  • Page 1

    STYLISTIC ST Series EasyGuide...

  • Page 2

    Are there ..any technical problems or other questions which you would like to be clarified? Please contact: ● our Hotline/Help Desk (see Help Desk List or the Internet: http://ts.fujitsu.com/helpdesk) ● your sales partner ● your sales office The latest information on our products, tips, updates etc. can be found on the Internet at:...

  • Page 4

    Published by Fujitsu Technology Solutions GmbH A26391-K279-Z220-1-7619, Edition 1 2009/04 Produced by XEROX Global Services...

  • Page 5: User Guide

    Introduction Manufacturer’s notes Important notes Index Equipment overview STYLISTIC ST6012 Preparing the Tablet PC for use Using the Tablet PC User Guide Memory expansion Security functions Troubleshooting and tips Technical data Tablet Dock (optional) April 2009 edition...

  • Page 6

    Intel and Pentium are registered trademarks of Intel Corporation, USA. The SD Logo is a trademark of Secure Digital. The Bluetooth trademarks are the property of Bluetooth SIG, Inc., U.S.A. licensed for Fujitsu Technology Solutions GmbH. All other trademarks referenced are trademarks or registered trademarks of their respective owners, whose protected rights are acknowledged.

  • Page 7: Table Of Contents

    Contents Innovative technology........................1 Notational conventions ......................... 1 Important notes ..........................3 Safety notes............................3 Additional safety notes for devices with radio components............4 Notes on installing and removing boards and components............4 Protecting the screen..........................5 On the move with your Tablet PC......................8 Before you travel ..........................

  • Page 8

    Contents Memory cards .............................39 Inserting a memory card ......................39 Removing a memory card......................40 Wireless LAN / Bluetooth / UMTS radio components (optional) ............40 Switching radio components on and off ..................41 Memory expansion..........................43 Removing and installing memory modules ..................43 Removing a memory module ......................43 Installing a memory module ......................45 Security functions ..........................49 Brief overview of security functions.....................49...

  • Page 9: Innovative Technology

    Innovative technology ... ensures that the Table PC STYLISTIC ST is a reliable and convenient system. The operating system is pre-installed on the hard disk to make things easier when you use the Tablet PC for the first time. This manual tells you how to set up your Tablet PC, and how to operate it on a day-to-day basis. Notational conventions The following notational conventions are used in this manual: Indicates information which is important for your health, the operability of your...

  • Page 10

    Innovative technology A26391-K279-Z220-1-7619, edition 1...

  • Page 11: Important Notes

    Important notes In this chapter you will find information regarding safety, which is essential to observe when using your Tablet PC. The other notes provide useful information on your Tablet PC. Safety notes Pay attention to the information provided in the "Safety" manual and in the following safety notes.

  • Page 12: Additional Safety Notes For Devices With Radio Components

    With data traffic via a wireless connection, it is also possible for unauthorised third parties to receive data. Fujitsu Technology Solutions GmbH cannot be held responsible for radio or television faults arising from unauthorised modifications made to this device. Fujitsu Technology Solutions GmbH is, furthermore, not responsible for replacing and / or exchanging connector cables and devices which have not been specified by Fujitsu Technology Solutions GmbH.

  • Page 13: Protecting The Screen

    Important notes Protecting the screen The Tablet PC is designed to provide you with years of service. Using a screen protector will help ensure that the screen remains as clear as possible. When installed, the screen protector becomes a durable, replaceable writing surface that protects the actual screen from abrasion. Please contact your dealer for additional screen protectors.

  • Page 14

    Important notes ► Remove the protective coating from the adhesive side of the screen protector. ► Align the screen protector with the edges of the screen and place it on the screen surface with the adhesive side downwards (see illustration). ►...

  • Page 15

    Important notes A plastic protective coating is provided on the screen protector that must be pulled off before touching the screen with the pen. ► Carefully lift off the protective plastic coating at the angled corner. Now you can carefully pull off the protective coating (see illustration).

