Viewing Sample Configuration Files

This appendix contains examples of Cisco uBR7200 series universal broadband router configuration
files. To view the current configuration of a Cisco uBR7200 series router, enter the show running-config
command at the CLI prompt in EXEC mode or privileged EXEC mode.

Basic Internet Access Examples

General Example
This section provides a Cisco Release 12.0(5)T sample configuration file for the Cisco uBR7246,
including spectrum management and modulation profile configuration for QAM 16:
version 12.0
no service pad
service timestamps debug uptime
service timestamps log uptime
no service password-encryption
!
hostname uBR7246
!
boot system flash slot0:ubr7200-p-mz.120-5.T
boot system flash
!
cable spectrum-group 1 frequency 40000000
cable spectrum-group 1 frequency 20000000 2
cable modulation-profile 3 request 0 16 1 8 16qam scrambler 152 no-diff 128 fixed uw16
cable modulation-profile 3 initial 5 34 0 48 16qam scrambler 152 no-diff 256 fixed uw16
cable modulation-profile 3 station 5 34 0 48 16qam scrambler 152 no-diff 256 fixed uw16
cable modulation-profile 3 short 5 75 6 8 16qam scrambler 152 no-diff 144 fixed uw8
cable modulation-profile 3 long 8 220 0 8 16qam scrambler 152 no-diff 160 fixed uw8
no cable qos permission create
no cable qos permission update
cable qos permission modems
ip subnet-zero
ip dhcp relay information option
!
interface FastEthernet0/0
ip address 10.1.70.2 255.255.255.0
no ip directed-broadcast
no ip mroute-cache
!
!
interface Ethernet2/3
ip address 1.3.59.1 255.255.0.0
