NATURAL GAS BURNER SYSTEM MODEL SDVBNC WITH
PROPANE/LP GAS BURNER SYSTEM CONVERSION KIT
IMPORTANT: This direct-vent burner system must be installed into approved Comfort Glow cast iron
WARNING: If the information in this manual is not followed
exactly, a fire or explosion may result causing property
damage, personal injury, or loss of life.
Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch
• Do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
This appliance may be installed in an aftermarket*, permanently located, manufactured (mo-
bile) home, where not prohibited by state or local codes.
This appliance is only for use with the type of gas indicated on the rating plate. This appli-
ance is not convertible for use with other gases, unless a certified kit is used.
* Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer.
CAST IRON STOVE AND DIRECT-VENT
(FREESTANDING FIREPLACE HEATER)
BURNER SYSTEM
OWNER'S OPERATION AND INSTALLATION MANUAL
REMOTE READY
stove bodies, models CSDBN ONLY.
FOR YOUR SAFETY
FOR YOUR SAFETY
Save this manual for future reference.
Save this manual for future reference.
CSDBN AND
CSDPBN STOVES
WARNING: Improper instal-
lation, adjustment, alteration,
service, or maintenance can
cause injury or property dam-
age. Refer to this manual for
correct installation and op-
erational procedures. For as-
sistance or additional infor-
mation consult a qualified in-
staller, service agency, or the
gas supplier.
Installation and service must
be performed by a qualified
installer, service agency, or
the gas supplier.
Advertisement
Table of Contents
Related Manuals for Comfort Glow CSDBN
Summary of Contents for Comfort Glow CSDBN
- Page 1 (FREESTANDING FIREPLACE HEATER) BURNER SYSTEM OWNER’S OPERATION AND INSTALLATION MANUAL CSDBN AND CSDPBN STOVES REMOTE READY stove bodies, models CSDBN ONLY. WARNING: Improper instal- lation, adjustment, alteration, service, or maintenance can cause injury or property dam- age. Refer to this manual for correct installation and op- erational procedures.
-
