW - 48 BLACK 1-1/4" FLAT HEAD SCREW - 28 BLACK 1-9/16" FLAT HEAD SCREW - 30 BLACK 7/8" MACHINE SCREW - 6 Page 4 416404 www.sauder.com/services...
  • Page 5 Look for this icon. It means a Step 1 video assembly tip is available at www.sauder.com/services/tips Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. Push sixteen HIDDEN CAMS (1F) into the ENDS (A and B), å...
  • Page 6 Step 2 Insert six CAM SCREWS (8F) into the DRAWER å FRONTS (I and J). (6 used) Page 6 416404 www.sauder.com/services...
  • Page 7 END. Turn a SCREW into this hole. Finished edge Open end Finished edge Finished edge GOLD 5/16" FLAT HEAD SCREW (24 used in this step) Open end Push the release lever in and pull the SLIDE from the RAIL. www.sauder.com/services 416404 Page 7...
  • Page 8 Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To Minimum completely tighten: 190 degrees Page 8 416404 www.sauder.com/services...
  • Page 9 Use four BLACK 1-7/8" FLAT HEAD SCREWS (2S). These holes must be here. S u r f a c i t h H I D D E N BLACK 1-7/8" FLAT HEAD SCREW (6 used in this step) www.sauder.com/services 416404 Page 9...
  • Page 10 D E N H I D Finished edge i t h o f a c S u r D E N (4 used) H I D Maximum Arrow 210 degrees Minimum 190 degrees Page 10 416404 www.sauder.com/services...
  • Page 11 (12 used for the METAL BRACKETS) Finished surface Rounded edge BLACK 1-1/4" FLAT HEAD SCREW (4 used in this step) S u r f a c i t h o u t h o l e www.sauder.com/services 416404 Page 11...
  • Page 12 Push on opposite corners of your unit if needed to make BACK fastened. The unit may collapse. it “square”. Fasten the BACK (G) to your unit using the NAILS (1N). å Cut-out should be here. NAIL (38 used in this step) Page 12 416404 www.sauder.com/services...
  • Page 13 BLACK 1-1/4" FLAT HEAD SCREWS (7S). Repeat this step for the remaining DRAWER å MOLDINGS (K) and DRAWER FRONTS (I and J). Use sixteen BLACK 1-1/4" FLAT HEAD SCREWS (7S). BLACK 1-1/4" FLAT HEAD SCREW (24 used in this step) www.sauder.com/services 416404 Page 13...
  • Page 14 D31) and DRAWER BRACE (M). Use five BLACK 1-9/16" FLAT DRAWER FRONT (I). Tighten one HIDDEN CAM. HEAD SCREWS. (30S). Repeat this step for the other DRAWERS using the remaining RIGHT DRAWER FRONTS (I) and LEFT DRAWER FRONTS (J). Page 14 416404 www.sauder.com/services...
  • Page 15 Repeat this step for the remaining drawers. å Open end Screw head - turn CAM to line up holes in the SLIDES with holes in DRAWER SIDES Open end GOLD 5/16" FLAT HEAD SCREW (24 used in this step) www.sauder.com/services 416404 Page 15...
  • Page 16 Step 12 Fasten a PULL (82K) to the RIGHT DRAWER FRONT (I). å Use a BLACK 7/8" MACHINE SCREW (37S). Repeat this step for the remaining drawers. å BLACK 7/8" MACHINE SCREW (6 used in this step) Page 16 416404 www.sauder.com/services...
  • Page 17 Once applied, do not try to remove it. Use of tip-over restraints may only reduce, but not eliminate, the risk of tip-over. 40 lbs. D733 35 lbs. 35 lbs. 35 lbs. www.sauder.com/services 416404 Page 17...
  • Page 18 The higher the screw in the oblong hole, the higher your drawer front will be. The lower the screw, the lower the drawer front. Page 18 416404 www.sauder.com/services...
  • Page 19 élément et conserver le livret pour future référence. EXTRÉMITÉ DROITE ..........1 (ENSEMBLE DE GLISSIÈRE ILLUSTRÉ À PART) Pour contacter Sauder EXTRÉMITÉ GAUCHE ..........1 GLISSIÈRE D'EXTENSION ........12 en ce qui concerne cet MONTANT................1 COULISSE D'EXTENSION ........12 élément, faire référence...
  • Page 20 DROIT (I) et sur le DEVANT DE TIROIR GAUCHE (J). Utiliser huit VIS TÊTE PLATE 32 mm NOIRES (7S). Répéter cette étape pour les autres MOULURES DE TIROIR (K) et les DEVANTS DE TIROIR (I et J). Utiliser seize VIS TÊTE PLATE 32 mm NOIRES (7S). Page 20 416404 www.sauder.com/services...
  • Page 21 Fixer une POIGNÉE (82K) sur le DEVANT DE TIROIR DROIT (I). Ceci complète l'assemblage. Pour nettoyer l’unité, humidifi er un Utiliser une VIS À MÉTAUX 22 mm NOIRE (37S). chiff on avec de l’eau du robinet et essuyer. Répéter cette étape pour les autres tiroirs. www.sauder.com/services 416404 Page 21...
  • Page 22 (JUEGO DE EXTENSIÓN SE MUESTRA POR et conserver le livret SEPARADO) EXTREMO IZQUIERDO ............1 pour future référence. RIEL DE EXTENSIÓN ..........12 Pour contacter Sauder PARAL ....................1 en ce qui concerne cet CORREDERA DE EXTENSIÓN ......12 PANEL SUPERIOR ..............1 élément, faire référence 10A EXCÉNTRICO DE CORREDERA .....12...
  • Page 23 TORNILLOS NEGROS DE CABEZA PERDIDA de 32 mm (7S). DE CABEZA PERDIDA de 48 mm (2S). Fije el SOPORTE DEL CENTRO (F) al FONDO (E). Utilice cuatro TORNILLOS NEGROS DE CABEZA PERDIDA de 48 mm (2S). www.sauder.com/services 416404 Page 23...
  • Page 24 PASO 12 Fije un TIRADOR (82K) a la CARA DERECHA DE CAJÓN (I). Utilice un TORNILLO NEGRO PARA METAL de 22 mm (37S). Repita este paso para los cajones que quedan. Page 24 416404 www.sauder.com/services...
  • Page 25 équipé. • Blessure physique. Le mobilier peut • Ne pas pousser le mobilier, surtout sur la être très lourd. moquette. www.sauder.com/services 416404 Page 25...
  • Page 26 • No empuje la unidad, especialmente • Lesión física. El mobiliario puede ser sobre un piso alfombrado. muy pesado. Page 26 416404 www.sauder.com/services...
  • Page 27 GARANTIE LIMITÉE DE 1 AN 1. Sauder Woodworking Co. (Sauder®) off re une couverture de garantie limitée à l’ a cheteur 4. La présente garantie ne s’ a pplique qu’ a ux défauts garantis qui se produisent pour initial du présent produit pendant une période un an à...
  • Page 28 Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