  • Page 16: On The Move With Your Tablet Pc

    To protect against damaging jolts and bumps, use a Tablet PC carrying case to transport the device. Fujitsu Technology Solutions offers a number of solutions for transporting your Tablet PC. Contact your sales outlet. Current offers can be found on the Internet under http://ts.fujitsu.com/accessories.

  • Page 17: Cleaning

    Important notes Cleaning ► Switch the Tablet PC off. ► Pull the power plug for the network adapter out of the mains outlet. ► Remove the battery. Do not clean any interior parts yourself; leave this job to a service technician. Only use cleaning products designed for computers.

  • Page 18: Drivers And Utilities

    Tablet PC onto the hard disk using the "Drivers & Utilities" CD/DVD. You will always find the drivers available when the device was shipped on the "Drivers & Utilities" CD/DVD. Driver updates and manuals are available at http://ts.fujitsu.com/support. Further information Detailed instructions and technical information for your Tablet PC are contained in this "EasyGuide"...

  • Page 19: Overview Of Your Tablet Pc

    Overview of your Tablet PC Top side view Status indicators Microphone ON/OFF switch Infrared receiver for keyboard Application buttons Fingerprint sensor A26391-K279-Z220-1-7619, edition 1...

  • Page 20: Underside

    Overview of your Tablet PC Underside Hard disk service compartment Memory service compartment Port for Tablet Dock Battery release latches WebCam (optional) Battery A26391-K279-Z220-1-7619, edition 1...

  • Page 21: Rear

    Overview of your Tablet PC Rear Pen / pen garage PC card eject button Anchorage for pen retention cord Multi-format card reader ON/OFF switch Ventilation slots PC card slot Release for UMTS antenna Port for SmartCard Left panel Headphone port Tablet Dock latch point Microphone jack LAN port...

  • Page 22

    Overview of your Tablet PC A26391-K279-Z220-1-7619, edition 1...

  • Page 23: Setting Up The Tablet Pc

    Setting up the Tablet PC Observe the relevant notes in the "Important notes" chapter and in the manual for your radio component. You must charge the battery and install the application programmes before you can use the Tablet PC. The operating system and drivers required are preinstalled. For mobile use, the built-in battery provides the Tablet PC with the necessary power.

  • Page 24: Switching On The Tablet Pc For The First Time

    Setting up the Tablet PC ► Connect the mains adapter cable (1) to the DC jack (DC IN) on the Tablet PC . ► Plug the power cable (2) into the mains adapter. ► Plug the power cable (3) into a mains outlet. Switching on the Tablet PC for the first time When you switch on the Tablet PC for the first time, the supplied software is installed and configured.

  • Page 25: Using The Tablet Pc

    Using the Tablet PC This chapter describes the basics for operating your Tablet PC. Please refer to the notes in "Important notes". System modes Before you begin using the Tablet PC, review the different system modes that the system provides. Your system may be configured to enter some of these modes automatically after a period of inactivity to conserve battery power.

  • Page 26: Off Mode

    Using the Tablet PC OFF mode All system functions are turned off to conserve power. The system does not respond to the pen or other input. The system consumes the same amount of power whether it is in Hibernate mode or OFF mode.

  • Page 27

    Using the Tablet PC In S3 (Suspend-to-RAM) you may lose unsaved data if the battery is removed and the system is not connected to the mains adapter. The power indicator either flashes (Suspend-to-RAM) or is not displayed (Hibernate) when system operation is suspended, depending on how your system is configured. At this point, programs that were running are stopped, active data is saved, and the system enters one of two different low-power modes, or suspend modes, as explained in the following paragraphs.

  • Page 28: Resuming Operation

    There are two ways to adjust the brightness of your display: Windows XP: ► Click the Fujitsu Menu icon in the task bar at the bottom right of the screen. The message Change tablet and pen settings will be displayed when the cursor is positioned over the icon.

  • Page 29

    Using the Tablet PC Windows Vista: ► Click the Fujitsu Menu icon in the task bar at the bottom right of the screen. When the cursor is on the icon, the message Mobile PC - Windows Mobility Center appears. ►...

