Lochinvar 140H Series Installation Manual And Owner's Manual

On-demand water heater

Hide thumbs Also See for 140H Series:

Installation manual and owner's manual (76 pages)

Table Of Contents

Quick Links

Download this manual

On-Demand Water Heater

Installation Manual and Owner's Guide

ANSI Z21.10.3 ・ CSA 4.3

Models

140H

240H

340H

540H

Gas Tankless Water Heater

Suitable for combination potable water heating

and space heating. Please refer to local codes for

space-heating compliance.

FEATURING

• ENDLESS HOT WATER

• ON-DEMAND USAGE

• COMPACT, SPACE SAVING

• ENERGY CONSERVATION

• COMPUTERIZED SAFETY

• NO PILOT LIGHT

• Complies with SCAQMD Rule

1146.2 for natural gas Low NOx

Emissions of 14 ng/J or 20 ppm.

• EASY-LINK SYSTEM (540H only)

• MULTI-UNIT SYSTEM (540H only)

Keep this manual near the water heater for future reference whenever maintenance, adjustment, or

service is required.

540H only

If the information in these

instructions is not followed

exactly, a fire or explosion may

result causing property damage,

WARNING

personal injury or death.
