Large Send Offload v2 (IPv4)

The Large Send Offload v2 (IPv4) feature allows you to control the load of
sending out large packets. When this feature is enabled, the 2711 series
adapter segments large packets for IPv4 traffic and reduces the CPU load.
This feature, which supports large packets up to 256kb, overrides the
Large Send Offload (IPv4) feature if both features are enabled.
To enable or disable the Large Send Offload v2 (IPv4) feature, do the
following:
1. Access the Advanced Properties.
See "Accessing Advanced Properties" on page 52.
2. Select Large Send Offload v2 (IPv4) in the Property box.
The Large Send Offload v2 (IPv4) page is displayed as shown in
Figure 28.
Figure 28. Large Send Offload v2 (IPv4) Page
2711 Series Fast Ethernet Adapter Installation Guide
69