  • Page 30: Status Indicator Panel

    Using the Tablet PC Status indicator panel The status of the system functions is displayed by the symbols in the status display. Security button indicator Hard disk indicator Battery charge level indicator Power source indicator Power indicator The following table lists the different display states. If an icon is not displayed, it indicates that the related system function is off or inactive.

  • Page 31

    Using the Tablet PC Hibernate mode Either the battery is not installed, the device with mains is not switched on, or the device is in adapter hibernate mode. Hibernate mode If battery is installed during power off, without mains indicator blinks amber for 4 seconds to adapter detect battery.

  • Page 32: Buttons

    Using the Tablet PC Buttons Application buttons Allow you to quickly launch pre-defined applications and utilities by pressing a button. Certain buttons have additional functions. You can activate this additional functions by pressing the Fn button while pressing the application button. The application buttons also have separate additional functions that can be used while the system is booting up.

  • Page 33

    Using the Tablet PC Button name and Tablet PC icon Function description icon (Fn + button) The Alt button performs two functions: Alt button If you hold the Alt button down for two seconds, you can log onto the system again: –...

  • Page 34

    Pressing the Fn button twice in succession within the "sticky" time, causes the Fujitsu Menu to appear on your screen. The Fujitsu Menu is used to change certain system settings. A26391-K279-Z220-1-7619, edition 1...

  • Page 35: Navigation Buttons

    Using the Tablet PC The Fn button has a practical delay function. This allows you to press the two buttons for a shortcut one after the other instead of needing to press them both at the same time. After pressing the Fn button, you have a short time (2 to 3 seconds) to press the second button.

  • Page 36: Additional Functions Of Application And Navigation Buttons

    BIOS Setup. Any changes you make take effect as soon as you save and quit the BIOS Setup. The system is booting up while the Fujitsu Technology Solutions logo is displayed immediately after turning on the system. The following table shows which additional functions the application and navigation buttons offer when booting the system and in the BIOS Setup.

  • Page 37: Pen

    Using the Tablet PC Buttons and icons Purpose (when pressed while the system is booting up) Pressing the Fn button while the system is displaying the operating Fn button system boot menu opens the Windows Advanced Options Menu. This menu allows you to set different operating system modes (such as safe mode).

  • Page 38

    Using the Tablet PC You can use the pen on your notebook as an electronic writing implement to select items and to navigate through menu options and programs. Programs that support handwriting recognition also allow you to write characters directly on the screen with the pen. You can also use the pen as a drawing tool.

  • Page 39: Setting The Pen

    Hold the pen tip less than 1/8 inch (3-5 mm) from the screen and move the pen. Setting the pen Windows XP Under Fujitsu Pen Settings or Tablet and Pen Settingsin the Control Panel you can change various settings for the pen (pressure sensitivity, assignment and function of the rocker button). Windows Vista Under Start symbol –...

  • Page 40: Installing A Pen Cord

    Using the Tablet PC ► To remove the tip; position the tip in the gap between the two ends of the tool. ► Pinch the two ends of the tip changer together so that the tip is firmly clasped (1), then pull it from the barrel. ►...

  • Page 41: Battery

    Tablet PC. Charging, caring for and maintaining the battery Only use batteries approved by Fujitsu Technology Solutions for your device. Take care not to drop the batteries or otherwise damage their casing (fire risk).

  • Page 42: Removing And Installing The Battery

    Removing and installing the battery The battery can be removed from the Tablet PC and replaced with a charged battery. Only use batteries approved by Fujitsu Technology Solutions for your Tablet PC. Never use force when inserting or removing a battery.

  • Page 43: Removing The Battery

    Using the Tablet PC Removing the battery ► Push the battery lock (1) in the direction of the arrow. ► Pull the battery out of the Tablet PC in the direction of the arrow (2). Installing the battery ► Align the battery with the guides in the empty battery compartment. ►...

  • Page 44: Tips For Conserving Battery Power

    Using the Tablet PC Tips for conserving battery power Battery life depends upon the operating system, energy-saving settings and the applications in use. You can extend the life of your battery by conserving battery power: ► Use an external power source such as the mains adapter whenever the system is docked to a Tablet Dock.

