- Page 1 Trussati TV Stand FOLLOW US: CONTACT INFO: ITEM NO. 014-HG-41010 The instruction booklet contains IMPORTANT support@belleze.com @bellezefurniture safety information. Please read it in full and 1-800-682-6376 keep it for future reference. www.belleze.com...
- Page 2 Scan this QR Code to view our online tutorial Estimated time for assembly: 0 mins Weight limitations are as follows: Maximum Load 80 lb Maximum Load 20 lb...
- Page 3 Assemble the furniture on an empty carton, carpet, or rug to prevent scratches or damage. For safety, please keep pets and children away from the assembly area. Ensure the product is fully assembled before use. If you are missing any hardware or products, do not use it until you have restored the missing parts.
-
Page 4: Package Contents
PACKAGE CONTENTS... - Page 5 PACKAGE CONTENTS CODE DESCRIPTION Top Panel Bottom Panel Side Panel Left Medial Panel Right Medial Panel Vertical Support Panel Center Panel Back Panel Side Storage Panel Center Storage Panel Front Base Panel Back Base Panel Left Base Panel Right Base Panel Base Support Panel Cabinet Door Drawer Front Panel...
- Page 6 Install all hardware perpendicular to the opening.
- Page 7 PACKAGE CONTENTS Install all hardware perpendicular to the opening. 2023...
- Page 8 Required tools for assembly (Not included) Attach cam bolts to the front, back, left and right base panels (11, 12, 13, 14).
- Page 9 Insert wood dowels to the back, left, right, and support base panels (12, 13, 14, 15). Attach corner connectors to the front, back, left and right base panels (11, 12, 13, 14). 2023...
- Page 10 Assemble the left, right base panels (13, 14), base support panels (15) to the back base panel (12). Assemble the front base panel (11) to the base assembly.
- Page 11 Attach cam bolts to the underside of the bottom panel (2). Assemble the base assembly to the bottom panel (2). 2023...
- Page 12 Further secure the base support panels to the base panel. Attach cam bolts on top of the bottom panel (2).
- Page 13 Detatch the slide runner from the slide mount. Slide Mount Slide Runner Attach the slide runners to the left and right medial panels (3, 4). Make sure to insert screws in the correct opening. 2023...
- Page 14 Attach cam bolts to the left and right medial panels (4, 5) and the vertical support panels (6). Insert wood dowels to the left and right medial panels (4, 5).
- Page 15 Assemble the center panel (7) between the left and right medial panels (4, 5). Insert wood dowels to the side panels (3). 2023...
- Page 16 Assemble the vertical support panels (6) to the side panels (3).
- Page 17 Assemble side panels (3), left and right medial panels (4, 5) on the bottom panel (2). 2023...
- Page 18 Attach cam bolts to the underside of the top panel (1). Assemble the top panel (1) on top of the assembly.
- Page 19 Assemble the back panels (8) to the back of the stand. 2023...
- Page 20 Attach slide runners to the drawer left and right panels (18, 19). Make sure to insert screws in the correct opening. Assemble the drawer back panel (20) between the drawer left and right panels (18, 19).
- Page 21 Slide the drawer bottom panel (21) into the drawer assembly. Attach cam bolts to the drawer front panel (17). 2023...
- Page 22 Assemble the drawer support panel (22) to the drawer assembly. Assemble the drawer front panel (17) to the drawer assembly.
- Page 23 Secure the drawer support panel to the drawer front panel. Attach drawer handle to the drawer. 2023...
- Page 24 Insert shelf pegs into the stand and put on the storage shelf panels (9, 10).
- Page 25 Slide the drawer into the stand. Slide the slider plate to the forward position. Up and down adjustment by loosening the screws on the slide runner. 2023...
- Page 26 Attach door hinges to the cabinet doors (16). Attach door handles to the cabinet doors (16).
- Page 27 Assemble the cabinet doors to the stand. Adjust the position of the cabinet doors. 2023...
- Page 28 Attach anti-tipping straps to the back of the stand.
- Page 29 device to prevent the furniture from tipping over. • Mark the drill position on the wall with a pencil. • Drill a small hole on the marked position. • Insert a wall anchor into the drilled hole. • Fixed the anti-tipping strap to the wall with provided screws. 2023...
- Page 30 Stick the wood trip (23) on top of the TV stand. NOTE: Put the TV behind the wood strip to prevent it from falling o . YOU’RE FINISHED!
- Page 31 Warning Only place items on top of the product if they meet the recommended size and weight limits. Climbing on, stepping on, or placing overweighted objects on the product may cause property damage and/or injuries. Items placed onto this product must be resting on a support surface without hanging over the edges.
- Page 32 WARNING For use with televisions weighing 80lbs (36.3kg) or less. Use with heavier televisions may result in instability, causing tip over resulting in death or serious injury. Death or serious injury may occur when children climb on audio and/or video equipment furniture. A remote control or toys placed on the furnishing may encourage a child to climb on the furnishing and as a result the furnishing may tip over on to the child.
- Page 33 FURNITURE CARE AND MAINTENANCE Medium - Density Fiberboard Thank you for your purchase. We want your item to last as long as possible. To ensure the product gives you years of longevity, please follow the recommendations in this care and maintenance guide. MAINTENANCE •...
- Page 35 © All copyright of this document belongs to BELLEZE . This document may not be printed, translated, reproduced, or distributed in whole or in part without written permission from BELLEZE. 2023...
-
