Configuring the Cisco uBR7200 Series Using the Setup Facility
Complete these steps to activate upstream interfaces:
After the Setup facility has initially configured noncable interfaces on the Cisco uBR7200 series router,
Step 1
enter the enable command and your password (privileged EXEC).
Step 2 Enter the configure terminal command to get into global configuration mode.
Step 3 In global configuration mode, configure modulation profiles and spectrum groups for your
Cisco uBR7200 series router using the cable modulation-profile and cable spectrum-group
commands.
In cable interface configuration mode, configure various characteristics for the interface in question,
Step 4
using the cable upstream commands.
Refer to
Note
information.

Configuring Interfaces with the Setup Facility

Follow the procedure in this section to configure WAN or LAN interfaces. To configure interface
parameters, have your interface network addresses and subnet mask information ready.
Configuring Ethernet Interfaces
In the following example, the system is being configured for an Ethernet LAN using IP. Respond to the
Step 1
prompts as follows, using your own addresses and mask at the setup prompts:
Configuring interface parameters:
Configuring interface Ethernet0/0:
Is this interface in use? [no]: yes
Configure IP on this interface? [no]: yes
IP address for this interface: 1.1.1.10
Number of bits in subnet field [0]:
Class A network is 1.0.0.0, 0 subnet bits; mask is 255.0.0.0
Do not enable Internetwork Package Exchange (IPX) on this interface; IPX is not supported on the Cisco
Step 2
uBR7200 series universal broadband router:
Configure IPX on this interface? [no]: no
If additional Ethernet interfaces are available in your system, enter their configurations when you are
Step 3
prompted.
Step 4 Save the configuration to NVRAM:
Router# copy running-config startup-config
You must always manually save the configuration settings to NVRAM whenever they are modified.
Note
Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide
2-22
Chapter 2, "Configuring the Cable Modem Termination System for the First Time,"
Chapter 2 Configuring the Cable Modem Termination System for the First Time
for further