  • Page 45: Pc Cards

    Using the Tablet PC PC cards The PC card slot (PCMCIA) on the Tablet PC allows you to install a Type I or Type II PC card. Inserting a PC card ► Insert the PC card, contacts first, into the slot guide. The labelled side of the PC card should be facing upwards.

  • Page 46: Removing A Pc Card

    Using the Tablet PC Removing a PC card ► First click the Safely Remove Hardware icon in the task bar in the bottom right-hand corner of the display. Select the device to be removed and click on Shut down. ► Press the eject button (1).

  • Page 47: Memory Cards

    Using the Tablet PC Memory cards The slot is suitable for storage cards of the "Secure Digital I/O" and "Memory Stick" type. Inserting a memory card ► Gently push the memory card into the slot until you feel it click into place. A26391-K279-Z220-1-7619, edition 1...

  • Page 48: Removing A Memory Card

    "Wireless LAN" manual included in PDF format on the "Drivers & Utilities" CD/DVD or pre-installed on your Tablet PC (optional) under Start - All Programs – AddOn (Windows XP) or Start - All Programs - Fujitsu (Windows Vista) . You will find further information in the online help for Bluetooth and Wireless LAN software.

  • Page 49: Switching Radio Components On And Off

    Using the Tablet PC Switching radio components on and off ► Slide the ON/OFF switch to the "ON" position to activate the radio component. ► Slide the ON/OFF switch to the "OFF" position to deactivate the radio component. A26391-K279-Z220-1-7619, edition 1...

  • Page 50

    Using the Tablet PC A26391-K279-Z220-1-7619, edition 1...

  • Page 51: Memory Expansion

    Memory expansion Your Tablet PC has two DIMM slots. 1 GB and 2 GB modules are available, so that you can install up to 4 GB of memory on your system. A DIMM replacement should only be carried out at a suitable workplace. You must statically discharge yourself (e.g.

  • Page 52

    Memory expansion ► Remove the screws (1). ► Slide the cover off the Tablet PC in the direction of the arrow (2). ► Carefully push the two mounting clips outwards (1). The memory module will snap upwards (2). ► Pull the memory module out of its slot in the direction of the arrow (3). A26391-K279-Z220-1-7619, edition 1...

  • Page 53: Installing A Memory Module

    Memory expansion Installing a memory module ► Switch the Tablet PC off (see "Press the ON/OFF switch to boot the system. ► Switching off the Tablet PC"). Do not attempt to remove or install a memory module when the system is in Suspend mode or running. ►...

  • Page 54

    Memory expansion ► Insert the memory module into the slot (1), contacts first. ► Carefully push the memory module downwards until you feel it click into place (2). The memory module is coded to prevent it from being inserted backwards. ►...

  • Page 55

    Memory expansion ► Confirm that the memory module is recognised by the system. To do so, restart the Tablet PC. The size of the memory module should be displayed in the Info menu in BIOS Setup. The memory module is now installed on your Tablet PC. You can now use the system. A26391-K279-Z220-1-7619, edition 1...

  • Page 56

    Memory expansion A26391-K279-Z220-1-7619, edition 1...

  • Page 57: Security Functions

    Security functions Your Tablet PC enables you to protect your system and personal data against unauthorised access in a number of ways. By combining these options, you can achieve maximum protection for your system. In this chapter you will learn which security functions your Tablet PC is equipped with, the benefits these functions offer you and how to configure and use them.

  • Page 58: Kensington Lock

    Security functions Kensington Lock The Tablet PC has a Kensington Lock mechanism for the Kensington MicroSaver. The Kensington MicroSaver, a sturdy steel cable, allows you to protect your Tablet PC from theft. The Kensington MicroSaver is available as an accessory. Configuring password protection in BIOS Setup Before using the various password protection options for your data security in the BIOS Setup, please note the following:...

  • Page 59

    Security functions ► To assign the user password, highlight the Set User Password field and proceed exactly as when configuring the supervisor password. If you do not want to make any other settings, you can exit BIOS Setup. ► Select the Exit Saving Changes option in the Exit menu. The Tablet PC is rebooted and the new password is effective.

