- Page 1 Norrell TV Stand w/ Fireplace FOLLOW US: CONTACT INFO: ITEM NO. 014-HG-41802-HT The instruction booklet contains IMPORTANT support@belleze.com @bellezefurniture safety information. Please read it in full and 1-800-682-6376 keep it for future reference. www.belleze.com...
- Page 2 Scan this QR Code to view our online tutorial Estimated time for assembly: 120 mins Weight limitations are as follows: Maximum Load 70 lb Maximum Load 20 lb...
- Page 3 Assemble the furniture on an empty carton, carpet, or rug to prevent scratches or damage. For safety, please keep pets and children away from the assembly area. Ensure the product is fully assembled before use. If you are missing any hardware or products, do not use it until you have restored the missing parts.
-
Page 4: Package Contents
PACKAGE CONTENTS... - Page 5 PACKAGE CONTENTS CODE DESCRIPTION Top Panel Upper Side Panel Divider Panel Middle Shelf Panel Upper Back Panel Side Back Panel Crossbar Cabinet Door Left Side Panel Left Medial Panel Right Medial Panel Right Side Panel Right Support Baffle Left Support Baffle Storage Shelf Panel Base v.07252022...
- Page 6 PACKAGE CONTENTS 34x + 1x 34x + 1x 22x + 1x 28x + 1x 34x + 1x Install all hardware perpendicular to the opening.
- Page 7 Required tools for assembly (Not included) Attach cam bolts on the base. v.07252022...
- Page 8 Attach wood dowels to the base. Attach cam bolts to the support baffles.
- Page 9 Attach the support baffles to the medial panels. v.07252022...
- Page 10 Assemble the side panels and the medial panels to the base. Attach cam bolts to the underside of the middle shelf panel.
- Page 11 Attach the crossbar underneath the middle shelf panel. Attach the middle shelf panel on top of the side panels and medial panels. v.07252022...
- Page 12 Secure the crossbar to the support baffles. Attach cam bolts on top of the middle shelf panel.
- Page 13 Assemble the upper side panels and the divider panel on the middle shelf panel. v.07252022...
- Page 14 Attach cam bolts under the top panel Assemble the top panel on the assembly.
- Page 15 Attach back panels to the back of the TV stand. Warning lable should be facing outward. v.07252022...
- Page 16 Attach door hinges to the cabinet doors. Attach door knobs to the cabinet doors.
- Page 17 Attach cabinet doors to the TV stand. Up and down In and out adjustment Side to side adjustment adjustment by by loosening the screws using the front loosening the screws on the hinge arm. adjustment screw on on the mounting plate. the hinge.
- Page 18 Insert shelf pegs inside the TV stand and put on the storage shelf panels.
- Page 19 Attach anti-tipping strap behind the TV stand. v.07252022...
- Page 20 Affix the TV stand to the wall. Furniture must permanently fixed to the wall stud with included anti-tipping device to prevent the furniture from tipping over. • Mark the drill position on the wall with a pencil. • Drill a small hole on the marked position. •...
- Page 21 Attach the wood strip on top of the TV stand. 0.2” / 5mm 2” / 50mm YOU’RE FINISHED! v.07252022...
-
Page 22: Fireplace Installation
FIREPLACE INSTALLATION Set the unit from the back of the fireplace mantel and center it in the opening. Check the alignment and attach the unit to the mantel by inserting screws through the drilled holes on the mantel. For the exact instruction, please refer to the user’s manual provided with the fireplace. - Page 23 Warning Only place items on top of the product if they meet the recommended size and weight limits. Climbing on, stepping on, or placing overweighted objects on the product may cause property damage and/or injuries. Items placed onto this product must be resting on a support surface without hanging over the edges.
- Page 24 ⚠ WARNING For use with televisions weighing 70lbs (31.8kg) or less. Use with heavier televisions may result in instability, causing tip over resulting in death or serious injury. Death or serious injury may occur when children climb on audio and/or video equipment furniture. A remote control or toys placed on the furnishing may encourage a child to climb on the furnishing and as a result the furnishing may tip over on to the child.
- Page 25 FURNITURE CARE AND MAINTENANCE Medium - Density Fiberboard Thank you for your purchase. We want your item to last as long as possible. To ensure the product gives you years of longevity, please follow the recommendations in this care and maintenance guide. MAINTENANCE •...
- Page 27 © All copyright of this document belongs to BELLEZE . This document may not be printed, translated, reproduced, or distributed in whole or in part without written permission from BELLEZE. v.07252022...
-
Page 28: Warranty
WARRANTY BELLEZE products come with a 1-year warranty from the date of delivery. Register your product on our website to enjoy our limited lifetime warranty! AFTER-SALE SERVICE Encounter any difficulties or missing parts? Contact us at 1-800-682-6376 or email us at support@belleze.com We will send you replacement.
