Chapter 2 Cabling and Troubleshooting the CSS
Figure 2-9
Figure 2-9
1
1
2
Table 2-6
Table 2-6
LED Name
Status
(left)
Status
(right)
78-13884-06
illustrates the SSL module front panel LEDs.
SSL Module LEDs
2
3
ST AT US ST AT US
4
Bicolor status LED (green and red) 3
Amber status LED
describes the LEDs.
SSL Module LED Descriptions
Color State
Green Solid
Red Solid
Slow blink
No color Off
Amber Fast blink
Slow blink
Solid
Off
Cisco 11500 Series Content Services Switch Hardware Installation Guide
Cabling the CSS 11503 and CSS 11506 Modules
Spring-loaded screw (one of two)
4
Ejector (one of two)
Indicates
The module is ready.
The module failed the power-up self test
during the boot process.
The module failed.
The module failed and has no power.
The module is running power-up self test.
The module is offline and active.
The module is online and not active.
See the left status LED for indication.
2-21
