Summarization of Contents
SAFETY AND WARNINGS
Electrical Shock Hazard
Warning about electrical risks during installation and operation.
Cut Hazard Warning
Warning about sharp edges on panels causing injury or cuts.
Integrated Panel Electrical Safety
Warning for fitting front panels, earthing components and electrical safety.
PARTS SUPPLIED
List of Installation Components
An overview of all parts provided for installation, including hardware and accessories.
CABINETRY DIMENSIONS
Minimum Clearances for Cabinetry
Requirements for spacing from surrounding cabinets to ensure proper operation and ventilation.
CUSTOM DRAWER PANEL CALCULATIONS
Calculate Drawer Panel Width
Steps for determining the correct width for custom drawer front panels.
Calculate Upper Drawer Panel Height
Steps for determining the correct height for custom upper drawer panels.
Calculate Lower Drawer Panel Height
Steps for determining the correct height for custom lower drawer panels.
CUSTOM TOEKICK PANEL CALCULATIONS
Calculate Toekick Panel Height
Steps for determining the correct height for custom toekick panels.
CAVITY PREPARATION
Water Connection and Pressure Requirements
Details on water supply connection, recommended temperature and pressure limits.
Kosher Installation Considerations
Specific guidelines and recommendations for installations adhering to kosher requirements.
Service Hole Guidelines
Guidance on creating service holes for utilities, including material and edge treatment.
INSTALLATION METHOD A: SECURE WITHOUT DRAWER REMOVAL
Attach Side Mounting Brackets
Procedure for securing mounting brackets to the cabinetry sides.
Route Hoses and Position Unit
Steps for routing hoses and pushing the appliance into the cavity.
Secure to Cabinetry on Sides
Secure to Cabinetry on Sides
Fastening the appliance securely to the cabinet sides using mounting brackets.
Optional Secure to Cabinetry Above
Optional method for securing the appliance to the top of the cabinetry.
INSTALLATION METHOD B: SECURE BY DRAWER REMOVAL
Route Hoses and Position Unit
Steps for routing hoses and pushing the appliance into the cavity.
Remove the Lower Drawer
Procedure for safely removing the lower drawer from its runners.
Secure to Cabinetry on Sides
Secure to Cabinetry on Sides
Fastening the appliance securely to the cabinet sides using mounting brackets.
Optional Secure to Cabinetry Above
Optional method for securing the appliance to the top of the cabinetry.
INSTALLING CUSTOM FRONT DRAWER PANELS
Remove Panel Brackets from Product
Detaching the front drawer panel brackets from the main appliance unit.
Remove Knock-to-Pause Module
Detaching the knock-to-pause module from the appliance.
Attach Custom Panels to Brackets
Attach Custom Panels to Brackets
Connecting custom front panels to the detached appliance brackets.
Attach Knock-to-Pause Module to Panels
Connecting the knock-to-pause module to the custom front panels.
Connect Module to Controller
Connect Module to Controller
Connecting the knock-to-pause module cable to the unit's controller.
Reconnect Earth Wire to Panel Bracket
Reattaching the earth wire to the panel bracket for electrical safety.
Attach Custom Panels to Product
Mounting the custom front panels onto the main appliance unit.
Adjust Custom Panel Height for Alignment
Fine-tuning panel height to achieve proper alignment with cabinetry gaps.
FITTING A CUSTOM TOEKICK PANEL
Select Toekick Depth and Cutout Profile
Choosing the correct toekick panel cutout profile based on its depth.
PLUMBING AND DRAINAGE OPTIONS
Drainage Option 1: Standpipe Connection
Connecting the drain hose to a standpipe as per Option 1.
Drainage Option 2: Sink Trap Connection
Connecting the drain hose via a sink trap joiner as per Option 2.
