Belleze Calvin 014-HG-41862 Manual

Tv fire stand
Hide thumbs

Advertisement

Table of Contents

Calvin TV Fire Stand
FOLLOW US:
@bellezefurniture
CONTACT INFO:
support@belleze.com
1-800-682-6376
www.belleze.com
ITEM NO. 014-HG-41862
The instruction booklet contains IMPORTANT
safety information. Please read it in full and
keep it for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Calvin 014-HG-41862 and is the answer not in the manual?

Questions and answers

Related Manuals for Belleze Calvin 014-HG-41862

Summary of Contents for Belleze Calvin 014-HG-41862

  • Page 1 Calvin TV Fire Stand FOLLOW US: CONTACT INFO: ITEM NO. 014-HG-41862 The instruction booklet contains IMPORTANT support@belleze.com @bellezefurniture safety information. Please read it in full and 1-800-682-6376 keep it for future reference. www.belleze.com...
  • Page 2 Scan this QR Code to view our online tutorial Estimated time for assembly: 120 mins Weight limitations are as follows: Maximum Load 70 lb Maximum Load 20 lb...
  • Page 3 Assemble the furniture on an empty carton, carpet, or rug to prevent scratches or damage. For safety, please keep pets and children away from the assembly area. Ensure the product is fully assembled before use. If you are missing any hardware or products, do not use it until you have restored the missing parts.

  • Page 4: Package Contents

    PACKAGE CONTENTS...
  • Page 5 PACKAGE CONTENTS CODE DESCRIPTION Top Panel Bottom Panel Left Lateral Panel Right Lateral Panel Left Medial Panel Right Medial Panel Center Panel Divider Panel Center Back Panel Side Back Panel Storage Shelf Panel Left Cabinet Door Right Cabinet Door Left Trim Panel Right Trim Panel Top Surround Strip Left Surround Strip...
  • Page 6 PACKAGE CONTENTS 57x + 4x 57x + 4x 57x + 4x 36x + 4x 18x + 1x 24x + 2x Install all hardware perpendicular to the opening.
  • Page 7 PACKAGE CONTENTS Install all hardware perpendicular to the opening. v.09182024...
  • Page 8 Required tools for assembly (Not included) Attach cam bolts to the lateral panels (3, 4).
  • Page 9 Attach cam bolts both sides of the medial panels (5, 6) and the center panel (7). Flip Flip Flip v.09182024...
  • Page 10 Insert wood dowels to the lateral panels (3, 4), medial panels (5, 6), center panel (7), side back panels (10), trim panels (14, 15), and center crossbar (19).
  • Page 11 Insert small wood dowels to the medial panels (5, 6) and the center panel (7). Assemble surround panels(16, 17, 18) to the medial panels (5, 6) and the center panel (7). v.09182024...
  • Page 12 Assemble the center crossbar (19) to the center panel (7). Assemble the center back panel (9) to the center panel (7).
  • Page 13 Assemble the center panel (7) between the medial panels (5, 6). Secure the center back panel (9) to the medial panels (5, 6). v.09182024...
  • Page 14 Assemble side back panels (10) to the outside of the medial panels (5, 6). Attach trim panels (14, 15) to the lateral panels (3, 4).
  • Page 15 Secure the trim panels (14, 15) in place with screws. Assemble the lateral panels to the outside of the side back panels (10). v.09182024...
  • Page 16 Attach the divider panel (8) on top of the center panel (7). Insert small wood dowels to the top panel (1).
  • Page 17 Attach top crossbar (22) underneath the top panel (1). Attach cam bolts to the top panel (1). v.09182024...
  • Page 18 Assemble the top panel (1) on top of the stand assembly.
  • Page 19 Further secure the top panel (1) to the back panels. v.09182024...
  • Page 20 Secure the trim panels (14, 15) to the top panel (1). Attach cam bolts to the bottom panel (2).
  • Page 21 Place the stand assembly upside down and assemble the bottom panel (2) to the stand. v.09182024...
  • Page 22 Further secure the back panels to the bottom panel (2).
  • Page 23 Insert legs (20) into the base crossbars (21). Secure the legs (20) to the base crossbars (21). Note: Leave bolts 80% tightened. v.09182024...
  • Page 24 Attach the base to the bottom panel (2). Note: Tighten all the bolts.
  • Page 25 Attach center legs to the bottom panel (2). v.09182024...
  • Page 26 Attach magnetic catches to the medial panels (5, 6).
  • Page 27 Insert shelf pegs into the stand and put storage shelf panels (11) onto the pegs. Attach magnetic catch plates to the cabinet doors (12, 13). v.09182024...
  • Page 28 Attach door hinges to the cabinet doors (12, 13). Attach cabinet doors to the stand.
  • Page 29 When the clearance of the door is uneven, Adjust the cabinet door according to the gure. lf you still have trouble while adjusting the door, please contact us. Up and down Side to side In and out adjustment by adjustment using adjustment by loosening the screws the front adjustment...
  • Page 30 Rebound hinge, only need to gently press the doorpanel when opening the door.
  • Page 31 Set the unit from the front of the replace mantel and center it in the opening, check the alignment and attack the unit to the mantel by inserting screws through the drilled holes on the mantel. v.09182024...
  • Page 32 CAUTION: Careful when handling glass to prevent injury or damage. For the exact instruction, please refer to the user's manual.
  • Page 33 Attach anti-tipping straps to the back of the stand. v.09182024...
  • Page 34 Adjust table foot pads. Keeps stable even on uneven floors. device to prevent the furniture from tipping over. • Mark the drill position on the wall with a pencil. • Drill a small hole on the marked position. • Insert a wall anchor into the drilled hole. •...
  • Page 35 Warning Serious or fatal crushing injuries may occur if the furniture tip-over. order to prevent the furniture from tipping over. stability and load bearing capacity of the furniture. If you are uncertain about which type of device to use, please contact us or your local hardware store. Warning Only place items on top of the product if they meet the recommended size and weight limits.
  • Page 36 WARNING For use with televisions weighing 70lbs (31.8kg) or less. Use with heavier televisions may result in instability, causing tip over resulting in death or serious injury. Death or serious injury may occur when children climb on audio and/or video equipment furniture. A remote control or toys placed on the furnishing may encourage a child to climb on the furnishing and as a result the furnishing may tip over on to the child.
  • Page 37 FURNITURE CARE AND MAINTENANCE Medium - Density Fiberboard Thank you for your purchase. We want your item to last as long as possible. To ensure the product gives you years of longevity, please follow the recommendations in this care and maintenance guide. MAINTENANCE •...
  • Page 39 © All copyright of this document belongs to BELLEZE. This document may not be printed, translated, reproduced, or distributed in whole or in part without written permission from BELLEZE. v.09182024...

  • Page 40: Warranty

    WARRANTY BELLEZE products come with a 1-year warranty from the date of delivery. Register your product on our website to enjoy our limited lifetime warranty! AFTER-SALE SERVICE Contact us at 1-800-682-6376 or email us at support@belleze.com We will send you replacement.

This manual is also suitable for:

Calvin 014-hg-41862-cam+036
