Chapter 2
Cabling and Troubleshooting the CSS
Session Accelerator Module LEDs
78-13884-06
The Session Accelerator Module (SAM), model CSS5-SAM, is used with the
SCM to provide additional processing support for session setup. The SAM front
panel LEDs indicate its operational status. The SAM has no connectors.
Figure 2-8
illustrates the SAM front panel LEDs.
Figure 2-8
Session Accelerator Module LEDs
2
ST AT US
ST AT US
1
1
Bicolor status LED (green and red) 3
2
Amber status LED
Cisco 11500 Series Content Services Switch Hardware Installation Guide
Cabling the CSS 11503 and CSS 11506 Modules
3
4
4
Spring-loaded screw (one of two)
Ejector (one of two)
2-19