  • Page 60: Password Protection For Starting The Operating System

    Security functions Password protection for starting the operating system You can also use the supervisor password or the user password you have assigned in the BIOS Setup (see "Setting the supervisor and user password") to prevent the operating system from being started up. Activating system protection ►...

  • Page 61: Password Protection For Hard Disk

    Security functions Password protection for hard disk The hard disk password prevents unauthorised access to the hard disk drives and is checked internally each time the system is booted. The condition for this is that you have assigned at least the supervisor password. Activating hard disk protection ►...

  • Page 62: Configuring The Fingerprint Sensor (optional)

    The software for the fingerprint sensor is saved on the hard disk in the C:\AddOn (Windows XP) or C:\Fujitsu (Windows Vista) directory and must be installed. Fingerprint sensor The fingerprint software can be found at C:\AddOn (Windows XP) or C:\Fujitsu (Windows Vista) or on the supplied CD. ►...

  • Page 63: Using The Smartcard Reader

    Security functions Using the SmartCard reader Your tablet PC features an integrated SmartCard reader. With the appropriate software you can use your SmartCard as an alternative to password protection, but also as a digital signature, for encrypting your e-mails or for home banking. SmartCard reader SmartCards SmartCards are not supplied as standard equipment.

  • Page 64: Inserting A Smartcard

    Security functions Inserting a SmartCard Do not use force when inserting and removing the SmartCard. Make sure that foreign objects do not fall into the SmartCard reader. ► Slide the SmartCard into the SmartCard reader with the chip facing upwards and to the front. When the SmartCard is properly inserted, it protrudes by approximately 2 cm.

  • Page 65

    TPM either on the hard disk (installation via Start – All Programs – AddOn (Windows XP) or Start – All Programs – Fujitsu (Windows Vista)) or on the supplied TPM software CD/DVD. Information on using the TPM and the related software is also provided on the TPM software CD/DVD.

  • Page 66

    Security functions A26391-K279-Z220-1-7619, edition 1...

  • Page 67: Troubleshooting And Tips

    ► If you still need assistance resolving the problem, contact the relevant Help Desk for your country (see the Help Desk List or go to http://ts.fujitsu.com/support). Have the ID/serial No. of your system and the DIFS code ready. Troubleshooting...

  • Page 68: Smartcard Reader Is Not Recognised

    Troubleshooting and tips SmartCard reader is not recognised Cause Troubleshooting Chip card inserted incorrectly. ► Make sure you have inserted your SmartCard into the SmartCard reader with the chip facing upwards. ► Check whether the SmartCard you are using is supported.

  • Page 69: Display Screen Is Blank Or Difficult To Read

    Display screen is blank or difficult to read Cause Troubleshooting Brightness set too low. ► Press the Fn button twice to open the Fujitsu Menu. This menu contains the tab for changing the brightness. Power saving has been activated ►...

  • Page 70: Device Is Not Responding To The Pen

    Troubleshooting and tips Device is not responding to the pen Cause Troubleshooting Application or system crashed ► Close the application or restart the Tablet PC by switching it on/off or with a warm boot. ► If the system responds to a keyboard but not to a pen, contact your sales partner or hotline/help desk.

  • Page 71: Technical Data

    Technical data STYLISTIC ST6012 The following table provides general hardware specifications of the Tablet PC. Dimensions and weight Width / Depth / Height 220 x 325 x 23.8-31.7 mm Weight 1.6 kg Processor SU 9400 Chipset Intel GS 45 + ICH9 Storage ●...

  • Page 72

    Technical data ● 6-cell NiMH, 35 mAh Buffer battery ● Battery life (when system is receiving power from buffer battery alone in Suspend-to-RAM mode): Approx. 5 minutes (with full charge) Power adapter Autosensing 100 V - 240 V, 50 Hz - 60 Hz primary, 16 V, 3.75 A secondary, power draw 60 W Environmental conditions Temperature...

  • Page 73: Tablet Dock (optional)

    Tablet Dock (optional) The Tablet Dock is available as optional accessory. Below is a brief description of the Tablet Dock. USB ports DC input connector (DC IN) Release button CD/DVD drive Locking slide System interface for the Tablet PC Kensington lock device A26391-K279-Z220-1-7619, edition 1...

