Lithonia Lighting QUANTUM LHQM LED Manual

FEATURES & SPECIFICATIONS
INTENDED USE — Suitable for applications requiring both exit sign and unit equipment. Attractive, 8"
tall, streamlined design is great for above-the-door applications and other tight fits. Optional high-output
version with remote lamps are ideal for emergency egress lighting. Certain airborne contaminants
can diminish integrity of acrylic and/or polycarbonate.
Compatibility table for suitable uses.
CONSTRUCTION — Engineering-grade thermoplastic housing is impact-resistant, scratch-resistant and
corrosion-proof. UL94V-O flame rating. UV-stable resin resists discoloration from natural and man-made
light sources.
Rugged unibody housing snaps together with no additional fasteners. Faceplate and back cover are inter-
changeable on housing. Positive snap-fit tabs hold faceplate securely, yet are easily removable for lamp
compartment access. Universal, directional chevron inserts are easily removed and reinserted.
Uniform graphics illumination without shadows or hot spots. Letters are 6" high with 3/4" stroke, with 100 ft.
viewing distance rating based upon UL924 standard.
LEDs mounted on primary circuit boards for sign illumination. Low-energy LED lamp in sign operates in normal
(AC input) and emergency (DC input) modes.
Low-profile, integrated test switch/pilot light. Easily viewed bright red status indicator.
Unique track-and-swivel arrangement permits full range of direction of lamp head adjustment. Universal J-box
mounting pattern. Tool-less access for maintenance. Conduit entry position on top of unit.
U.S. Patent No. 6,848,798; 6,499,866; 6,142,648; 5,797,673; D379,373; 5,526,251; D484,272;
D473,672; 5,611,163; 5,646,502.
OPTICS — Twin LED lamp heads operate in emergency (DC input) mode with 12 series-parallel white LEDs
in each head. Provides redundant light sources to ensure emergency lighting performance. The typical life of
the exit LED lamp is 10 years.
ELECTRICAL — Dual-voltage input capability (120/277V). Edge connector on printed circuit board ensures
long-term durability.
Current-limiting charger maximizes battery life and minimizes energy consumption. Provides low operating
costs.
Short-circuit protection — current-limiting charger circuitry protects printed circuit board from shorts.
Thermal compensation adjusts charger output to provide optimum charge voltage relative to ambient
temperature.
Regulated charge voltage maintains constant-charge voltage over a wide range of line voltages. Prevents over/
undercharging that shortens battery life and reduces capacity.
Filtered charger input minimizes charge voltage ripple and extends battery life.
AC/LVD reset allows battery connection before AC power is applied and prevents battery damage from
deep discharge.
Single multi-color LED indicator to display two-state charging, test activation and three-state diagnostic test.
Test switch provides manual activation of 30-second diagnostic testing for on-demand visual inspection.
Self-diagnostic testing for 30 seconds every 30 days, 30 minutes at 180-day interval, and 90 minutes annually.
Diagnostic evaluation of LED light source, AC-to-DC transfer, charging and battery condition.
Battery: Sealed, maintenance-free nickel-cadmium battery delivers 90-minute capacity to emergency
lamps. Two-state contstant-current charge maximizes battery life and automatically recharges after battery
discharge. Low-voltage disconnect prevents excessively deep discharge that can permanently damage the bat-
tery. Optional high-output battery to power both local and optional LED remote lamp heads simultaneously.
INSTALLATION — Universal mounting canopy for top or end mount. Back mount standard for single face only.
Housing snaps to canopy with positive-locking tabs. Cam locking pin secures housing to canopy.
Easily removed mounting knockouts. Conduit entry knockout for 1/2" flexible conduit. J-box pattern on back panel.
Looking for Contractor Select readily available
configurations? Click here to visit Contractor Select™
spec sheet or go to www.contractorselect.com
ORDERING INFORMATION
Lead times will vary depending on options selected. Consult with your sales representative.
LHQM LED
Family Lamp type
LHQM Stencil face, single LED
face plate with
extra face plate
Notes
1 When operating ERE SQ T remotes off of HO battery, temperature range of LHQM LED is
limited to 68°-104°F (20°-40°C), with a 48-hour battery recharge time.
2 Available in black or white. Consult factory for options.
3 Only available in white. NOM standard.
4 Only compatible with self-diagnostic option. (ex: HO SD)
5 Only compatible with HO or HO R0 with SD option. See spec sheet ELA-Q-LED.
6 See spec sheet ELA-WG.
EMERGENCY
Click here for Acrylic- Polycarbonate
Housing color Letter color
Two (blank) White R
1.5W/9.6V
B Black G
white LED
Catalog
Number
Notes
Type
HO R0
LISTINGS — UL damp location listed standard 50°-104°F (10°-40°C). Meets UL 924, NFPA 101 (current Life
Safety Code), NEC and OSHA illumination standards. Meets all applicable FCC Title 47, Part 15, Subpart B
requirements.
BUY AMERICAN ACT — Product with the BAA option is assembled in the USA and meets the Buy America(n)
government procurement requirements under FAR, DFARS and DOT regulations.
Please refer to www.acuitybrands.com/buy-american
WARRANTY — 5-year limited warranty. (Battery is prorated). This is the only warranty provided and no
other statements in this specification sheet create any warranty of any kind. All other express and implied
warranties are disclaimed. Complete warranty terms located at:
www.acuitybrands.com/support/warranty/terms-and-conditions
Note: Actual performance may differ as a result of end-user environment and application.
All values are design or typical values, measured under laboratory conditions at 25 °C.
Specifications subject to change without notice.
† Exit Signs Certified in the CA Title 20 Appliance Efficiency Database.
Options
Red HO High-output Ni-cad
Green HO R0 High-output option, less lamp heads
SD Self-diagnostics
7 See spec sheet ELA-Stemkits.
8 See spec sheet ERE. When operating ERE SQ T remotes off of HO battery, temperature range
of LHQM LED is limited to 68°-104°F (20°-40°C), with a 48-hour battery recharge time.
9 Not available with SD. Only compatible with HO or HO R0 option. When operating ERE SQ
T remotes off of HO battery, temperature range of LHQM LED is limited to 68°-104°F (20°-
40°C), with a 48-hour battery recharge time.
LHQM LED
for additional information.
NOM Meets Mexican standards
1
NOM SALIDA Salida signage (non-UL)
BAA Buy America(n) Act Compliant
Thermoplastic Exits
LED Lamp Head
Nickel-Cadmium Battery
†
Example: LHQM LED G
2
3
LHQM-LED
