Summarization of Contents
Part I Operating Instructions
Fundamentals
Introduction to coordinate systems, dimensions, and positions.
Datum Setting
Methods for establishing workpiece datums using tools or edge finders.
Tool Compensation
Entering tool dimensions (length, diameter) for accurate machining.
Error Messages
Listing and explaining common error messages and their causes.
Part II Installation and Specifications
Items Supplied
List of included ND 720/760 units and optional accessories.
Connections and Mounting
Rear panel connectors, mounting instructions, and power supply details.
Operating Parameters
How to access, change, and understand unit operating parameters.
Data Interface and Output
RS-232-C/V.24 interface, data transmission, and measured value output.
