Summarization of Contents
Information
Information Details
Details on meter display menus, activation via magnet, and radio performance impact on battery life.
Radio Activation Methods
Explains two methods for activating the meter radio: water flow and in-display menu.
Certified Module Information
Lists FCC ID and IC for the certified module.
Installation of the external antenna
Antenna Installation Procedure
Details on installing the cellular antenna before meter commissioning.
Proper Antenna Seating
Instructions to ensure the antenna is correctly seated without gaps for optimal connection.
Radio activation
Radio Activation with Water Flow
Explains automatic radio activation when water flows through the meter.
Network Call after Water Flow
Describes the meter performing a network call and indicating success with 'donE'.
Radio Activation via In-Display Menu
Guides on activating the menu using a magnet on the optical interface.
Navigating Menu for Radio Activation
Steps to navigate to and activate 'do CALL' using the magnet.
Network Call Confirmation
Meter returns to normal display and performs a network call, showing 'done' on success.
Network performance check
Initial Network Performance Check
Importance of network check during commissioning; checking 'no49' for status if 'donE' not shown.
Typical Installation Status Codes
Lists common status codes encountered during installation and their meanings.
Radio Link Quality Status
How to check radio link quality using menu 'no47' and interpret network connection status.
Connection Quality Assessment
Interpreting the last digit for connection quality (Poor to Excellent) and its implications.
Cellular network performance
Checking Meter Network Performance
Recommends checking radio performance and ensuring it's at least medium for battery lifetime.