  • Page 74

    Tablet Dock (optional) LAN port Audio Line Out Screen port Inserting and removing Tablet PCYou can use a Tablet-PC STYLISTIC ST with two different battery dimensions in the Tablet Dock. With the larger battery you must adapt the Tablet Dock accordingly. Enlarging mounting surface on Tablet Dock ►...

  • Page 75

    Tablet Dock (optional) Inserting the Tablet PC ► Insert the Tablet PC in the Tablet Dock so that the system interfaces interlock. Make sure that the locking slide is in the upper position. ► Slide the locking slide downwards. Now that it has been locked, you can turn the Tablet PC in the Tablet Dock. You can operate the Tablet PC in a horizontal or vertical position.

  • Page 76

    Tablet Dock (optional) A26391-K279-Z220-1-7619, edition 1...

  • Page 77: Manufacturer's Notes

    Declarations of Conformity You will find the Declarations of Conformity for this device on the Internet at: http://ts.fujitsu.com/products/certificates.html. Fujitsu Technology Solutions hereby declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. CE marking...

  • Page 78: Regulatory Notices

    US trading area. Regulatory information for Tablet PCs without radio device NOTICE: Changes or modifications not expressly approved by Fujitsu Technology Solutions could void this user’s authority to operate the equipment. Notice to Users of Radios and Television These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 79

    Manufacturer’s notes Notice to Users of the US Telephone Network Your Tablet PC may be supplied with an internal modem which complies with Part 68 of the FCC rules. On this Tablet PC is a label that contains the FCC Registration Number and the Ringer Equivalence Number (REN) for this equipment among other information.

  • Page 80

    Repairs to telecommunication equipment should be made by a Canadian authorized maintenance facility. Any repairs or alterations not expressly approved by Fujitsu or any equipment failures may give the telecommunication company cause to request the user to disconnect the equipment from the telephone line.

  • Page 81

    Les réparations de l’équipement de télécommunications doivent être evectuées par un service de maintenance agréé au Canada. Toute réparation ou modification, qui n’est pas expressément approuvée par Fujitsu, ou toute défaillance de l’équipement peut entraîner la compagnie de télécommunications à exiger que l’utilisateur déconnecte l’équipement de la ligne téléphonique.

  • Page 82: Fcc Regulatory Information For Tablet Pcs With Radio Device

    Manufacturer’s notes UL Notice This unit requires an AC adapter to operate. Only use a UL Listed Class 2 adapter. The correct output rating is indicated on the AC adapter label. Refer to the illustration below for the correct AC Adapter output polarity: CAUTION: To reduce the risk of fire, use only 26AWG or larger telecommunications line cord.

  • Page 83

    Manufacturer’s notes If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures: ●...

  • Page 84

    (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesirable operation. Modifications not expressly authorized by Fujitsu Technology Solutions may invalidate the user's right to operate this equipment. A26391-K279-Z220-1-7619, edition 1...

  • Page 85: Index

    Index removing 45 Display Power supply 23 Activating suspend mode 18 Display Mode button 25 Agency approval specifications 69 Display screen blank or difficult to read 65 Application buttons 11, 24 DOC (INDUSTRY CANADA) NOTICES 80 A 27 additional functions 29 Alt 25 B 27 E-Mail button 25...

  • Page 86

    Index Replacing the pen tip 33 Main memory, see Memory expansion Rocker button 30 Mains adapter Selecting menu items 32 connecting 15 Starting programs 32 Mains adapter, port 13 using 30 Memory card Pen garage 13, 14 Memory Stick 41 Pen retention cord, anchorage 13 Memory Stick PRO 41 Pen tip removing tool 33...

  • Page 87

    Index System modes 17 System will not resume operation 64 USB port 13 Using the SmartCard reader 57 Tablet Dock, port 12 Tablet PC Ventilation slots 13 will not resume operation 64 Volume Technical data, Tablet PC 69 too low 67 Tips 63 TPM 58 Transport 8...
