Installing the Cisco 7204
This chapter explains the procedures for installing and starting the Cisco 7204. The chapter
contains the following sections:
•
Rack-Mounting the Cisco 7204
•
General Installation
•
Connecting Port Adapter Cables
•
Connecting I/O Controller Cables
•
Connecting Power
•
Starting the Cisco 7204
A rack-mounting kit is included in the shipping container for mounting the Cisco 7204 in
a standard 19-inch-wide equipment rack or in a 19-inch Telco-type rack. The kit is not
suitable for use with other racks, such as 23-inch Telco racks. If you are installing an
equipment shelf or using mounting hardware other than that supplied with the chassis,
review the guidelines in the section "Equipment Racks" in the chapter "Preparing for
Installation," then proceed to the section "General Installation" in this chapter.
If you plan to install your Cisco 7204 in an equipment rack, proceed to the section "General
Installation" later in this chapter.
C H A P T E R
3
Installing the Cisco 7204 3-1

Advertisement

Table of Contents
loading

Related Manuals for Cisco 7204

Summary of Contents for Cisco 7204

  • Page 1 “Equipment Racks” in the chapter “Preparing for Installation,” then proceed to the section “General Installation” in this chapter. If you plan to install your Cisco 7204 in an equipment rack, proceed to the section “General Installation” later in this chapter.

  • Page 2: Rack-Mounting The Cisco 7204

    The inlet and exhaust ports for cooling air are located on the right and left of the chassis, respectively, so multiple routers can be stacked in a rack with little or no vertical clearance. 3-2 Cisco 7204 Installation and Configuration Guide...
  • Page 3 Rack-Mounting the Cisco 7204 Figure 3-1 Typical 19-Inch Equipment Rack Posts and Mounting Strips Rack posts 110 VAC 18.312" outlets hole C to C Mounting strips 17.00 " min. Installing the Cisco 7204 3-3...

  • Page 4: Installing The Brackets On The Chassis

    (One person should support the chassis in the rack while the second person installs the fasteners.) To see translated versions of this warning, refer to the publication Regulatory Compliance and Safety Information for the Cisco 7200 Series Routers (Document Number 78-3419-xx) that accompanied your Cisco 7204.

  • Page 5: Installing The Chassis In The Rack

    Installation,” before installing the router in a rack. To see translated versions of this warning, refer to the publication Regulatory Compliance and Safety Information for the Cisco 7200 Series Routers (Document Number 78-3419-xx) that accompanied your Cisco 7204. Installing the Chassis in the Rack After installing the brackets on the chassis, mount the router by securing the brackets to two posts or mounting strips in the rack using the eight slotted screws provided.
  • Page 6 Warning near the bottom of the rack. To see translated versions of this warning, refer to the publication Regulatory Compliance and Safety Information for the Cisco 7200 Series Routers (Document Number 78-3419-xx) that accompanied your Cisco 7204. 3-6 Cisco 7204 Installation and Configuration Guide...
  • Page 7 floor and, if necessary, anchored with appropriate fixtures. To see translated versions of this warning, refer to the publication Regulatory Compliance and Safety Information for the Cisco 7200 Series Routers (Document Number 78-3419-xx) that accompanied your Cisco 7204.
  • Page 8 To prevent damage to the chassis or personal injury, never attempt to lift or tilt the Cisco 7204 using the port adapter handles or the I/O controller handle; they are not designed to support the weight of the router. Always have someone help you when installing the Cisco 7204.

  • Page 9: General Installation

    If not, refer to the section “Site Requirements” in the chapter “Preparing for Installation.” When installing the Cisco 7204 on a workbench or tabletop, ensure that the surface is clean and in a safe location and that you have considered the following: •...

  • Page 10: Connecting Port Adapter Cables

    This configuration note accompanies every Token Ring port adapter that is shipped from the factory as an installed item in a Cisco 7204 or as a FRU. The document is also available on the Cisco Connection Documentation, Enterprise Series CD, and on Cisco Connection Online (CCO).

  • Page 11: Console And Auxiliary Port Connection Equipment

    The auxiliary port is a DTE DB-25 plug for connecting a modem or other DCE device (such as a CSU/DSU or other router) to the Cisco 7204 (refer to Figure 3-6). Both the console and auxiliary ports are asynchronous serial ports; any devices Note connected to these ports must be capable of asynchronous transmission.
  • Page 12 For console and auxiliary port pinouts, refer to the following sections “Console Port Signals” and “Auxiliary Port Signals.” Figure 3-6 Console and Auxiliary Port Connections Console Auxiliary port port FAST ETHERNET INPUT/OUT PUT CONTROLL ER Modem Console terminal 3-12 Cisco 7204 Installation and Configuration Guide...

  • Page 13: Console Port Signals

    Table 3-1 lists the signals used on the console port. The console port requires a straight-through EIA/TIA-232 cable. Table 3-1 Console Port Signals Signal Direction Description – Ground <— Transmit Data —> Receive Data —> Data Set Ready (always on) – Ground —> Data Carrier Detect (always on) Installing the Cisco 7204 3-13...

  • Page 14: Auxiliary Port Signals

    Figure 3-7). Caution Make sure input power to your Cisco 7204 is turned off and the router is completely powered down before connecting an external transceiver to the Fast Ethernet port on the I/O controller. If you connect an external transceiver to the Fast Ethernet port when the router is powered on, the system will reset and you could lose data.
  • Page 15 MII port. MII cables and transceivers have knurled thumbscrews that you fasten to the jackscrews on the MII connector and tighten with your fingers. Use the jackscrews to secure your MII cable to the MII receptacle. Figure 3-8 MII Receptacle Pin 1 Jackscrew Pin 21 Installing the Cisco 7204 3-15...
  • Page 16 – – – Common (ground) 1, 20, 21, 40 – – – +5.0 volts (V) 1. Any pins not indicated are not used. 2. Tx_CLK and Rx_CLK are provided by the external transceiver. 3-16 Cisco 7204 Installation and Configuration Guide...

  • Page 17: Connecting Power

    Connecting Power Connecting Power Following are the procedures for connecting AC-input power to your Cisco 7204. Detailed instructions for handling and replacing the Cisco 7204 power supplies are Note contained in the configuration notes Cisco 7200 Series 280-Watt AC-Input Power Supply...
  • Page 18 Repeat Step 1 through Step 4 for the second power supply (if present). Step 5 This completes the procedure for connecting power. Proceed to the following “Starting the Cisco 7204,” to start the router. 3-18 Cisco 7204 Installation and Configuration Guide...

  • Page 19: Starting The Cisco 7204

    Starting the Cisco 7204 Starting the Cisco 7204 After installing your Cisco 7204 and connecting cables, start the router as follows: Check for the following: Step 1 • Each port adapter is inserted in its slot and its respective port adapter lever is in the locked position.
  • Page 20 Starting the Cisco 7204 Configure the interfaces. When you start up the Cisco 7204 for the first time, the Step 6 system automatically enters the setup command facility, which determines which port adapters are installed and prompts you for configuration information for each one.
